MSI
MSI GTX1660TiVENTUS XSOC graphics card
Refurbished GTX 1660 Ti with 6GB GDDR6, 1536 CUDA cores and 1830 MHz boost clock driving four displays via HDMI 2.0b and three DisplayPort 1.4a outputs
- InterfacePCI Express 3.0 x16
- Chipset ManufacturerNVIDIA
- GPU SeriesNVIDIA GeForce GTX 16 Series
- GPUGeForce GTX 1660 Ti
- ArchitectureTuring
- Boost Clock1830 MHz
- 6 GB GDDR6 memory with 12 Gbps effective clock for smooth 1080p gaming
- Boost clock reaches 1830 MHz for responsive performance in modern titles
- 1536 CUDA cores accelerate parallel workloads and creative applications
- Three DisplayPort 1.4a and one HDMI 2.0b drive up to four displays
- Dual-fan Ventus cooler keeps thermals in check during extended sessions
Compact 6GB Turing GPU
The MSI Ventus GeForce GTX 1660 Ti delivers 1536 CUDA cores and 6GB of GDDR6 memory on a 192-bit bus. It connects through a PCI Express 3.0 x16 slot and reaches a boost clock of 1830 MHz. The card drives up to four displays via one HDMI 2.0b and three DisplayPort 1.4a outputs.
1080p gaming focus, not a 4K or ray-tracing card
This model suits builders who want solid 1080p performance in a compact dual-fan design without auxiliary power cables beyond the slot. It supports DirectX 12 and OpenGL 4.5 for modern titles. Buyers targeting 1440p ultra settings, 4K resolution, or hardware ray tracing should consider a higher-tier GPU.
6GB GDDR6 frame buffer
The 6GB GDDR6 memory capacity and 192-bit interface determine the texture resolution and frame-buffer headroom available at 1080p and 1440p. If your workflow or games regularly exceed 6GB of VRAM usage, this card will become the limiting factor.
Highlights
- 6 GB GDDR6 memory with 12 Gbps effective clock for smooth 1080p gaming
- Boost clock reaches 1830 MHz for responsive performance in modern titles
- 1536 CUDA cores accelerate parallel workloads and creative applications
- Three DisplayPort 1.4a and one HDMI 2.0b drive up to four displays
- Dual-fan Ventus cooler keeps thermals in check during extended sessions
Specifications
| Brand | MSI |
|---|---|
| Series | Ventus |
| Model | GTX 1660 TI VENTUS XS 6G OC |
| Interface | PCI Express 3.0 x16 |
| Chipset Manufacturer | NVIDIA |
| GPU Series | NVIDIA GeForce GTX 16 Series |
| GPU | GeForce GTX 1660 Ti |
| Architecture | Turing |
| Boost Clock | 1830 MHz |
| CUDA Cores | 1536 |
| Effective Memory Clock | 12 Gbps |
| Memory Size | 6GB |
| Memory Interface | 192-Bit |
| Memory Type | GDDR6 |
| DirectX | DirectX 12 |
| OpenGL | OpenGL 4.5 |
| Multi-Monitor Support | 4 |
| HDMI | 1 x HDMI 2.0b |
| DisplayPort | 3 x DisplayPort 1.4a |
| Max Resolution | 7680 x 4320 |
| Virtual Reality Ready | Yes |
| Cooler | Double Fans |
| Thermal Design Power | 120W |
| Recommended PSU Wattage | 450W |
| Power Connector | 8-Pin |
| HDCP Ready | 2.2 |
| Features | TORX Fan 2.0 Dispersion fan blade: Steep curved blade accelerating the airflow. Traditional fan blade: Provides steady airflow to massive heat sink below. Afterburner Overclocking Utility Wireless control through Android/iOS devices. Predator: In-game video recording. Kombustor: DirectX12 benchmark. NVIDIA G-SYNC and HDR Get smooth, tear-free gameplay at refresh rates up to 240 Hz, plus HDR, and more. This is the ultimate gaming display and the go-to equipment for enthusiast gamers. |
| Max GPU Length | 204 mm |
| Card Dimensions (L x H) | 8.03" x 5.04" |
| Slot Width | 2 Slots |
| Shipping weight | 1.05 kg |
| Package size | 325 × 224 × 71 mm |
Questions about this item
How loud and hot does the dual-fan GTX 1660 Ti Ventus XS OC run under sustained load?
The dual-fan Ventus cooler is designed to keep the 1830 MHz boost clock stable during long sessions; fan speed ramps with GPU temperature so noise stays proportional to load.
What motherboard slot and power connector does the PCI Express 3.0 x16 card require?
It needs a full-size PCIe 3.0 x16 slot and a single 8-pin PCIe power cable from the power supply.
Will the HDMI 2.0b and three DisplayPort 1.4a outputs drive my existing 1080p and 1440p monitors at their native refresh rates?
Yes — the HDMI 2.0b and three DisplayPort 1.4a ports support up to 7680 x 4320 resolution, so older 1080p or 1440p panels will run at their maximum refresh rates without adapters.
