Silver micro-ATX board with teal geometric accents, LGA 1851 socket, dual DDR5 slots, PCIe 5.0 x16 slot, M.2 shield, USB 20G Type-C

MSI

MSI H810M GAMING WIFI6E DDR5 6400MHz Intel motherboard

SKU CH-K09D-MEMZP

H810 chipset board for Intel Core Ultra LGA 1851 CPUs with DDR5 6400 MT/s support, PCIe 5.0 x16 slot, Wi-Fi 6E, 2.5G LAN and USB 20G Type‑C

  • Supports Intel Core Ultra Series 2 processors on LGA 1851 socket
  • DDR5 memory up to 6400 MT/s overclocked with XMP 3.0 support
  • PCIe 5.0 x16 slot for latest graphics cards
  • Wi-Fi 6E and 2.5G LAN for high-speed networking
  • USB 20G Type-C port for fast data transfer

H810M GAMING WIFI6E DDR5 board for Intel Core

This motherboard uses the Intel H810 chipset and the LGA 1851 socket to support Intel Core Ultra Processors (Series 2). It provides two DDR5 UDIMM slots with a maximum capacity of 128GB and runs memory at JEDEC speeds from 4800 to 6400 MT/s, plus overclocking via Intel XMP 3.0. The board targets gamers and AI workloads with a 6 P-PAK power system, 8-pin CPU power connectors and a 6-layer server-grade PCB.

Check CPU cooler clearance

The LGA 1851 socket requires a compatible cooler mounting pattern, so verify your cooler kit includes the correct hardware. This board uses single-sided latches on its two DIMM slots, which can affect installation with tall heatspreaders. You also need a processor with integrated graphics to use the onboard HDMI 2.1 and DisplayPort 1.4 video outputs, both limited to 4K 60Hz. The single PCIe 5.0 x16 slot and two PCIe 4.0 x1 slots define your expansion options.

Extended heatsinks and M.2 Shield Frozr handle

MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and the M.2 Shield Frozr work with the extended heatsink to manage heat during sustained loads. The 6 P-PAK power system and 8-pin CPU connectors deliver stable current to the voltage regulators, helping to keep component temperatures in check. Onboard Wi-Fi 6E and 2.5G LAN add connectivity without extra cards that would increase case airflow restrictions.

Highlights

  • Supports Intel Core Ultra Series 2 processors on LGA 1851 socket
  • DDR5 memory up to 6400 MT/s overclocked with XMP 3.0 support
  • PCIe 5.0 x16 slot for latest graphics cards
  • Wi-Fi 6E and 2.5G LAN for high-speed networking
  • USB 20G Type-C port for fast data transfer

Specifications

No published specifications for this item yet.

Questions about this item

Does the H810M GAMING WIFI6E include Wi-Fi antennas or must they be purchased separately?

The motherboard includes Wi-Fi 6E and 2.5G LAN onboard; antenna connectors are present on the rear I/O so the supplied antennas attach directly without extra parts.

Should I choose DDR5 4800 or 6400 MT/s modules for this board?

The board supports JEDEC speeds up to 4800 MT/s and overclocked speeds up to 6400+ MT/s via XMP 3.0; pick 6400 MT/s kits for maximum rated performance.

What does the PCIe 5.0 x16 slot deliver once a graphics card is installed?

The primary PCIe 5.0 x16 slot connects directly to the CPU, providing full 5.0 bandwidth for compatible graphics cards or add-in cards.
