Micro-ATX board, black PCB, silver heatsinks, FM2 socket, four DDR3 slots, single PCIe x16 slot

MSI

MSI FM2-A55M-P33 Socket FM2 AMD A55 motherboard 16GB DDR3

SKU CH-EG8C-5FJPD

Micro-ATX board for FM2 APUs with dual-channel DDR3 up to 2133 MHz and 16 GB capacity

  • CPU Socket TypeSocket FM2
  • CPU TypeAMD A10/A8/A6/A4 series processors supporting Socket FM2 arc
  • ChipsetAMD A55
  • Memory StandardSupports dual-channel DDR3 2133 (overclocking)/1866/1600/133
  • Maximum Memory Supported16GB
  • PCI Slots1 PCIe 2.0 x16 slot 1 PCIe 2.0 x1 slot 1 PCI slot
  • Dual-channel DDR3 up to 2133 MHz for responsive memory performance
  • AMD A55 chipset with Socket FM2 supports A10, A8, A6 and A4 processors
  • Realtek ALC887 provides eight-channel audio output
  • Realtek RTL8111E Gigabit LAN controller for wired networking
  • Micro-ATX board with PCIe 2.0 x16, PCIe 2.0 x1 and legacy PCI expansion slots

Socket FM2 AMD A55 board

This micro-ATX motherboard uses the AMD A55 chipset and a Socket FM2 CPU interface. It is built for AMD A10, A8, A6 and A4 series processors. The board fits compact cases and supports up to 16GB of system memory.

Dual-channel DDR3 up to 2133

Memory runs in dual-channel mode at 1066, 1333, 1600, 1866 or 2133MHz with overclocking. The 16GB maximum capacity is the key figure to match against your planned RAM kit. Four DIMM slots are provided for this limit.

Simple drop-in with basic I/O

The board mounts with standard micro-ATX screw holes and ships with a rear I/O shield, one SATA cable and a CMOS battery. Align the shield before seating the board. Connect the 24-pin and 4-pin power headers, then add drives to the six SATA ports.

Highlights

  • Dual-channel DDR3 up to 2133 MHz for responsive memory performance
  • AMD A55 chipset with Socket FM2 supports A10, A8, A6 and A4 processors
  • Realtek ALC887 provides eight-channel audio output
  • Realtek RTL8111E Gigabit LAN controller for wired networking
  • Micro-ATX board with PCIe 2.0 x16, PCIe 2.0 x1 and legacy PCI expansion slots

Specifications

BrandMSI
SeriesMSI FM2-A55M-P33
ModelMSI FM2-A55M-P33
CPU Socket TypeSocket FM2
CPU TypeAMD A10/A8/A6/A4 series processors supporting Socket FM2 architecture
ChipsetAMD A55
Memory StandardSupports dual-channel DDR3 2133 (overclocking)/1866/1600/1333/1066MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCIe 2.0 x16 slot
1 PCIe 2.0 x1 slot
1 PCI slot
SATA RAID6XSATA II interface
Audio ChipsetRealtek ALC887 Chip
- Supports 8-channel sound effects detected by intelligent sound interface
Compatible with Azalia 1.0 specifications
LAN ChipsetRealtek PCI-E GbLAN Controller RTL8111E Chip
Onboard USB6 USB 2.0 ports (backplane)

Questions about this item

How much DDR3 memory can I actually install on this board?

The board supports up to 16GB of dual-channel DDR3 across its memory slots.

What does the PCIe 2.0 x16 slot limit for a graphics card?

The slot runs at PCIe 2.0 speeds, so a modern card will operate at that bandwidth ceiling.

What size case and mounting points does this Micro ATX board need?

It fits any Micro ATX or larger case using standard Micro ATX mounting holes.
