Green Micro ATX motherboard with black LGA 1151 socket and silver heatsinks

MSI

MSI H110M PRO-D LGA 1151 H110 DDR4 32GB Micro ATX Intel motherboard

SKU CH-XYH3-S86EG

Micro ATX board for LGA 1151 CPUs with DDR4 2133 support up to 32 GB, one PCIe 3.0 x16 slot, two PCIe 2.0 x1 slots, four SATA ports, Realtek ALC887 7.1 audio and RTL8111H gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU Type6th generation Intel Core ™ i3/i5/i7, Intel Pentium, Celeron
  • ChipsetIntel H110
  • Memory StandardSupports dual-channel DDR4 2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 2.0 x1 slots
  • Supports 6th-gen Intel Core i3/i5/i7, Pentium and Celeron CPUs via LGA 1151 socket
  • Dual-channel DDR4 2133MHz memory up to 32GB capacity
  • PCIe 3.0 x16 plus two PCIe 2.0 x1 expansion slots
  • Four SATA III ports for high-speed storage drives
  • Realtek ALC887 7.1-channel audio with gigabit RTL8111H LAN

Socket LGA 1151 Micro ATX board

The MSI H110M PRO-D is a Micro ATX motherboard built around the Intel H110 chipset for LGA 1151 processors. It accepts 6th generation Intel Core i3, i5 and i7 CPUs as well as Pentium and Celeron models. The compact form factor fits smaller chassis while keeping essential desktop connectivity.

Dual-channel DDR4 up to 32 GB

Two memory slots support dual-channel DDR4 at 2133 MHz for a total of 32 GB. Everyday workloads and mainstream applications run comfortably within this limit. Memory-heavy tasks such as large virtual machines or heavy content creation will hit the ceiling.

Realtek audio LAN and USB 3.1 Gen1

Onboard audio uses the Realtek ALC887 codec for 7.1 channel output. A single Realtek RTL8111H controller provides gigabit Ethernet. The rear panel offers two USB 3.1 Gen1 ports and four USB 2.0 ports, with two more USB 3.1 Gen1 and two USB 2.0 headers internally. Expansion includes one PCIe 3.0 x16 slot and two PCIe 2.0 x1 slots alongside four SATA III connectors.

Highlights

  • Supports 6th-gen Intel Core i3/i5/i7, Pentium and Celeron CPUs via LGA 1151 socket
  • Dual-channel DDR4 2133MHz memory up to 32GB capacity
  • PCIe 3.0 x16 plus two PCIe 2.0 x1 expansion slots
  • Four SATA III ports for high-speed storage drives
  • Realtek ALC887 7.1-channel audio with gigabit RTL8111H LAN

Specifications

BrandMSI
SeriesMSI H110M PRO-D
ModelMSI H110M PRO-D
CPU Socket TypeLGA 1151
CPU Type6th generation Intel Core ™ i3/i5/i7, Intel Pentium, Celeron processors with LGA1151 architecture
ChipsetIntel H110
Memory StandardSupports dual-channel DDR4 2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 2.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H gigabit network interface card
Onboard USB- 4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 located on the backplane, 2 provided through the onboard USB port)
- 6 USB 2.0 (High-speed USB) ports (4 on the backplane, 2 via onboard USB ports)

Questions about this item

Will this LGA 1151 board run with the DDR4 2133 MHz modules I already own?

Yes, the board supports dual-channel DDR4 2133 MHz memory up to 32 GB, so your existing modules will work at their rated speed.

How can I confirm the Realtek ALC887 audio is active after the build?

Open Sound settings in Windows, select the Realtek device and play a test tone; you should hear 7.1 channel output from the rear jacks.

What ships in the box and which cables or parts must I source myself?

The package includes the motherboard, a CMOS battery, one SATA cable and the I/O back panel; you will need to provide CPU cooler mounting hardware, additional SATA cables and any case-specific standoffs.
