Green micro-ATX board with silver CPU socket, four black RAM slots, single PCIe x16 slot, M.2 key-E socket, four SATA ports

MSI

MSI H510M-A PRO Intel H510 LGA 1200 DDR4 Micro ATX Motherboard

SKU CH-59TZ-N6SZP

Supports 10th and 11th Gen Intel Core, Pentium Gold and Celeron processors with dual-channel DDR4 up to 3200 MHz and 64 GB capacity

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core Processors, 11th Gen Intel Core
  • ChipsetIntel H510
  • Memory StandardSupport dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133
  • Maximum Memory Supported64GB
  • PCI Slots1x PCIe x16 slot (From CPU) Support up to PCIe 4.0 for 11th
  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64GB with XMP 2.0 support
  • PCIe 4.0 x16 slot ready for 11th Gen CPUs
  • Intel I219V 1Gbps LAN and Realtek ALC897 7.1-channel audio
  • Four SATA III ports plus M.2 E-key slot for WiFi module

Board identity

The MSI H510M-A PRO is a Micro ATX motherboard built on the Intel H510 chipset for LGA 1200 processors. It supports 10th and 11th Gen Intel Core, Pentium Gold and Celeron CPUs with dual-channel DDR4 memory up to 64GB.

Thermals noise and power

The board draws power through a standard 24-pin ATX connector and a 4-pin CPU connector without additional PCIe power inputs. Passive heatsinks on the VRM and chipset keep temperatures in check during typical office or home workloads while the single system-fan header allows quiet, low-speed cooling.

Memory limit

Maximum supported capacity is 64GB across two DDR4 slots running at speeds from 2133 to 3200MHz with XMP 2.0 support. This ceiling determines whether the platform suits your multitasking or content-creation needs.

Highlights

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64GB with XMP 2.0 support
  • PCIe 4.0 x16 slot ready for 11th Gen CPUs
  • Intel I219V 1Gbps LAN and Realtek ALC897 7.1-channel audio
  • Four SATA III ports plus M.2 E-key slot for WiFi module

Specifications

BrandMSI
SeriesMSI H510M-A PRO
ModelMSI H510M-A PRO
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors1
ChipsetIntel H510
Memory StandardSupport dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133MHz memory
Support ECC UDIMM memory module (running in non-ECC mode)
Supports Intel Extreme Memory Profile (XMP) 2.0 technology
Maximum Memory Supported64GB
PCI Slots1x PCIe x16 slot (From CPU)
Support up to PCIe 4.0 for 11th Gen Intel CPU
Support up to PCIe 3.0 for 10th Gen Intel CPU
1x PCIe 3.0 x1 slot (From PCH)
1x M.2 slot with E key for WiFi module only(M2_2)
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN Chipset1x Intel I219V 1Gbps LAN controller
Onboard USB4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 ports (4 Type-A ports on the back panel(hub- GL850G), 2 ports available through the internal USB 2.0 connector)

Questions about this item

How do I seat the CPU in the LGA 1200 socket without bending pins?

Align the notches on the processor with the socket keys, lower it straight down without force, then close the retention lever until it clicks; the lever pressure secures the chip.

What component will need replacement first during long-term ownership?

The CMOS battery included in the box will eventually lose charge; swap it when the system clock drifts or BIOS settings reset.

Which limit appears first when the VRM runs under sustained load?

The 6-phase power delivery feeding the LGA 1200 socket reaches its thermal ceiling before the chipset does, so VRM temperature becomes the bottleneck.
