Green Micro ATX board with AM2 socket and silver heatsink

MSI

MSI K9N6PGM2-V2 Socket AM2+/AM2 NVIDIA NF6100-430 AMD motherboard

SKU CH-FJRT-MPCXZ

Micro-ATX board with NVIDIA NF6100-430 chipset supporting Socket AM2+/AM2 CPUs and up to 8GB DDR2 memory

  • CPU Socket TypeSocket AM2+/AM2
  • CPU TypeAM2 slot supports AMD Athlon 64 and Athlon 64X2 processors A
  • ChipsetNVIDIA NF6100-430
  • Memory StandardSupports dual-channel DDR2 800/667MHz memory
  • Maximum Memory Supported8GB
  • PCI Slots1 PCI Express 1.0 x16 slot 1 PCI Express 1.0 x1 slot 2 PCI s
  • Supports AMD Athlon 64 and Athlon 64X2 processors via AM2 socket
  • AM2+ socket accepts AMD Phenom, Phenom II and Athlon II CPUs up to 95W
  • NVIDIA NF6100-430 chipset provides integrated graphics and system control
  • Dual-channel DDR2 800/667MHz memory support up to 8GB
  • Realtek ALC888/ALC888S audio chip enables 8-channel sound effects

Socket AM2+/AM2 micro-ATX board

This micro-ATX motherboard fits Socket AM2+/AM2 processors from AMD. It accepts Athlon 64, Athlon 64 X2 and Phenom CPUs up to 95 W. The NVIDIA NF6100-430 chipset provides integrated graphics and basic platform features for budget desktop builds.

PCI Express 1.0 and DDR2 limits

The board carries one PCI Express 1.0 x16 slot and one PCI Express 1.0 x1 slot plus two 3.3 V/5 V PCI slots. Dual-channel DDR2 memory runs at 800 or 667 MHz with a maximum capacity of 8 GB. Onboard audio uses the Realtek ALC888 codec for 8-channel output. Networking is handled by Realtek 8201EL and 8211CL chips providing 10/100 and 10/100/1000 Ethernet.

Simple drop-in with legacy I/O

Installation follows standard micro-ATX mounting points and a 24-pin ATX power connector. The rear panel supplies four USB 2.0 ports, PS/2 keyboard and mouse, VGA, Ethernet and audio jacks. A single SATA cable and I/O shield are included. Builders must verify CPU support on the vendor list and ensure the 95 W limit is not exceeded.

Highlights

  • Supports AMD Athlon 64 and Athlon 64X2 processors via AM2 socket
  • AM2+ socket accepts AMD Phenom, Phenom II and Athlon II CPUs up to 95W
  • NVIDIA NF6100-430 chipset provides integrated graphics and system control
  • Dual-channel DDR2 800/667MHz memory support up to 8GB
  • Realtek ALC888/ALC888S audio chip enables 8-channel sound effects

Specifications

BrandMSI
SeriesMSI K9N6PGM2-V2
ModelMSI K9N6PGM2-V2
CPU Socket TypeSocket AM2+/AM2
CPU TypeAM2 slot supports AMD Athlon 64 and Athlon 64X2 processors
AM2 + slot supports AMD Phenom processors (95W only)
AM2 + slot supports AMD Phenom II/Athlon II processors (95W only)
Please check the support status table for CPU support. The above specifications are for reference only
ChipsetNVIDIA NF6100-430
Memory StandardSupports dual-channel DDR2 800/667MHz memory
Maximum Memory Supported8GB
PCI Slots1 PCI Express 1.0 x16 slot
1 PCI Express 1.0 x1 slot
2 PCI slots, supporting 3.3v/5v PCI main bus interface
SATA RAIDNo data yet
Audio ChipsetRealtek ALC888/ALC888S Chip
- Supports 8-channel sound effects detected by intelligent sound interface
Compatible with Azalia 1.0 specifications
LAN ChipsetRealtek 8201EL chip supports 10/100 high-speed Ethernet network
Realtek 8211CL chip supports 10/100/1000 high-speed Ethernet networks
Onboard USB4 USB 2.0 ports (backplane)

Questions about this item

Should I pick the AM2 or AM2+ socket version of this board for a Phenom II CPU?

The board uses a single Socket AM2+/AM2 that accepts Phenom II processors up to 95 W; no separate version choice is needed.

What does the 8 GB maximum memory mean when I install DDR2 modules?

You can populate the dual-channel DDR2 800/667 MHz slots with up to 8 GB total capacity.

How does the PCI Express 1.0 x16 slot limit a modern graphics card?

The slot runs at PCI Express 1.0 speeds, capping bandwidth to the 1.0 generation for any installed GPU.
