Green Micro ATX motherboard with black FM2 socket and silver heatsinks

MSI

MSI FM2-A85XMA-P33 AMD A85X Socket FM2 16GB DDR3 Micro ATX motherboard

SKU CH-JA62-CGYBA

Micro ATX board for Socket FM2 APUs with AMD A85X chipset, dual-channel DDR3 up to 2133MHz, 16GB maximum memory, one PCIe 2.0 x16 slot, six SATA III ports, Realtek 8-channel audio and gigabit LAN

  • CPU Socket TypeSocket FM2
  • CPU TypeAMD A10/A8/A6/A4 series processors supporting Socket FM2 arc
  • ChipsetAMD A85X
  • Memory StandardSupports dual-channel DDR3 2133 (overclocking)/1866/1600/133
  • Maximum Memory Supported16GB
  • PCI Slots1 PCIe 2.0 x16 slot 1 PCIe 2.0 x1 slot 1 PCI slot
  • Supports AMD A10/A8/A6/A4 processors via Socket FM2
  • Dual-channel DDR3 up to 2133 MHz overclocking for faster memory throughput
  • 16 GB maximum memory capacity enables larger workloads
  • Six SATA III ports provide multiple drive connections
  • Realtek Gigabit LAN delivers 10/100/1000 Mb/s wired networking

Socket FM2 AMD A85X platform

This Micro ATX motherboard uses the AMD A85X chipset and accepts AMD A10, A8, A6 and A4 series processors in a Socket FM2 package. It is aimed at builders assembling a compact desktop that needs basic expansion and legacy peripheral support.

Check CPU socket and memory type before ordering

The board only fits Socket FM2 processors and takes dual-channel DDR3 modules up to 16 GB running at 1066, 1333, 1600, 1866 or 2133 MHz with overclocking. Verify that your existing cooler mounting matches the FM2 layout and that your power supply provides the standard ATX connectors required by this platform.

Six SATA III ports and Realtek Gigabit LAN under

Six SATA III connectors keep multiple drives active during sustained file transfers while the Realtek RTL8111E controller maintains 10, 100 and 1000 Mb/s network throughput. The PCIe 2.0 x16 slot, single PCIe 2.0 x1 slot and one PCI slot stay electrically stable during extended sessions, and the Realtek ALC887 codec continues delivering eight-channel audio without interruption.

Highlights

  • Supports AMD A10/A8/A6/A4 processors via Socket FM2
  • Dual-channel DDR3 up to 2133 MHz overclocking for faster memory throughput
  • 16 GB maximum memory capacity enables larger workloads
  • Six SATA III ports provide multiple drive connections
  • Realtek Gigabit LAN delivers 10/100/1000 Mb/s wired networking

Specifications

BrandMSI
SeriesMSI FM2-A85XMA-P33
ModelMSI FM2-A85XMA-P33
CPU Socket TypeSocket FM2
CPU TypeAMD A10/A8/A6/A4 series processors supporting Socket FM2 architecture
ChipsetAMD A85X
Memory StandardSupports dual-channel DDR3 2133 (overclocking)/1866/1600/1333/1066MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCIe 2.0 x16 slot
1 PCIe 2.0 x1 slot
1 PCI slot
SATA RAID6XSATA III interface
Audio ChipsetRealtek ALC887 Chip
- Supports 8-channel sound effects detected by intelligent sound interface
LAN ChipsetRealtek PCI-E GbLAN Controller RTL8111E Chip
- Supports 10Mb/s, 100Mb/s and 1000Mb/s
Compliant with PCI-Express bus specification v1.0a.
Onboard USB4 USB 2.0 ports (backplane)

Questions about this item

What comes in the box and what must I buy separately?

The package includes the motherboard, a CMOS battery, one SATA cable and the chassis I/O back panel. You will need to supply a Socket FM2 processor, DDR3 memory modules, storage drives and a power supply yourself.

Which DDR3 speeds can I use with the 16 GB limit?

The board supports dual-channel DDR3 at 1066, 1333, 1600, 1866 and 2133 MHz (overclocking). Populate two slots with matching modules up to 8 GB each to reach the 16 GB maximum.

What does the single PCIe 2.0 x16 slot mean for a graphics card?

It provides one full-length slot wired at PCIe 2.0 x16 bandwidth. A modern graphics card will work but will be limited to PCIe 2.0 speeds rather than PCIe 3.0 or newer.
