Green Mini-ITX board, silver CPU socket, black I/O shield, gold PCIe slot, two M.2 slots, antenna connectors

MSI

MSI H510I PRO WIFI Intel H510 motherboard

SKU CH-6XS7-HW7HZ

A Mini-ITX board with LGA 1200 socket for 10th and 11th Gen Intel Core processors, dual-channel DDR4 up to 3200 MHz, 64 GB maximum memory, one PCIe x16 slot, 2.5 Gbps LAN, Realtek ALC897 7.1 audio.

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core Processors, 11th Gen Intel Core
  • ChipsetIntel H510
  • Memory StandardSupport dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133
  • Maximum Memory Supported64GB
  • PCI Slots1x PCIe x16 slot Support up to PCIe 4.0 for 11th Gen Intel C
  • Supports 10th and 11th Gen Intel Core, Pentium Gold and Celeron processors on LGA 1200 socket
  • Dual-channel DDR4 memory up to 3200 MHz with 64 GB maximum capacity
  • PCIe 4.0 x16 slot for 11th Gen CPUs and PCIe 3.0 for 10th Gen CPUs
  • Realtek 8125B 2.5 Gbps LAN plus four USB 3.2 Gen 1 and four USB 2.0 ports
  • Realtek ALC897 7.1-channel audio with one M.2 and four SATA III connections

LGA 1200 Mini-ITX motherboard for compact builds

The MSI H510I PRO WIFI fits Intel 10th and 11th generation Core, Pentium Gold and Celeron processors into a Mini-ITX form factor. It targets system builders who need a small footprint without sacrificing core connectivity. The board delivers the essential platform features for everyday computing and light workloads.

Dual-channel DDR4 with 2.5 Gbps LAN and 7.1 audio

Four memory slots support dual-channel DDR4 up to 3200 MHz and a 64 GB capacity ceiling. A Realtek 8125B controller provides 2.5 Gbps wired networking, while the ALC897 codec handles 7.1-channel audio. Rear I/O includes two USB 3.2 Gen 1 Type-A ports, four USB 2.0 Type-A ports and an internal USB 3.2 Gen 1 header for front-panel expansion.

PCIe generation depends on the installed CPU

The single PCIe x16 slot runs at PCIe 4.0 with an 11th generation processor and at PCIe 3.0 with a 10th generation processor. Storage options comprise one M.2 interface and four SATA III ports. This distinction is the key factor when matching the board to a graphics card or high-speed storage device.

Highlights

  • Supports 10th and 11th Gen Intel Core, Pentium Gold and Celeron processors on LGA 1200 socket
  • Dual-channel DDR4 memory up to 3200 MHz with 64 GB maximum capacity
  • PCIe 4.0 x16 slot for 11th Gen CPUs and PCIe 3.0 for 10th Gen CPUs
  • Realtek 8125B 2.5 Gbps LAN plus four USB 3.2 Gen 1 and four USB 2.0 ports
  • Realtek ALC897 7.1-channel audio with one M.2 and four SATA III connections

Specifications

BrandMSI
SeriesMSI H510I PRO WIFI
ModelMSI H510I PRO WIFI
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors
Processor socket LGA1200
ChipsetIntel H510
Memory StandardSupport dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133MHz memory
Maximum Memory Supported64GB
PCI Slots1x PCIe x16 slot
Support up to PCIe 4.0 for 11th Gen Intel CPU
Support up to PCIe 3.0 for 10th Gen Intel CPU
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN Chipset1x Realtek 8125B 2.5Gbps LAN controller
Onboard USBntel H510 Chipset
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors)
4x USB 2.0 Type-A ports on the back panel
GL850G Hub
2x USB 2.0 ports available through the internal USB connector

Questions about this item

What PCIe generation does the single x16 slot run at with an 11th Gen CPU?

The x16 slot supports PCIe 4.0 when an 11th Gen Intel Core processor is installed, and PCIe 3.0 with a 10th Gen CPU.

What form factor and socket does this board use for case and cooler compatibility?

It is a Mini-ITX board with an LGA 1200 socket, so it fits Mini-ITX cases and coolers rated for LGA 1200.

How do I attach the Wi-Fi antenna and where is the connector located?

Screw the supplied antenna onto the gold MHF4 connector on the rear I/O panel; the connector is labelled and sits next to the LAN port.
