Green Mini-ITX motherboard with black LGA 1151 socket and silver I/O shield

MSI

MSI H310I PRO Intel H310 LGA 1151 DDR4 Mini-ITX Motherboard

SKU CH-BE3A-T0ZXA

Mini-ITX board for 8th Gen Intel Core, Pentium Gold and Celeron CPUs with dual-channel DDR4 up to 32 GB, one PCIe 3.0 x16 slot, four SATA III ports, one M.2 interface.

  • CPU Socket TypeLGA 1151
  • CPU Type8th Gen Intel Core ™ processors with LGA1151 support, Pentiu
  • ChipsetIntel H310
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot
  • Supports 8th Gen Intel Core, Pentium Gold and Celeron CPUs via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32GB at 2666/2400/2133MHz
  • One PCIe 3.0 x16 slot plus one M.2 and four SATA connections
  • Realtek ALC887 codec delivers 7.1 channel audio
  • Realtek RTL8111H provides Gigabit LAN with four USB 3.1 Gen1 and five USB 2.0 ports

Compact LGA 1151 foundation

The MSI H310I PRO is a Mini-ITX motherboard built around the Intel H310 chipset for 8th generation Intel Core, Pentium Gold and Celeron processors using the LGA 1151 socket. Its small footprint suits compact system builds where space is limited. The board delivers essential connectivity for a basic desktop platform.

Dual-channel DDR4 ceiling

Memory support tops out at 32 GB across two slots running at 2666, 2400 or 2133 MHz. A single PCIe 3.0 x16 slot provides the only high-speed expansion path for a graphics card or other add-in board. Storage connects through one M.2 interface and four SATA III ports, while networking relies on a Realtek RTL8111H Gigabit LAN controller.

32 GB memory limit

The maximum supported capacity of 32 GB is the decisive figure when choosing this board; systems needing more RAM must look elsewhere. Audio is handled by a Realtek ALC887 codec delivering 7.1 channel output. Rear I/O includes two USB 3.1 Gen1 Type-A ports and three USB 2.0 ports, with additional headers for two more USB 3.1 Gen1 and two USB 2.0 connections internally.

Highlights

  • Supports 8th Gen Intel Core, Pentium Gold and Celeron CPUs via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32GB at 2666/2400/2133MHz
  • One PCIe 3.0 x16 slot plus one M.2 and four SATA connections
  • Realtek ALC887 codec delivers 7.1 channel audio
  • Realtek RTL8111H provides Gigabit LAN with four USB 3.1 Gen1 and five USB 2.0 ports

Specifications

BrandMSI
SeriesMSI H310I PRO
ModelMSI H310I PRO
CPU Socket TypeLGA 1151
CPU Type8th Gen Intel Core ™ processors with LGA1151 support, Pentium Gold and Celeron processors
ChipsetIntel H310
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H Gigabit network interface card
Onboard USB4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the backplane, 2 via onboard USB ports)
5 USB 2.0 (High-speed USB) ports (3 on the backplane, 2 via onboard USB ports)

Questions about this item

Should I pick a 16 GB or 32 GB DDR4 kit for this board?

The board supports up to 32 GB across two slots, so a 32 GB kit uses the full capacity while a 16 GB kit leaves room for a later upgrade.

What does the 2666 MHz DDR4 rating mean once the board is running?

With 8th Gen Intel Core processors the memory controller tops out at 2666 MHz, so modules rated at that speed will run at their rated frequency without manual tuning.

What does the single PCIe 3.0 x16 slot limit for expansion cards?

The slot provides one full-length PCIe 3.0 x16 connection, so only one graphics card or other x16 device can be installed at a time.
