Green micro-ATX board with black LGA 1151 socket, four DDR4 slots, silver PCIe x16 slot and rear I/O shield

MSI

MSI H310M PRO-VL Intel H310 LGA 1151 DDR4 Micro ATX motherboard

SKU CH-AVZR-RCJ2H

A Micro ATX board for 8th Gen Intel Core, Pentium Gold and Celeron CPUs with dual-channel DDR4 up to 32GB and one PCIe 3.0 x16 slot

  • CPU Socket TypeLGA 1151
  • CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as wel
  • ChipsetIntel H310
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 2.0 x1 slots
  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • One PCIe 3.0 x16 slot plus two PCIe 2.0 x1 slots for expansion
  • Four SATA III ports for fast storage connectivity
  • Realtek ALC887 7.1 channel audio with Gigabit LAN

Socket and chipset

This MSI H310M PRO-VL motherboard uses the Intel H310 chipset and an LGA 1151 socket. It supports 8th Generation Intel Core processors along with Pentium Gold and Celeron CPUs. The Micro ATX form factor fits a wide range of chassis.

Memory capacity and speed

Dual-channel DDR4 memory runs at 2666, 2400 or 2133 MHz with a maximum capacity of 32 GB. Builders who need more than 32 GB or faster memory standards should consider a different platform.

Primary expansion slot

A single PCIe 3.0 x16 slot provides the main graphics or add-in card connection. Two PCIe 2.0 x1 slots are available for additional expansion cards. Systems requiring multiple x16 slots or newer PCIe generations will need another board.

Highlights

  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • One PCIe 3.0 x16 slot plus two PCIe 2.0 x1 slots for expansion
  • Four SATA III ports for fast storage connectivity
  • Realtek ALC887 7.1 channel audio with Gigabit LAN

Specifications

BrandMSI
SeriesMSI H310M PRO-VL
ModelMSI H310M PRO-VL
CPU Socket TypeLGA 1151
CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as well as Pentium Gold and Celeron processors
ChipsetIntel H310
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 2.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 x Realtek RTL8111H Gigabit network interface card
Onboard USB4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the backplane, 2 via onboard USB ports)
6 USB 2.0 (High-speed USB) ports (4 Type-A ports on the backplane, 2 via onboard USB ports)

Questions about this item

How do I install the CPU into the LGA 1151 socket without bending pins?

Lift the retention lever, align the processor notches with the socket keys, place the chip gently without force, lower the frame, and lock the lever back down; the socket has no pins to bend, so the only risk is seating the CPU crooked.

When will the onboard Realtek ALC887 audio or RTL8111H LAN need a driver update?

Update the audio and network drivers after the OS install and whenever Windows Update or the MSI support page releases a newer WHQL package; the hardware itself does not wear out.

At what memory speed does the dual-channel DDR4 controller stop scaling under heavy load?

The board officially supports DDR4 up to 2666 MHz; running modules rated higher will default to 2666 MHz, so that ceiling is the first limit you hit during sustained memory-intensive work.
