Green Micro ATX board with silver heatsinks and black PCB

MSI

MSI H510M BOMBER Intel motherboard

SKU CH-B66N-YVFKJ

Micro ATX board for 10th and 11th Gen Intel Core, Pentium Gold and Celeron CPUs on LGA 1200, with dual-channel DDR4 up to 64 GB, PCIe 4.0 on 11th Gen, four SATA III ports and Intel 219V 1 Gbps LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core Processors, 11th Gen Intel Core
  • ChipsetIntel H510
  • Memory StandardSupport dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133
  • Maximum Memory Supported64GB
  • PCI Slots1x PCIe x16 slot (From CPU) Support up to PCIe 4.0 for 11th
  • Supports 10th and 11th Gen Intel Core CPUs via LGA 1200 socket
  • Dual-channel DDR4 up to 3200 MHz with 64 GB maximum capacity
  • PCIe 4.0 x16 slot for 11th Gen CPUs, PCIe 3.0 for 10th Gen
  • Realtek ALC897 7.1-channel audio and Intel I219V 1 Gbps LAN
  • Four USB 3.2 Gen 1 ports plus six USB 2.0 ports onboard

LGA 1200 micro-ATX foundation

The MSI H510M BOMBER is a micro-ATX motherboard built around the Intel H510 chipset and LGA 1200 socket. It accepts 10th and 11th Gen Intel Core processors plus Pentium Gold and Celeron CPUs. Dual-channel DDR4 memory runs up to 3200 MHz with a 64 GB ceiling.

Budget builders versus expanders

First-time builders and office upgraders who need one graphics card and a few SATA drives will find the layout straightforward. Enthusiasts wanting multiple PCIe x16 slots, CPU overclocking or more than four SATA ports should consider a different chipset.

PCIe generation tied to CPU generation

The single PCIe x16 slot operates at 4.0 with an 11th Gen processor and at 3.0 with a 10th Gen processor. That single lane-width and generation switch is the specification that decides whether the board matches the graphics card and processor you plan to install.

Highlights

  • Supports 10th and 11th Gen Intel Core CPUs via LGA 1200 socket
  • Dual-channel DDR4 up to 3200 MHz with 64 GB maximum capacity
  • PCIe 4.0 x16 slot for 11th Gen CPUs, PCIe 3.0 for 10th Gen
  • Realtek ALC897 7.1-channel audio and Intel I219V 1 Gbps LAN
  • Four USB 3.2 Gen 1 ports plus six USB 2.0 ports onboard

Specifications

BrandMSI
SeriesMSI H510M BOMBER
ModelMSI H510M BOMBER
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processors
ChipsetIntel H510
Memory StandardSupport dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133MHz memory
Maximum Memory Supported64GB
PCI Slots1x PCIe x16 slot (From CPU)
Support up to PCIe 4.0 for 11th Gen Intel CPU
Support up to PCIe 3.0 for 10th Gen Intel CPU
1x PCIe 3.0 x1 slot (From PCH)
1x M.2 slot with E key for WiFi module only(M2_2)
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN Chipset1x Intel I219V 1Gbps LAN controller
Onboard USB4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 ports (4 Type-A ports on the back panel(hub- GL850G), 2 ports available through the internal USB 2.0 connector)

Questions about this item

Which processor socket must my CPU have to fit the H510M BOMBER?

The board uses the LGA 1200 socket, so the CPU must be an LGA 1200 model such as a 10th or 11th Gen Intel Core, Pentium Gold or Celeron processor.

If I keep my PCIe 3.0 graphics card, will it run at full speed in the primary x16 slot?

With a 10th Gen CPU the slot operates at PCIe 3.0, matching the card; with an 11th Gen CPU the slot can run at PCIe 4.0 but the card will still work at its native 3.0 speed.

How can I verify the 7.1-channel Realtek ALC897 audio is active after building the system?

Open Windows Sound settings, select the Realtek device, choose the 7.1 configuration in speaker setup and run the test tones for all eight channels.
