Green rectangular ATX motherboard with silver CPU socket, four black memory slots

MSI

MSI B85-G41 PC Mate LGA 1150 Intel B85 HDMI SATA 6Gb/s USB 3.0 ATX CF Intel motherboard

SKU CH-EMSM-ET2HV

ATX motherboard for 4th-generation Intel Core i5 and i7 processors with four DDR3 memory slots supporting up to 32 GB, one PCI Express 3.0 x16 slot, four SATA ports and HDMI video output

  • CPU Socket TypeLGA 1150
  • CPU Type4th-generation Core i5, i7 (LGA1150)
  • ChipsetIntel B85
  • Number of Memory Slots4x240pin
  • Memory StandardDDR3 1066/1333/1600
  • Maximum Memory Supported32GB
  • Supports 4th-gen Intel Core i5 and i7 processors via LGA 1150 socket
  • Four DDR3 slots accept up to 32 GB at 1066/1333/1600 speeds
  • Realtek ALC887 codec delivers 8-channel high-definition audio
  • Gigabit LAN with Realtek 8111G controller provides 10/100/1000 Mbps connectivity
  • One PCIe 3.0 x16 slot plus one PCIe 2.0 x16 at x4 for expansion

LGA 1150 motherboard for 4th-generation Intel Core

This ATX board uses the Intel B85 chipset and supports 4th-generation Core i5 and i7 processors in the LGA 1150 socket. It provides four DDR3 memory slots running at 1066, 1333 or 1600 speeds in dual-channel mode. The layout includes one PCI Express 3.0 x16 slot, one PCI Express 2.0 x16 slot running at x4, two PCI Express x1 slots and two legacy PCI slots for expansion cards.

Memory capacity and SATA headroom

The board accepts up to 32 GB of DDR3 memory across its four 240-pin slots, giving ample headroom for multitasking and older workloads. Storage connectivity includes four SATA 6 Gb/s ports plus two SATA 3 Gb/s ports, so six drives can be attached before additional controllers are needed. The single PCI Express 3.0 x16 slot handles one modern graphics card, while the x4 slot and PCI slots cover extra I/O or legacy add-in cards.

Realtek audio and gigabit LAN included

Onboard audio uses the Realtek ALC887 codec with 8-channel output for surround sound without a separate card. Networking is handled by a Realtek 8111G controller delivering 1 Gbps wired Ethernet. Rear I/O supplies HDMI video (active only with a CPU that has integrated graphics), two PS/2 ports, two USB 3.0 ports and four USB 2.0/1.1 ports for peripherals.

Highlights

  • Supports 4th-gen Intel Core i5 and i7 processors via LGA 1150 socket
  • Four DDR3 slots accept up to 32 GB at 1066/1333/1600 speeds
  • Realtek ALC887 codec delivers 8-channel high-definition audio
  • Gigabit LAN with Realtek 8111G controller provides 10/100/1000 Mbps connectivity
  • One PCIe 3.0 x16 slot plus one PCIe 2.0 x16 at x4 for expansion

Specifications

BrandMSI
ModelB85-G41 PC Mate
CPU Socket TypeLGA 1150
CPU Type4th-generation Core i5, i7 (LGA1150)
ChipsetIntel B85
Number of Memory Slots4x240pin
Memory StandardDDR3 1066/1333/1600
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express 2.0 x161(running at x4)
PCI Express x12 x PCI Express x1
PCI Slots2 x PCI Slots
Serial ATA (SATA)4 x SATA 6Gb/s
Audio ChipsetRealtek ALC887
Audio Channels8 Channels
LAN ChipsetRealtek 8111G
Max LAN Speed1Gbps
Back I/O Ports1 x HDMI / 2 x PS/2 / 2 x USB 3.0 / 4 x USB 2.0/1.1
PS/22
Video PortsD-Sub + DVI
HDMI1 x HDMI
USB 3.02 x USB 3.0
USB 1.1/2.04 x USB 2.0
Audio Ports3 Ports
Onboard USB2 x USB 3.0 + 4 x USB 2.0
Other Connectors1 x ATX 24-Pin power connector1 x 8-pin ATX 12V power connectorCPU x 2 / System x 3 FAN connectors1 x Clear CMOS jumper1 x Serial port connector1 x TPM Module connector1 x Parallel Port connector1 x Front Panel Audio connector1 x Front Panel connector1 x Chassis Intrusion connector
Form FactorATX
Dimensions (W x L)12" x 8.66"
Power Pin24 Pin
FeaturesSupports 4th Gen Intel Core / Pentium / Celeron processors for LGA 1150 socketSupports DDR3-1600 MemoryUSB 3.0 + SATA 6Gb/sMilitary Class 4: Top Quality & StabilityMilitary Class Essentials: Total Protection for Military Class MotherboardsOC Genie 4: Overclock in 1 SecondClick BIOS 4: Easily Fine-tune Your System4K UHD Support: Ultra-high Definition Visual Experience3 Display Outputs: HDMI/DVI/D-Sub SupportPCI Express Gen 3: World's 1st PCI Express Gen 3 Motherboard BrandMulti-GPU: AMD CrossFire SupportCommand Center: Control & Customize Your PC SettingsFast Boot: Quickly Boo
Package Contents2 x SATAIII CableIO Shield

Questions about this item

Will my existing DDR3-1333 memory work in the four 240-pin slots on this B85-G41 PC Mate?

Yes, the board supports DDR3 at 1066, 1333 and 1600 speeds across four 240-pin slots for up to 32 GB in dual-channel mode.

How can I confirm the Realtek 8111G LAN is running at 1000 Mbps after installation?

Check the network adapter status in the operating system; it should report a 1 Gbps link speed when connected to a gigabit switch or router.

Does the box include SATA cables for the four 6 Gb/s ports and the two 3 Gb/s ports?

The motherboard ships with an I/O shield and driver disc; SATA cables are not included and must be purchased separately for each drive.
