Green Micro ATX board with silver CPU socket and black slots

MSI

MSI H310M PRO-VD LGA 1151 Intel H310 DDR4 32GB Micro ATX motherboard

SKU CH-ZBPG-Z0348

Supports 8th Gen Intel Core, Pentium Gold and Celeron CPUs on LGA 1151 with dual-channel DDR4 up to 32GB, one PCIe 3.0 x16 slot, two PCIe 2.0 x1 slots, four SATA ports.

  • CPU Socket TypeLGA 1151
  • CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as wel
  • ChipsetIntel H310
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 2.0 x1 slots
  • Supports 8th Gen Intel Core CPUs via LGA 1151 socket
  • Up to 32GB dual-channel DDR4 at 2666MHz
  • 1 PCIe 3.0 x16 and 2 PCIe 2.0 x1 expansion slots
  • Four SATA III ports for storage drives
  • 1-channel Realtek ALC887 audio with RTL8111H Gigabit LAN

Micro ATX Intel H310 foundation

This motherboard uses the Intel H310 chipset on a Micro ATX PCB and fits LGA 1151 processors from Intel 8th Gen Core, Pentium Gold and Celeron lines. It targets budget office builds, basic home PCs and simple upgrade projects where a compact board is required. The layout keeps the essential I/O and expansion while leaving room in smaller cases.

Dual-channel DDR4 up to 32 GB

Two DDR4 slots accept 2666, 2400 or 2133 MHz modules for a maximum of 32 GB in dual-channel mode. A single PCIe 3.0 x16 slot handles a graphics card or other x16 device, while two PCIe 2.0 x1 slots add extra cards such as Wi-Fi or sound. Four SATA III ports connect drives and the board supplies four USB 3.1 Gen1 and six USB 2.0 ports across rear and internal headers.

Realtek ALC887 audio with RTL8111H LAN

The Realtek ALC887 codec delivers 7.1 channel output for everyday multimedia and conferencing. The RTL8111H Gigabit controller provides wired networking without extra hardware. Under sustained load the H310 chipset and modest VRM area run warm but stay within design limits for typical office workloads; airflow from a standard case fan is sufficient for continuous operation.

Highlights

  • Supports 8th Gen Intel Core CPUs via LGA 1151 socket
  • Up to 32GB dual-channel DDR4 at 2666MHz
  • 1 PCIe 3.0 x16 and 2 PCIe 2.0 x1 expansion slots
  • Four SATA III ports for storage drives
  • 1-channel Realtek ALC887 audio with RTL8111H Gigabit LAN

Specifications

BrandMSI
SeriesMSI H310M PRO-VD
ModelMSI H310M PRO-VD
CPU Socket TypeLGA 1151
CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as well as Intel Pentium Gold and Celeron processors
ChipsetIntel H310
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 2.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 RTL8111H Gigabit network interface card
Onboard USB4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the backplane, 2 via onboard USB ports)
6 USB 2.0 (High-speed USB) ports (4 ports on the backplane, 2 via onboard USB ports)

Questions about this item

Will the 32 GB DDR4 2666 MHz memory limit appear before the CPU hits its thermal ceiling under sustained load?

The board caps system memory at 32 GB of DDR4 running up to 2666 MHz, so total capacity and speed are fixed regardless of how long the processor runs.

What fan headers and power phases does the MSI H310M PRO-VD expose for all-day cooling and VRM stability?

The board provides standard CPU and system fan headers plus a 4+2 phase power design that feeds the LGA 1151 socket, keeping VRM temperatures manageable during continuous operation.

Which DDR4 kit, LGA 1151 cooler and ATX power supply must I already own for this Micro ATX board to post?

You need DDR4 modules up to 2666 MHz, an LGA 1151 compatible CPU cooler, and an ATX power supply with 24-pin plus 4-pin CPU connectors to power the H310 chipset and 8th Gen Intel Core processor.
