Green micro-ATX board with LGA 775 socket and four DDR2 slots

MSI

MSI G41TM-E43 LGA 775 Intel G41 DDR2 8GB Micro ATX Motherboard

SKU CH-1B5K-MXEH8

Supports Intel Core 2 Quad and Duo processors on LGA 775 with dual-channel DDR2 up to 8 GB and four SATA ports on a Micro ATX board

  • CPU Socket TypeLGA 775
  • CPU TypeSupports Intel Core 2 Quad/Core 2 Duo based processors in LG
  • ChipsetIntel G41
  • Memory StandardSupports dual-channel DDR2 800/667MHz memory
  • Maximum Memory Supported8GB
  • PCI SlotsSupports PCI Express LAN 10/100/1000 Fast Ethernet by Realte
  • Supports Core 2 Quad and Duo processors on LGA 775 socket
  • Intel G41 chipset enables 1333 MHz front-side bus speed
  • Dual-channel DDR2 memory up to 8 GB at 800 MHz
  • Four SATA II ports provide storage connectivity
  • Realtek 8111DL Gigabit LAN delivers 10/100/1000 network speeds

MSI G41TM-E43 LGA 775 Micro ATX

The MSI G41TM-E43 is a Micro ATX motherboard built around the Intel G41 chipset and the LGA 775 socket. It accepts Intel Core 2 Quad and Core 2 Duo processors, including 45 nm Yorkfield and Wolfdale models, with front-side bus speeds of 1333, 1066 and 800 MHz. Dual-channel DDR2 memory at 800 or 667 MHz is supported up to 8 GB. Onboard features include four SATA II ports, four USB 2.0 ports on the back panel, Gigabit LAN via Realtek 8111DL and Realtek ALC888S/889/885 audio.

Suits legacy LGA 775 repair and basic office builds

This board suits users replacing a failed motherboard in an existing LGA 775 system or assembling a low-cost office PC from spare DDR2 memory and Core 2 processors. It provides essential connectivity with Gigabit Ethernet, four SATA II connectors and integrated audio. Builders who need newer processor sockets, different memory types or additional expansion slots should look at alternative platforms.

Maximum memory capacity is 8 GB DDR2

The single specification that decides fit is the 8 GB maximum memory limit on dual-channel DDR2 800/667 MHz. If the intended workload or operating system requires more than 8 GB of RAM, this motherboard cannot meet that requirement and a different platform must be chosen.

Highlights

  • Supports Core 2 Quad and Duo processors on LGA 775 socket
  • Intel G41 chipset enables 1333 MHz front-side bus speed
  • Dual-channel DDR2 memory up to 8 GB at 800 MHz
  • Four SATA II ports provide storage connectivity
  • Realtek 8111DL Gigabit LAN delivers 10/100/1000 network speeds

Specifications

BrandMSI
SeriesMSI G41TM-E43
ModelMSI G41TM-E43
CPU Socket TypeLGA 775
CPU TypeSupports Intel Core 2 Quad/Core 2 Duo based processors in LGA775 package.
Supports Intel Yorkfield, Wolfdale in the LGA775 package.
Supports Intel next generation 45nm multi-core processors
Supports FSB 1333/1066/800 MHz.
Supports VRD 11.1 standard.
Supports FMB 05a@95W
ChipsetIntel G41
Memory StandardSupports dual-channel DDR2 800/667MHz memory
Maximum Memory Supported8GB
PCI SlotsSupports PCI Express LAN 10/100/1000 Fast Ethernet by Realtek 8111DL
SATA RAID4XSATA II interface
Audio ChipsetChipset integrated by Realtek ALC888S / ALC889 / ALC885
LAN ChipsetSupports PCI Express LAN 10/100/1000 Fast Ethernet by Realtek 8111DL
Onboard USB4 USB 2.0 ports (backplane)

Questions about this item

What comes in the package and what do I need to source separately?

The box holds the board, one CMOS battery, one SATA cable and the rear I/O shield. A LGA 775 CPU, DDR2 800 or 667 memory modules, a power supply and any case or drives must be bought separately.

Should I pick 800 MHz or 667 MHz DDR2 for the 8 GB limit?

Either speed works in dual-channel mode; 800 MHz modules run at their rated frequency while 667 MHz parts run slower but cost less. Both reach the 8 GB ceiling when four slots are filled.

What does the 1000 figure on the LAN port mean once the board is running?

It indicates a gigabit Ethernet connection capable of 1000 Mbps throughput when linked to a matching switch or router via the Realtek 8111DL controller.
