Green Micro-ATX board with black slots and silver I/O shield

MSI

MSI H81M-P33 PLUS 16GB DDR3 LGA 1150 Intel motherboard

SKU CH-DS1M-BEC72

Micro-ATX board for LGA 1150 CPUs with dual-channel DDR3 up to 16 GB, one PCIe 2.0 x16 slot, two SATA III and two SATA II ports, Realtek ALC887 audio and RTL8111G LAN.

  • CPU Socket TypeLGA 1150
  • CPU Type4th generation Intel Core i7/i5/i3/Pentium/Celeron processor
  • ChipsetIntel H81
  • Memory StandardSupports dual-channel DDR3 1600/1333/1066MHz memory
  • Maximum Memory Supported16GB
  • PCI Slots1 PCIe 2.0 x16 slot 1 PCIe 2.0 x1 slot
  • Supports 16GB DDR3 dual-channel memory up to 1600MHz
  • LGA 1150 socket fits 4th generation Intel Core and Pentium CPUs
  • Intel H81 chipset provides 2 SATA III and 2 SATA II ports
  • Realtek ALC887 audio and RTL8111G LAN built into the board
  • Micro ATX form factor with 1 PCIe 2.0 x16 and 1 PCIe 2.0 x1 slot

LGA 1150 Micro ATX board

The MSI H81M-P33 PLUS is a Micro ATX motherboard built around the Intel H81 chipset for LGA 1150 processors. It accepts 4th generation Core i7, i5, i3, Pentium and Celeron CPUs. Dual-channel DDR3 memory runs at 1600, 1333 or 1066 MHz up to 16 GB total. A single PCIe 2.0 x16 slot handles a graphics card.

Best for basic builds, not for newer CPUs

This board suits budget office PCs, home servers or legacy upgrades that need LGA 1150 and DDR3. It provides two SATA III and two SATA II ports, Realtek ALC887 audio and a Realtek RTL8111G LAN controller. Builders targeting 6th generation or later Intel processors, or any AMD platform, must choose a different socket and chipset.

One PCIe 2.0 x16 slot decides GPU choice

The only full-length expansion slot is a PCIe 2.0 x16 connector, so graphics cards are limited to that interface speed. A single PCIe 2.0 x1 slot is available for add-in cards such as Wi-Fi or extra USB controllers. Rear I/O includes two USB 3.1 Gen1 ports and four USB 2.0 ports, with four more USB 2.0 headers onboard.

Highlights

  • Supports 16GB DDR3 dual-channel memory up to 1600MHz
  • LGA 1150 socket fits 4th generation Intel Core and Pentium CPUs
  • Intel H81 chipset provides 2 SATA III and 2 SATA II ports
  • Realtek ALC887 audio and RTL8111G LAN built into the board
  • Micro ATX form factor with 1 PCIe 2.0 x16 and 1 PCIe 2.0 x1 slot

Specifications

BrandMSI
SeriesMSI H81M-P33 PLUS
ModelMSI H81M-P33 PLUS
CPU Socket TypeLGA 1150
CPU Type4th generation Intel Core i7/i5/i3/Pentium/Celeron processors with LGA 1150 architecture
ChipsetIntel H81
Memory StandardSupports dual-channel DDR3 1600/1333/1066MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCIe 2.0 x16 slot
1 PCIe 2.0 x1 slot
SATA RAID2XSATA III interface, 2xSATA II interface
Audio ChipsetRealtek ALC887 Decoder Chip
LAN Chipset1 Realtek RTL8111G network interface card
Onboard USB2 USB 3.1 Gen1 ports (backplane)
- 8 USB 2.0 ports (4 located on the back panel, 4 to be provided through built-in interfaces)

Questions about this item

What size case and screw pattern does this Micro ATX board need?

It fits any Micro ATX or larger chassis using the standard mounting holes for this form factor.

Which memory slots must be filled first for dual-channel DDR3 1600/1333/1066 operation?

Populate the two slots of the same colour — usually DIMM1 and DIMM2 — so the memory controller enables dual-channel mode.

What component should be replaced when the system loses date, time or BIOS settings after power-off?

The included CMOS battery on the board; swap it with an identical coin cell when settings no longer persist.
