Green rectangular Intel motherboard with silver PCIe slots and black memory sockets

MSI

MSI H310M PRO-V PLUS DDR4 Intel motherboard

SKU CH-SGD7-J73J4

Supports LGA1151 8th/9th gen Intel CPUs with DDR4 up to 2666 MHz, PCIe steel armor, Audio Boost and EZ Debug LED

  • CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
  • Supports 8th and 9th generation Intel Core processors via LGA1151 socket
  • DDR4 memory up to 2666 MHz across two slots for 32 GB total
  • Realtek ALC887 codec delivers 7.1 channel audio with Audio Boost
  • PCIe 3.0 x16 slot reinforced with steel armor for graphics card stability
  • RTL8111H Gigabit LAN provides wired network connectivity

Socket LGA1151 Intel H310 motherboard

This MSI board pairs 8th and 9th generation Intel Core, Pentium and Celeron processors with the Intel H310 chipset in a compact micro-ATX layout. Two DDR4 slots accept up to 32 GB of memory at 2666 MHz in dual-channel mode. A single PCIe 3.0 x16 slot and two PCIe 2.0 x1 slots handle graphics and add-in cards.

Entry builders and office upgrades

It suits builders assembling a basic desktop for general productivity, home office tasks or light gaming with a discrete graphics card. The simple debugging LEDs help first-time assemblers identify boot issues quickly. Buyers who need four memory slots, multiple PCIe x16 slots or integrated Wi-Fi should consider a different board.

One PCIe 3.0 x16 slot

The single full-length PCIe 3.0 x16 slot is the specification that determines whether a graphics card or other expansion card can be installed. Four SATA 6Gb/s ports provide storage connectivity while two USB 3.1 Gen1 and six USB 2.0 ports cover peripheral needs. Realtek ALC887 7.1-channel audio and a Gigabit LAN port complete the I/O.

Highlights

  • Supports 8th and 9th generation Intel Core processors via LGA1151 socket
  • DDR4 memory up to 2666 MHz across two slots for 32 GB total
  • Realtek ALC887 codec delivers 7.1 channel audio with Audio Boost
  • PCIe 3.0 x16 slot reinforced with steel armor for graphics card stability
  • RTL8111H Gigabit LAN provides wired network connectivity

Specifications

CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)

Questions about this item

What case standoffs and power connectors does the MSI H310M PRO-V PLUS DDR4 motherboard require?

The board uses a micro-ATX layout with a 24-pin ATX main power connector and an 8-pin ATX 12V connector.

How do I install a CPU in the LGA1151 socket without bending pins?

Lift the socket lever, align the processor triangle with the socket corner, place it gently without force, then lower the lever to lock it.

Which memory speeds can I use if I fill both DDR4 slots?

The board supports DDR4 at 2666, 2400 and 2133 MHz in dual-channel mode up to 32 GB total.
