Green rectangular micro ATX board with silver sockets and black heatsink

MSI

MSI H110M PRO-VD LGA 1151 Intel H110 DDR4 32GB Micro ATX Motherboard

SKU CH-DKRJ-6YBQC

Supports 6th-gen Intel Core i3, i5, i7, Pentium and Celeron CPUs with dual-channel DDR4 up to 32GB

  • CPU Socket TypeLGA 1151
  • CPU Type6th generation Intel Core ™ i3/i5/i7, Intel Pentium, Celeron
  • ChipsetIntel H110
  • Memory StandardSupports dual-channel DDR4 2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 2.0 x1 slots
  • Supports 32GB DDR4 2133MHz dual-channel memory for responsive multitasking
  • Intel H110 chipset with LGA 1151 socket fits 6th gen Core i3 i5 i7 Pentium Celeron CPUs
  • One PCIe 3.0 x16 and two PCIe 2.0 x1 slots give flexible expansion room
  • Realtek ALC887 codec delivers 7.1 channel high definition audio
  • Realtek RTL8111H gigabit LAN plus four USB 3.1 Gen1 and six USB 2.0 ports cover connectivity needs

Socket LGA 1151 Micro-ATX board

This MSI H110M PRO-VD motherboard uses the Intel H110 chipset and fits Micro-ATX cases. It accepts 6th generation Intel Core i3, i5, i7, Pentium and Celeron processors in an LGA 1151 socket. The board supports dual-channel DDR4 2133MHz memory up to 32GB total capacity.

Check CPU cooler clearance and power connectors

Verify that your chosen LGA 1151 processor matches the supported 6th generation Intel lineup before ordering. Confirm your chassis can accommodate a Micro-ATX form factor and that the power supply provides the necessary CPU and 24-pin ATX connectors. Ensure you have DDR4 modules rated for 2133MHz operation.

Steel-reinforced PCIe slot and full I/O shield

The single PCIe 3.0 x16 slot features steel reinforcement for heavier graphics cards. Two PCIe 2.0 x1 slots handle additional expansion cards. Rear I/O includes 2 USB 3.1 Gen1 ports, 4 USB 2.0 ports, gigabit LAN via Realtek RTL8111H and 7.1 channel audio from the Realtek ALC887 codec. Four SATA III headers support storage arrays.

Highlights

  • Supports 32GB DDR4 2133MHz dual-channel memory for responsive multitasking
  • Intel H110 chipset with LGA 1151 socket fits 6th gen Core i3 i5 i7 Pentium Celeron CPUs
  • One PCIe 3.0 x16 and two PCIe 2.0 x1 slots give flexible expansion room
  • Realtek ALC887 codec delivers 7.1 channel high definition audio
  • Realtek RTL8111H gigabit LAN plus four USB 3.1 Gen1 and six USB 2.0 ports cover connectivity needs

Specifications

BrandMSI
SeriesMSI H110M PRO-VD
ModelMSI H110M PRO-VD
CPU Socket TypeLGA 1151
CPU Type6th generation Intel Core ™ i3/i5/i7, Intel Pentium, Celeron processors with LGA1151 architecture
ChipsetIntel H110
Memory StandardSupports dual-channel DDR4 2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 2.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H gigabit network interface card
Onboard USB- 4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 on the back panel, 2 via onboard USB ports)
- 6 USB 2.0 (High-speed USB) ports (4 on the backplane, 2 via onboard USB ports)

Questions about this item

What accessories come in the box and what must I buy separately?

The box contains the motherboard, a CMOS battery, one SATA cable and the chassis I/O back panel. You must supply a LGA 1151 processor, DDR4 2133MHz memory modules, storage drives, a power supply and a case.

How do I decide between the memory capacity options for this board?

The board supports up to 32 GB across two DDR4 2133MHz slots. Choose 16 GB for typical office or light gaming builds, or 32 GB if you run virtual machines or heavy multitasking workloads.

What does the 7.1 channel audio spec mean when the system is running?

The Realtek ALC887 codec delivers eight-channel surround sound through the rear panel jacks, so games and media can use full 7.1 speaker sets or headphone virtualisation without an add-in sound card.
