Green Micro ATX motherboard with silver heatsinks and black slots

MSI

MSI H410M PRO-VH LGA 1200 Intel H410 Micro ATX Motherboard

SKU CH-8WKJ-5P4W4

Micro ATX motherboard for LGA 1200 Intel 10th Gen CPUs with H410 chipset, dual-channel DDR4 up to 64 GB, PCIe 3.0 x16 and x1 slots, four SATA III ports, Intel I219V Gigabit LAN.

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core and Pentium Gold / Celeron proc
  • ChipsetIntel H410
  • Memory StandardSupport dual-channel DDR4 2133/2200/2400/2666/2800/2933MHz m
  • Maximum Memory Supported64GB
  • PCI Slots1x PCIe 3.0 x16 slot (From CPU) 1x PCIe 3.0 x1 slot (From PC
  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64 GB at 2933 MHz
  • PCIe 3.0 x16 slot plus x1 slot for expansion cards
  • Realtek ALC892/897 codec delivers 7.1-channel high-definition audio
  • Intel I219V Gigabit LAN plus four USB 3.2 Gen 1 5 Gbps ports

Socket LGA 1200 H410 micro-ATX board

This MSI H410M PRO-VH motherboard uses the Intel H410 chipset and an LGA 1200 socket for 10th Gen Intel Core, Pentium Gold and Celeron processors. It fits a micro-ATX chassis and supports dual-channel DDR4 memory up to 64 GB across speeds from 2133 to 2933 MHz. One PCIe 3.0 x16 slot and one PCIe 3.0 x1 slot handle expansion cards.

Entry office builds not multi-GPU or heavy storage

The board suits basic office or home PCs that need a single graphics card and SATA storage. Builders wanting multiple PCIe x16 slots, more than four SATA ports or CPU overclocking should choose a B-series or Z-series platform instead.

One PCIe 3.0 x16 slot from the CPU

A single PCIe 3.0 x16 slot wired to the processor is the only full-length expansion lane available. If the build requires a second x16 slot or additional high-speed lanes, this board will not meet the requirement.

Highlights

  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64 GB at 2933 MHz
  • PCIe 3.0 x16 slot plus x1 slot for expansion cards
  • Realtek ALC892/897 codec delivers 7.1-channel high-definition audio
  • Intel I219V Gigabit LAN plus four USB 3.2 Gen 1 5 Gbps ports

Specifications

BrandMSI
SeriesMSI H410M PRO-VH
ModelMSI H410M PRO-VH
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core and Pentium Gold / Celeron processors for LGA 1200 socket
ChipsetIntel H410
Memory StandardSupport dual-channel DDR4 2133/2200/2400/2666/2800/2933MHz memory
Maximum Memory Supported64GB
PCI Slots1x PCIe 3.0 x16 slot (From CPU)
1x PCIe 3.0 x1 slot (From PCH)
1x M.2 slot with E key for WiFi module only
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek Realtek ALC892/ALC897 Codec
7.1-Channel High Definition Audio
LAN Chipset1x Intel I219V Gigabit LAN controller
Onboard USBIntel H410 Chipset
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB 3.2 Gen 1 5Gbps connector)
6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector)

Questions about this item

Which memory capacity and speed should I select for this board?

The board supports dual-channel DDR4 up to 64GB total, with speeds of 2133, 2200, 2400, 2666, 2800 or 2933MHz. Install matched pairs in the two slots for best performance.

What does the 1x PCIe 3.0 x16 slot from the CPU deliver in a built system?

It provides a full x16 electrical link directly from a 10th Gen Intel Core or Pentium Gold / Celeron processor, so a discrete graphics card runs at the CPU's native PCIe 3.0 bandwidth.

How does the Intel H410 chipset limit the USB 3.2 Gen 1 ports in practice?

The chipset supplies four USB 3.2 Gen 1 5Gbps ports — two on the rear panel and two via an internal header — and six USB 2.0 ports, with no faster USB 3.2 Gen 2 or Type-C connections available.
