Green Micro ATX motherboard with silver LGA 1151 socket and black DDR4 slots

MSI

MSI H310M PRO-VDH PLUS Intel Motherboard LGA 1151 DDR4 32GB Micro ATX

SKU CH-6EFR-VR3FB

Micro-ATX board with LGA 1151 socket, dual-channel DDR4 up to 32 GB, one PCIe 3.0 x16 and two PCIe 2.0 x1 slots, four SATA III ports, Realtek ALC887 7.1 audio, Gigabit LAN.

  • CPU Socket TypeLGA 1151
  • CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as wel
  • ChipsetIntel H310
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 2.0 x1 slots
  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32GB at 2666 MHz
  • Four SATA III ports for high-speed storage connectivity
  • Realtek ALC887 codec delivers 7.1 channel audio
  • RTL8111H Gigabit LAN provides wired network access

H310 Chipset for LGA 1151 Builds

This Micro ATX motherboard pairs the Intel H310 chipset with an LGA 1151 socket for 8th Generation Intel Core, Pentium Gold and Celeron processors. It fits compact chassis while providing the core connectivity needed for everyday desktop systems. The board delivers a practical foundation for office workstations or home PCs.

Dual-Channel DDR4 Up to 32 GB

Two DDR4 slots accept memory modules running at 2666, 2400 or 2133 MHz in dual-channel mode for a maximum of 32 GB. Sustained workloads benefit from the stable memory bandwidth rather than brief burst speeds. The four SATA III ports maintain consistent throughput for storage arrays during long copy or backup sessions.

PCIe 3.0 x16 and Legacy Expansion

A single PCIe 3.0 x16 slot handles modern graphics cards at the interface's standard lane width and signalling rate. Two PCIe 2.0 x1 slots remain available for additional controllers or legacy add-in cards. Six USB 2.0 and four USB 3.1 Gen1 ports supply peripheral bandwidth within the limits of those respective specifications.

Highlights

  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32GB at 2666 MHz
  • Four SATA III ports for high-speed storage connectivity
  • Realtek ALC887 codec delivers 7.1 channel audio
  • RTL8111H Gigabit LAN provides wired network access

Specifications

BrandMSI
SeriesMSI H310M PRO-VDH PLUS
ModelMSI H310M PRO-VDH PLUS
CPU Socket TypeLGA 1151
CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as well as Pentium Gold and Celeron processors
ChipsetIntel H310
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 2.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 RTL8111H Gigabit LAN network interface card
Onboard USB4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the backplane, 2 via onboard USB ports)
6 USB 2.0 (High-speed USB) ports (4 ports on the backplane, 2 via onboard USB ports)

Questions about this item

How hot or loud does the H310M PRO-VDH PLUS get when running all day?

The board uses an Intel H310 chipset and supports 8th Gen Core processors with a 32 GB DDR4 limit, so typical office workloads stay cool and quiet with a basic CPU cooler.

What parts must I already own for this LGA 1151 board to boot?

You need an LGA 1151 8th Gen Intel Core, Pentium Gold or Celeron CPU, DDR4 memory up to 2666 MHz, a SATA drive, and an ATX power supply with 24-pin and 4-pin CPU connectors.

Will my older SATA drives and PCIe x1 cards work alongside this H310 board?

Yes, the board provides four SATA III ports and two PCIe 2.0 x1 slots, so existing SATA SSDs, hard drives and legacy expansion cards remain usable.
