MSI GeForce GTX 1060 graphics card with dual-fan cooler and black metal backplate

MSI

MSI GeForce GTX 1060 6GT OCV1 6GB GDDR5 graphics card

SKU CH-5DHD-GPA3V

A 6 GB GDDR5 graphics card with 1280 CUDA cores, 1544 MHz base and 1759 MHz boost clocks, PCIe 3.0 x16 interface, HDMI 2.0, three DisplayPort 1.4 outputs and DL-DVI-D for multi-monitor and VR-ready

  • InterfacePCI Express 3.0 x16
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce GTX 10 Series
  • GPUGeForce GTX 1060
  • Core Clock1544 MHz
  • Boost Clock1759 MHz
  • 6 GB GDDR5 memory on a 192-bit bus for smooth 1080p gaming
  • Boost clock reaches 1759 MHz for higher frame rates in demanding titles
  • 1280 CUDA cores accelerate compute workloads and modern game engines
  • HDMI 2.0 plus three DisplayPort 1.4 outputs drive up to four displays
  • Dual-fan thermal design with Military Class 4 components keeps temperatures low

MSI GeForce GTX 1060 6GB OCV1

The MSI GeForce GTX 1060 6GT OCV1 is a full-height graphics card built on the NVIDIA GeForce GTX 10 Series architecture. It delivers 1280 CUDA cores with a base clock of 1544 MHz and a boost clock of 1759 MHz. The board carries 6GB of GDDR5 memory across a 192-bit bus running at 8008 MHz effective. It connects through a PCI Express 3.0 x16 slot and supports DirectX 12 and OpenGL 4.5.

1080p gaming and VR-ready builds

This card suits builders targeting 1080p gaming at high settings or entry-level VR experiences backed by NVIDIA VR Ready validation. The three DisplayPort 1.4 outputs, one HDMI 2.0 port and one DL-DVI-D connector drive up to three displays simultaneously. Users chasing 1440p ultra detail or 4K output should look at higher-tier GPUs with more memory bandwidth and compute resources.

PCIe 3.0 slot and 6-pin power check

Verify your motherboard provides a full-length PCI Express 3.0 x16 slot and that your case accommodates a dual-slot, dual-fan cooler. The power supply must deliver a 6-pin PCIe connector and enough headroom for the board's typical draw. Ensure your monitor cables match the available DisplayPort 1.4, HDMI 2.0 or DVI-D ports before ordering.

Highlights

  • 6 GB GDDR5 memory on a 192-bit bus for smooth 1080p gaming
  • Boost clock reaches 1759 MHz for higher frame rates in demanding titles
  • 1280 CUDA cores accelerate compute workloads and modern game engines
  • HDMI 2.0 plus three DisplayPort 1.4 outputs drive up to four displays
  • Dual-fan thermal design with Military Class 4 components keeps temperatures low

Specifications

BrandMSI
ModelGTX 1060 6GT OCV1
InterfacePCI Express 3.0 x16
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce GTX 10 Series
GPUGeForce GTX 1060
Core Clock1544 MHz
Boost Clock1759 MHz
CUDA Cores1280
Effective Memory Clock8008 MHz
Memory Size6GB
Memory Interface192-Bit
Memory TypeGDDR5
DirectXDirectX 12
OpenGLOpenGL 4.5
Multi-Monitor Support3
HDMI1 x HDMI 2.0
DisplayPort3 x DisplayPort 1.4
DVI1 x DL-DVI-D
Virtual Reality ReadyYes
CoolerDouble Fans
Thermal Design Power120W
System RequirementsPower Consumption: 120W Recommended PSU: 400W
Power Connector6-Pin
Dual-Link DVI SupportedYes
HDCP Ready2.2
Form FactorATX
Max GPU Length243 mm
Card Dimensions (L x H)9.57" x 4.53"
Slot Width2 Slots

Questions about this item

Does my motherboard need a PCI Express 3.0 x16 slot for this card?

Yes, the GTX 1060 6GT OCV1 connects through a PCI Express 3.0 x16 interface and requires that slot to operate.

Will my older monitor with a DVI input work with the 1 x DL-DVI-D port?

The card includes a 1 x DL-DVI-D output alongside HDMI 2.0 and DisplayPort 1.4, so a DVI monitor can be used directly.

How can I check the core and boost clocks are running at 1544 MHz and 1759 MHz after installation?

Use the included Afterburner utility to monitor real-time GPU frequencies and confirm the 1544 MHz base and 1759 MHz boost clocks.
