Black dual-fan graphics card with silver backplate and red accents

MSI

MSI GeForce GTX 1060 GAMING X 6G 6GB graphics card

SKU CH-GGAE-EHFHZ

Delivers 6GB GDDR5 on a 192-bit bus with three DisplayPort 1.4, HDMI 2.0 and DL-DVI-D outputs, boost clocks up to 1809 MHz and 1280 CUDA cores for DirectX 12 and VR workloads

  • InterfacePCI Express 3.0 x16
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce GTX 10 Series
  • GPUGeForce GTX 1060
  • Core Clock1594 MHz (OC Mode) 1569 MHz (Gaming Mode) 1506 MHz (Silent M
  • Boost Clock1809 MHz (OC Mode) 1784 MHz (Gaming Mode) 1708 MHz (Silent M
  • 6 GB GDDR5 on a 192-bit bus feeds high-resolution textures
  • Core clock scales from 1506 MHz silent to 1594 MHz OC for flexible performance
  • Boost reaches 1809 MHz in OC mode for extra headroom
  • 1280 CUDA cores handle DirectX 12 and OpenGL 4.5 workloads
  • HDMI 2.0 plus three DisplayPort 1.4 outputs drive up to four monitors at 7680×4320

GTX 1060 GAMING X 6G for 1080p gaming

The MSI GeForce GTX 1060 GAMING X 6G is built for 1080p gaming with 6GB of GDDR5 on a 192-bit bus and 1280 CUDA cores. Three factory profiles — Silent, Gaming and OC — let you choose core clocks from 1506 MHz to 1594 MHz and boost clocks up to 1809 MHz. It plugs into a PCI Express 3.0 x16 slot and supports DirectX 12 and OpenGL 4.5.

Triple DisplayPort plus HDMI 2.0

One dual-link DVI-D, one HDMI 2.0 and three DisplayPort 1.4 outputs drive up to four monitors at a maximum resolution of 7680 x 4320. The ATX form factor fits standard cases and the card is HDCP ready for protected content. Connector placement keeps cabling tidy for multi-display setups or a single high-refresh panel.

Step up from 3GB or older mid-range cards

Moving from a 3GB GTX 1060 or an earlier mid-range GPU adds 3GB more frame buffer and higher memory clocks up to 8108 MHz effective. The extra VRAM helps with texture-heavy titles at 1080p and the three DisplayPort 1.4 ports simplify VR headset hook-up. The jump is worth it when current VRAM limits stutter or when you need four simultaneous displays.

Highlights

  • 6 GB GDDR5 on a 192-bit bus feeds high-resolution textures
  • Core clock scales from 1506 MHz silent to 1594 MHz OC for flexible performance
  • Boost reaches 1809 MHz in OC mode for extra headroom
  • 1280 CUDA cores handle DirectX 12 and OpenGL 4.5 workloads
  • HDMI 2.0 plus three DisplayPort 1.4 outputs drive up to four monitors at 7680×4320

Specifications

BrandMSI
ModelGTX 1060 GAMING X 6G
InterfacePCI Express 3.0 x16
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce GTX 10 Series
GPUGeForce GTX 1060
Core Clock1594 MHz (OC Mode) 1569 MHz (Gaming Mode) 1506 MHz (Silent Mode)
Boost Clock1809 MHz (OC Mode) 1784 MHz (Gaming Mode) 1708 MHz (Silent Mode)
CUDA Cores1280
Effective Memory Clock8108 MHz (OC Mode) 8008 MHz (Gaming Mode) 8008 MHz (Silent Mode)
Memory Size6GB
Memory Interface192-Bit
Memory TypeGDDR5
DirectXDirectX 12
OpenGLOpenGL 4.5
Multi-Monitor Support4
HDMI1 x HDMI 2.0
DisplayPort3 x DisplayPort 1.4
DVI1 x DL-DVI-D
Max Resolution7680 x 4320
Virtual Reality ReadyYes
CoolerDouble Fans
System RequirementsPower Consumption: 120W Recommended PSU: 400W
Power Connector8-Pin
Dual-Link DVI SupportedYes
HDCP Ready2.2
FeaturesThe Ultimate GAMING: TWIN FROZR VI - Smooth heat pipes: Squared shape at bottommaximize heat transfer from the copper base plate - Zero Frozr: Stopping the fan in low-load situations, keeping a noise-free environment - Airflow Control technology: Deflectors thrusts air onto heat pipes for lower temperatures and better gaming TORX FAN 2.0: Supremely silent - Dispersion fan blade: Steeper curved blade accelerating the airflow - Traditional fan blade: Provides steady airflow to massive heatsink below Gaming App - Instant Performance Gain: Unlock extra performance or keep your card silen
Form FactorATX
Max GPU Length277 mm
Card Dimensions (L x H)11.00" x 5.51"
Slot WidthDual Slot
Package ContentsAccessories: Driver CD Installation Guide

Questions about this item

What bandwidth limit does the PCI Express 3.0 x16 interface impose on this GTX 1060?

The PCI Express 3.0 x16 interface provides up to 16 GT/s per lane, giving the GTX 1060 a maximum theoretical bandwidth of roughly 16 GB/s, which is sufficient for the 192-Bit GDDR5 memory subsystem and 1280 CUDA cores at the listed 1809 MHz boost clock.

How many expansion slots and what power connectors does the GAMING X 6G require to fit in an ATX chassis?

The card occupies two full-height expansion slots and draws auxiliary power through a single 8-pin PCIe connector; ensure the case has two adjacent slot openings and the PSU supplies the required 8-pin lead.

What driver step do builders often skip when installing the GeForce GTX 1060 6GB for the first time?

After seating the card and connecting the 8-pin power, many forget to run the NVIDIA clean-install option that removes legacy driver branches before the new GeForce Experience package configures DirectX 12, OpenGL 4.5 and the 7680 x 4320 max resolution across the 1 x HDMI 2.0, 3 x DisplayPort 1.4 and 1 x DL-DVI-D outputs.
