Green Micro ATX motherboard with black LGA 1150 socket, four silver DDR3 slots, silver PCIe x16 slot, and silver rear I/O panel

MSI

MSI H87M-E35 LGA 1150 Intel H87 Micro ATX DDR3 16GB motherboard

SKU CH-0MPR-BK3PJ

LGA 1150 micro-ATX board with Intel H87 chipset, dual-channel DDR3 up to 16 GB, six SATA III ports and USB 3.0 connectivity

  • CPU Socket TypeLGA 1150
  • CPU TypeIntel Core ™ i7/Core ™ i5/Core ™ i3/Pentium/Celeron processo
  • ChipsetIntel H87
  • Memory StandardSupports dual-channel DDR3 1600/1333/1066MHz memory
  • Maximum Memory Supported16GB
  • PCI Slots1X PCIe x16 slots 2X PCIe 2.0 x1 slots 1 x PCIe slot
  • Supports up to 16GB DDR3 memory
  • Dual-channel DDR3 at 1600MHz for responsive multitasking
  • Six SATA III ports for multiple drives
  • Realtek ALC887 delivers 8-channel audio
  • Gigabit LAN via Realtek PCI Express controller

Socket LGA 1150 Micro ATX board

The MSI H87M-E35 is a Micro ATX motherboard built around the Intel H87 chipset for Socket LGA 1150 processors. It accepts Core i7, i5, i3, Pentium and Celeron CPUs in a compact form factor suited to smaller chassis.

Dual-channel DDR3 up to 16 GB

Memory support is the key compatibility check: the board runs dual-channel DDR3 at 1600, 1333 or 1066 MHz and is hard-limited to 16 GB total across its two slots. Exceeding this capacity is not possible.

Six SATA III ports and six USB 3.0 ports

Storage and peripheral headroom are generous for the form factor with six SATA III connectors and six USB 3.0 ports split between rear panel and internal headers. The single PCIe x16 slot and two PCIe 2.0 x1 slots limit expansion to one graphics card and two add-in cards.

Highlights

  • Supports up to 16GB DDR3 memory
  • Dual-channel DDR3 at 1600MHz for responsive multitasking
  • Six SATA III ports for multiple drives
  • Realtek ALC887 delivers 8-channel audio
  • Gigabit LAN via Realtek PCI Express controller

Specifications

BrandMSI
SeriesMSI H87M-E35
ModelMSI H87M-E35
CPU Socket TypeLGA 1150
CPU TypeIntel Core ™ i7/Core ™ i5/Core ™ i3/Pentium/Celeron processors with Socket 1150 architecture
ChipsetIntel H87
Memory StandardSupports dual-channel DDR3 1600/1333/1066MHz memory
Maximum Memory Supported16GB
PCI Slots1X PCIe x16 slots
2X PCIe 2.0 x1 slots
1 x PCIe slot
SATA RAID6XSATA III interface
Audio ChipsetRealtek ALC887 Audio Chip
- Supports 8-channel audio output
- Compliant with Azalia 1.0 specifications
LAN Chipset1 PCI Express network port supports 10/100/1000 Fast Ethernet provided by Realtek
Onboard USB6 USB 3.0 ports (4 on the backplane, 2 built-in)
6 USB 2.0 ports (2 on the backplane, 4 built-in)

Questions about this item

What does the 16 GB maximum memory mean for a build using this board?

The board supports up to 16 GB of dual-channel DDR3 across its slots, so a typical build would use two 8 GB modules running at 1600, 1333 or 1066 MHz.

How fast are the six SATA III ports in practice?

Each SATA III port runs at up to 6 Gb/s, giving the full standard throughput for SSDs and hard drives connected to the six onboard connectors.

What clearance does the Micro ATX form factor need in a case?

The Micro ATX layout fits any case with Micro ATX or larger mounting holes and the standard I/O shield cut-out, using the supplied back panel.
