Green Micro ATX motherboard with black LGA 1151 socket and silver heatsinks

MSI

MSI H110M PRO-VHL Intel H110 LGA 1151 DDR4 Micro ATX Motherboard

SKU CH-AKMB-P87Z2

Micro ATX board with LGA 1151 socket, Intel H110 chipset, dual-channel DDR4 2133MHz support up to 32GB, PCIe 3.0 x16 and x1 plus PCI slots, four SATA III ports, Realtek ALC887 7.1 audio.

  • CPU Socket TypeLGA 1151
  • CPU Type6th generation Intel Core ™ i3/i5/i7, Intel Pentium, Celeron
  • ChipsetIntel H110
  • Memory StandardSupports dual-channel DDR4 2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 x PCIe 3.0 x16 slot 1 x PCIe 3.0 x1 slot 1 x PCI slot
  • Supports 6th generation Intel Core i3 i5 i7 Pentium Celeron processors via LGA 1151 socket
  • Dual-channel DDR4 2133MHz memory up to 32GB capacity for responsive multitasking
  • PCIe 3.0 x16 slot plus PCIe 3.0 x1 and legacy PCI expansion options
  • Realtek ALC887 7.1 channel audio with Realtek RTL8111H gigabit LAN for clear sound and fast networking
  • Four USB 3.1 Gen1 and six USB 2.0 ports provide ample connectivity for peripherals

Socket and chipset

This MSI board uses the LGA 1151 socket with the Intel H110 chipset. It accepts 6th generation Core i3, i5 and i7 processors as well as Pentium and Celeron CPUs. The Micro ATX form factor fits compact chassis.

Memory and expansion

Dual-channel DDR4 2133MHz memory is supported up to 32GB. Expansion includes one PCIe 3.0 x16 slot, one PCIe 3.0 x1 slot and one legacy PCI slot. Four SATA III ports handle storage drives.

Onboard connectivity

Audio uses the Realtek ALC887 codec for 7.1 channel output. Networking relies on a Realtek RTL8111H gigabit LAN controller. USB provides four 3.1 Gen1 ports and six 2.0 ports split between rear panel and internal headers.

Highlights

  • Supports 6th generation Intel Core i3 i5 i7 Pentium Celeron processors via LGA 1151 socket
  • Dual-channel DDR4 2133MHz memory up to 32GB capacity for responsive multitasking
  • PCIe 3.0 x16 slot plus PCIe 3.0 x1 and legacy PCI expansion options
  • Realtek ALC887 7.1 channel audio with Realtek RTL8111H gigabit LAN for clear sound and fast networking
  • Four USB 3.1 Gen1 and six USB 2.0 ports provide ample connectivity for peripherals

Specifications

BrandMSI
SeriesMSI H110M PRO-VHL
ModelMSI H110M PRO-VHL
CPU Socket TypeLGA 1151
CPU Type6th generation Intel Core ™ i3/i5/i7, Intel Pentium, Celeron processors with LGA1151 architecture
ChipsetIntel H110
Memory StandardSupports dual-channel DDR4 2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 x PCIe 3.0 x16 slot
1 x PCIe 3.0 x1 slot
1 x PCI slot
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H gigabit network interface card
Onboard USB- 4 USB 3.1 Gen1 (SuperSpeed USB) interfaces (2 located on the backplane, 2 provided through the onboard USB interface)
- 6 USB 2.0 (High-speed USB) ports (4 on the backplane, 2 via onboard USB ports)

Questions about this item

How can I confirm the motherboard is functioning after installing a 6th generation Intel Core i5 and DDR4 2133MHz memory?

Power on the system and verify the POST screen appears; check that the Realtek ALC887 audio device and Realtek RTL8111H gigabit LAN adapter are detected in the operating system device manager.

What accessories are included in the box and what must be sourced separately for a build?

The package contains the motherboard, a CMOS battery, one SATA cable and the chassis I/O back panel; CPU, DDR4 memory modules, storage drives, power supply and case are not included.

Which memory capacity should I choose given the board's specifications?

The board supports dual-channel DDR4 2133MHz up to a maximum of 32GB; populate two slots with matching 16GB modules to reach the limit.
