Small square motherboard in dark green with silver and black components, rear I/O shield attached

MSI

MSI H110I PRO Intel H110 LGA 1151 DDR4 Mini-ITX motherboard

SKU CH-846F-A3ZFD

Mini-ITX board for LGA 1151 CPUs with DDR4 2133 support up to 32 GB, one PCIe 3.0 x16 slot, four SATA III ports, one M.2 slot, Realtek ALC887 7.1 audio and RTL8111H gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU Type6th generation Intel Core ™ i3/i5/i7, Intel Pentium, Celeron
  • ChipsetIntel H110
  • Memory StandardSupports dual-channel DDR4 2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot
  • Compact Mini-ITX design fits small-form-factor builds
  • LGA 1151 socket supports 6th generation Intel Core i3 i5 i7 Pentium Celeron
  • Dual-channel DDR4 2133 MHz memory up to 32 GB capacity
  • Realtek ALC887 7.1 channel audio delivers high-quality sound
  • Realtek RTL8111H Gigabit LAN provides wired network connectivity

Compact LGA 1151 platform

The MSI H110I PRO is a Mini-ITX motherboard built around the Intel H110 chipset for 6th generation Core i3, i5, i7, Pentium and Celeron processors. It fits small-form-factor chassis while providing the core connectivity needed for a basic desktop or office system.

Steady operation under load

The board uses a straightforward power layout that handles typical desktop workloads without throttle. Dual-channel DDR4 2133 MHz memory support up to 32 GB keeps multitasking smooth during extended sessions, while the single PCIe 3.0 x16 slot runs a discrete graphics card at full electrical width for sustained compute or render tasks.

Practical build and connectivity

A Realtek ALC887 codec delivers 7.1 channel audio through standard analogue jacks, and the Realtek RTL8111H controller provides a single gigabit Ethernet port for wired networking. Four SATA III ports and one M.2 interface give flexible storage options, while the rear I/O offers two USB 3.1 Gen1 and four USB 2.0 ports, with additional headers for front-panel expansion.

Highlights

  • Compact Mini-ITX design fits small-form-factor builds
  • LGA 1151 socket supports 6th generation Intel Core i3 i5 i7 Pentium Celeron
  • Dual-channel DDR4 2133 MHz memory up to 32 GB capacity
  • Realtek ALC887 7.1 channel audio delivers high-quality sound
  • Realtek RTL8111H Gigabit LAN provides wired network connectivity

Specifications

BrandMSI
SeriesMSI H110I PRO
ModelMSI H110I PRO
CPU Socket TypeLGA 1151
CPU Type6th generation Intel Core ™ i3/i5/i7, Intel Pentium, Celeron processors with LGA1151 architecture
ChipsetIntel H110
Memory StandardSupports dual-channel DDR4 2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H gigabit network interface card
Onboard USB- 4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 located on the backplane, 2 provided via onboard USB ports)
- 6 USB 2.0 (High-speed USB) ports (4 on the backplane, 2 via onboard USB ports)

Questions about this item

How much power does the H110I PRO draw when the system runs continuously?

The board itself does not publish a continuous power-draw figure; total consumption depends on the installed 6th-generation Intel Core, Pentium or Celeron processor and the DDR4 2133 MHz modules you choose.

Which components must I already have for the H110I PRO to function?

You need an LGA 1151 processor from the 6th-generation Intel Core, Pentium or Celeron line, DDR4 2133 MHz memory modules up to 32 GB total, a Mini-ITX compatible chassis and power supply, and storage drives for the four SATA III ports or the single M.2 interface.

Will my existing SATA III hard drives and DDR4 2133 MHz memory work with this board?

Yes — the four SATA III connectors and dual-channel DDR4 2133 MHz slots accept standard SATA III drives and DDR4 modules, so older drives and memory of that specification remain usable.
