Green Micro ATX motherboard with silver heatsinks and black slots

MSI

MSI H310M WATER LGA 1151 Micro ATX Motherboard

SKU CH-41PF-F3CW4

Supports 8th Generation Intel Core, Pentium Gold and Celeron LGA 1151 CPUs with dual-channel DDR4 up to 32GB, one PCIe 3.0 x16 slot, two PCIe 2.0 x1 slots, four SATA III ports.

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 8th Generation Intel Core™ Processors, Pentium Gold
  • ChipsetIntel H310
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 x PCIe 3.0 x16 slot 2 x PCIe 2.0 x1 slots
  • Supports 8th Gen Intel Core and Pentium Gold CPUs via LGA 1151 socket
  • Dual-channel DDR4 up to 2666 MHz with 32 GB maximum capacity
  • PCIe 3.0 x16 plus two PCIe 2.0 x1 slots for graphics and add-in cards
  • Four SATA III ports and six USB 2.0 plus four USB 3.1 Gen1 connections
  • Realtek ALC887 7.1-channel audio with RTL8111H Gigabit LAN

Intel H310 Micro ATX Motherboard

This LGA 1151 board targets builders who need a compact foundation for 8th Generation Intel Core, Pentium Gold and Celeron processors. The H310 chipset delivers essential platform features in a Micro ATX form factor suitable for smaller chassis and straightforward upgrades.

32GB DDR4 Dual-Channel Support

Four memory slots accept dual-channel DDR4 at 2666, 2400 or 2133 MHz up to a total of 32 GB, letting the system handle everyday multitasking and light content work without bottlenecks. The bundle adds a CMOS battery, one SATA cable and an I/O back panel so the board is ready for immediate installation.

Realtek ALC887 7.1 Audio and Gigabit LAN

Onboard audio uses the Realtek ALC887 codec for 7.1-channel output while a single RTL8111H controller provides wired Gigabit networking. Expansion includes one PCIe 3.0 x16 slot and two PCIe 2.0 x1 slots alongside four SATA III ports, four rear USB 3.1 Gen1 Type-A ports, two internal USB 3.1 Gen1 headers, four rear USB 2.0 ports and two internal USB 2.0 headers for front-panel connectivity.

Highlights

  • Supports 8th Gen Intel Core and Pentium Gold CPUs via LGA 1151 socket
  • Dual-channel DDR4 up to 2666 MHz with 32 GB maximum capacity
  • PCIe 3.0 x16 plus two PCIe 2.0 x1 slots for graphics and add-in cards
  • Four SATA III ports and six USB 2.0 plus four USB 3.1 Gen1 connections
  • Realtek ALC887 7.1-channel audio with RTL8111H Gigabit LAN

Specifications

BrandMSI
SeriesMSI H310M WATER
ModelMSI H310M WATER
CPU Socket TypeLGA 1151
CPU TypeSupports 8th Generation Intel Core™ Processors, Pentium Gold and Celeron Processors for Socket LGA1151
ChipsetIntel H310
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 x PCIe 3.0 x16 slot
2 x PCIe 2.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 Codec
7.1-Channel High Definition Audio
LAN Chipset1 x RTL8111H Gigabit LAN controller
Onboard USB4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)

Questions about this item

What maintenance or replacement will the board need later?

The package includes a CMOS battery; replace it when the system clock starts losing time.

What limit appears first under sustained use?

Memory capacity tops out at 32 GB across the two DDR4 slots.

How much noise, heat or power does it produce running all day?

Passive chipset cooling and no onboard fan mean silent operation; total power draw depends on the installed CPU and peripherals.
