MSI MAG A750BN PCIE5 750W power supply
A 750 W ATX power supply with 80 PLUS Bronze efficiency, a native 16-pin PCIe 5.1 connector for 300 W GPU power, active PFC and DC-to-DC design, plus full OCP, OVP, OPP.
- ColorBlack
- TypeIntel ATX 12V
- Maximum Power750 W
- Fans1 x 120 mm
- PFCActive
- Max PSU Length150 mm
Options ATX 80+ Bronze (750W)
- 750 W maximum power delivers stable energy for demanding builds
- 80 PLUS Bronze certification reduces energy consumption and heat output
- PCIe 5.1 ready native 16-pin connector supplies up to 300 W to modern GPUs
- 120 mm sleeve-bearing fan runs quietly while keeping temperatures low
- Compact 150 mm depth fits easily into smaller cases
750W ATX power supply for gaming builds
The MSI MAG A750BN PCIE5 delivers 750 W of continuous power from a standard Intel ATX 12V design. It targets entry-level gaming systems that need a reliable unit with modern GPU support. The 80 PLUS BRONZE rating confirms efficient operation across typical loads. A single 120 mm sleeve-bearing fan handles cooling duties.
Non-modular cables with native 16-pin GPU connector
All cables are fixed, so unused leads must be routed inside the case. The unit includes one 24-pin ATX, one 8-pin EPS, two 8-pin PCIe, five SATA, two Molex and one FDD connector. A native 16-pin 12V-2x6 cable supplies up to 300 W to PCIe 5.0 graphics cards such as the RTX 4070 series. DC-to-DC circuitry keeps minor rails stable.
150 mm depth fits compact cases
At 150 mm long the supply suits smaller chassis where longer units cannot be installed. Active PFC accepts 100-240 V input at 50/60 Hz for worldwide use. Protections cover over-current, over-voltage, over-power, over-temperature and short-circuit events. The fixed cable set limits routing flexibility in very tight layouts.
Highlights
- 750 W maximum power delivers stable energy for demanding builds
- 80 PLUS Bronze certification reduces energy consumption and heat output
- PCIe 5.1 ready native 16-pin connector supplies up to 300 W to modern GPUs
- 120 mm sleeve-bearing fan runs quietly while keeping temperatures low
- Compact 150 mm depth fits easily into smaller cases
Specifications
| Brand | MSI |
|---|---|
| Model | MAG A750BN PCIE5 |
| Color | Black |
| Type | Intel ATX 12V |
| Maximum Power | 750 W |
| Fans | 1 x 120 mm |
| PFC | Active |
| Max PSU Length | 150 mm |
| Modular | No |
| Energy-Efficient | 80 PLUS BRONZE Certified |
| Protection | OCP / OVP / OPP / OTP / SCP |
| Input Voltage | 100 - 240 V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 10-5A |
| Output | +3.3V@20A, +5V@20A, [email protected] , [email protected] , [email protected] |
| Connectors | 1 x 24 pin (20+4) ATX 1 x 8 pin (4+4) EPS (CPU) 2 x 8 pin (6+2) PCIe 5 x SATA 2 x Molex 1 x FDD |
| Dimensions | 5.51 x 5.9 x 3.38" |
| Weight | 4.37 lbs |
| Shipping weight | 2.45 kg |
| Package size | 292 × 203 × 127 mm |
Other versions of this model
4 more in the same range
Same family, different memory, cooler or clock — compare before you commit.
Questions about this item
What PCIe connector standard does the MAG A750BN PCIE5 use, and how much GPU power can it deliver?
It includes a native 16-pin 12V-2x6 cable rated for up to 300 W, making the unit PCIe 5.1 ready for compatible graphics cards.
What are the physical dimensions and mounting requirements for this power supply?
The unit measures 150 mm long, 5.51 inches wide and 3.38 inches high, fitting standard ATX bays with four rear mounting screws.
How do you install the fixed cables, and which step do builders often miss?
Connect the 24-pin ATX, the 8-pin EPS and the two 8-pin PCIe leads to the motherboard and GPU; the step often missed is seating the 16-pin 12V-2x6 connector fully until the latch clicks.
