Green micro-ATX board with black sockets and silver heatsinks

MSI

MSI H81M-P33 V2 Intel H81 motherboard LGA 1150 DDR3 16GB Micro ATX

SKU CH-1RDR-ACQKY

Micro-ATX board for LGA 1150 CPUs with dual-channel DDR3 up to 16 GB, one PCIe 2.0 x16 slot, two SATA III and two SATA II ports, Realtek 8-channel audio and gigabit LAN

  • CPU Socket TypeLGA 1150
  • CPU Type4th generation Intel Core i7/Core i5/Core i3/Pentium/Celeron
  • ChipsetIntel H81
  • Memory StandardSupports dual-channel DDR3 1600/1333/1066MHz memory
  • Maximum Memory Supported16GB
  • PCI Slots1 PCIe 2.0 x16 slot 2 PCIe x1 slots
  • Supports 4th generation Intel Core processors with LGA 1150 socket
  • Dual-channel DDR3 memory up to 16GB at 1600/1333/1066MHz
  • 8-channel audio via Realtek ALC887 chipset
  • Gigabit LAN with Realtek 8111G controller
  • Four USB 3.0 ports for fast peripheral connectivity

Socket and chipset

This Micro ATX board uses the Intel H81 chipset and an LGA 1150 socket. It accepts 4th generation Intel Core i7, Core i5, Core i3, Pentium and Celeron processors. The form factor fits compact chassis while keeping essential expansion.

Memory and expansion

Dual-channel DDR3 memory runs at 1600, 1333 or 1066 MHz up to a 16 GB limit. A single PCIe 2.0 x16 slot and two PCIe x1 slots provide room for a graphics card and add-in boards. Storage connects through two SATA III and two SATA II ports.

Sustained operation

Realtek ALC887 audio delivers 8-channel output compliant with Azalia 1.0. The Realtek 8111G LAN controller handles 10/100/1000 Ethernet traffic without extra cards. Four USB 3.0 ports, split between rear and front-panel headers, maintain throughput during long file transfers.

Highlights

  • Supports 4th generation Intel Core processors with LGA 1150 socket
  • Dual-channel DDR3 memory up to 16GB at 1600/1333/1066MHz
  • 8-channel audio via Realtek ALC887 chipset
  • Gigabit LAN with Realtek 8111G controller
  • Four USB 3.0 ports for fast peripheral connectivity

Specifications

BrandMSI
SeriesMSI H81M-P33 V2
ModelMSI H81M-P33 V2
CPU Socket TypeLGA 1150
CPU Type4th generation Intel Core i7/Core i5/Core i3/Pentium/Celeron processors with Socket 1150 architecture
ChipsetIntel H81
Memory StandardSupports dual-channel DDR3 1600/1333/1066MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCIe 2.0 x16 slot
2 PCIe x1 slots
SATA RAID2XSATA II interface, 2xSATA III interface
Audio ChipsetRealtek ALC887
- Supports 8-channel audio output
- Compliant with Azalia 1.0 specifications
LAN Chipset1 PCI Express network port supporting 10/100/1000 Fast Ethernet provided by Realtek 8111G
Onboard USB2 USB 3.0 ports located on the backplane
2 USB 3.0 ports are located on the front panel

Questions about this item

Which DDR3 memory speeds does this board support?

The board runs dual-channel DDR3 at 1600, 1333 and 1066 MHz, with a maximum capacity of 16 GB.

Will a 4th-generation Core i5 fit the socket?

Yes, the LGA 1150 socket accepts 4th-generation Intel Core i7, i5, i3, Pentium and Celeron processors.

How many SATA III ports are available for SSDs or hard drives?

Two SATA III and two SATA II connectors are provided on the board.
