Green micro ATX board with silver LGA 1200 socket and black DDR4 slots

MSI

MSI H410M-A PRO LGA 1200 Intel motherboard

SKU CH-HB5W-B6RZM

Micro-ATX board for LGA 1200 CPUs with dual-channel DDR4 up to 64 GB, one PCIe 3.0 x16 slot, four SATA III ports and Intel Gigabit LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core and Pentium Gold / Celeron proc
  • ChipsetIntel H410
  • Memory StandardSupport dual-channel DDR4 2133/2200/2400/2666/2800/2933MHz m
  • Maximum Memory Supported64GB
  • PCI Slots1x PCIe 3.0 x16 slot (From CPU) 1x PCIe 3.0 x1 slot (From PC
  • Supports 10th Gen Intel Core processors on LGA 1200 socket
  • Dual-channel DDR4 memory up to 64GB at 2933MHz
  • Intel I219V Gigabit LAN for wired network connectivity
  • Realtek ALC892/897 codec delivers 7.1-channel high-definition audio
  • Micro-ATX form factor measuring 23.6 x 20.0 cm

Socket LGA 1200 Micro ATX board

This MSI H410M-A PRO motherboard accepts 10th Gen Intel Core and Pentium Gold or Celeron processors in an LGA 1200 socket. It uses the Intel H410 chipset on a Micro ATX form factor. The board targets basic desktop builds and office upgrades.

Sustained load behaviour

Dual-channel DDR4 runs at 2133, 2200, 2400, 2666, 2800 or 2933 MHz up to 64 GB. One PCIe 3.0 x16 slot connects to the CPU and one PCIe 3.0 x1 slot connects to the PCH. An M.2 E-key slot accepts a WiFi module only. Four SATA III ports provide storage connectivity.

Deciding specification

The LGA 1200 socket and H410 chipset limit the board to 10th Gen Intel processors. If the build requires a newer CPU generation or a different socket, this motherboard will not fit. Compatibility with the intended processor is the single factor that decides suitability.

Highlights

  • Supports 10th Gen Intel Core processors on LGA 1200 socket
  • Dual-channel DDR4 memory up to 64GB at 2933MHz
  • Intel I219V Gigabit LAN for wired network connectivity
  • Realtek ALC892/897 codec delivers 7.1-channel high-definition audio
  • Micro-ATX form factor measuring 23.6 x 20.0 cm

Specifications

BrandMSI
SeriesMSI H410M-A PRO
ModelMSI H410M-A PRO
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core and Pentium Gold / Celeron processors for LGA 1200 socket
ChipsetIntel H410
Memory StandardSupport dual-channel DDR4 2133/2200/2400/2666/2800/2933MHz memory
Maximum Memory Supported64GB
PCI Slots1x PCIe 3.0 x16 slot (From CPU)
1x PCIe 3.0 x1 slot (From PCH)
1x M.2 slot with E key for WiFi module only
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtekALC892/ALC897 Codec
7.1-Channel High Definition Audio
LAN Chipset1x Intel I219V Gigabit LAN controller
Onboard USBIntel H410 Chipset
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB 3.2 Gen 1 5Gbps connector)
6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector)

Questions about this item

How much power does the Intel I219V Gigabit LAN controller draw under continuous load on this H410 board?

The Intel I219V Gigabit LAN controller is a low-power integrated PHY that typically consumes well under one watt, so it adds negligible heat to the H410 platform during all-day operation.

Which DDR4 speeds up to 2933 MHz does the board officially support for a 10th Gen Intel Core i3?

The board supports dual-channel DDR4 at 2133, 2200, 2400, 2666, 2800 and 2933 MHz, so any kit rated at those speeds will run at its rated frequency with a 10th Gen Core i3.

Will a PCIe 3.0 x16 graphics card from an older build work in the single x16 slot without bandwidth loss?

The single PCIe 3.0 x16 slot connects directly to the CPU, so an older PCIe 3.0 graphics card will run at full x16 bandwidth on this H410 board.
