Black ATX motherboard with silver heatsinks and grey PCB

MSI

MSI MAG Z590 TORPEDO Intel motherboard LGA 1200 DDR4 128GB

SKU CH-TMJA-PQ873

Z590 ATX board for 10th and 11th Gen Intel CPUs with 128 GB DDR4, 2.5 Gbps LAN and USB 3.2 Gen 2x2

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core™, 11th Gen Intel Core™, Pentium
  • ChipsetIntel Z590
  • Memory StandardSupport dual channel DDR4 5333 (OC)/5200 (OC)/5000 (OC)/4800
  • Maximum Memory Supported128GB
  • PCI Slots2x PCIe x16 slots 1x PCIe 3.0 x16 slot (from CPU) Support up
  • Supports 10th and 11th Gen Intel Core processors on LGA 1200 socket
  • Dual-channel DDR4 memory up to 128GB with speeds to 5333 OC
  • Intel Z590 chipset enables PCIe 4.0 on 11th Gen CPUs and PCIe 3.0 on 10th Gen
  • Dual Intel LAN with 2.5Gbps I225-V and 1Gbps I219-V controllers
  • Realtek ALC4080 codec delivers 7.1-channel high-definition audio with S/PDIF output

Socket and chipset

The board uses the LGA 1200 socket paired with the Intel Z590 chipset. It accepts 10th and 11th Gen Intel Core, Pentium Gold and Celeron processors. This combination determines whether your CPU will fit and which PCIe generation the top slot can run.

Memory capacity and speeds

Four DDR4 slots support a maximum of 128 GB. The board validates a long list of overclocked frequencies from 3300 up to 5333 MT/s. Buyers planning large memory kits should verify their modules appear on the qualified vendor list.

Connectivity and audience

Dual Intel LAN controllers provide 2.5 Gbps and 1 Gbps ports, while the rear I/O includes a USB 3.2 Gen 2x2 Type-C at 20 Gbps. The ATX form factor and extensive PCIe layout suit builders who need multiple expansion cards and high-speed external storage. Users requiring integrated Wi-Fi or a smaller footprint should consider other models.

Highlights

  • Supports 10th and 11th Gen Intel Core processors on LGA 1200 socket
  • Dual-channel DDR4 memory up to 128GB with speeds to 5333 OC
  • Intel Z590 chipset enables PCIe 4.0 on 11th Gen CPUs and PCIe 3.0 on 10th Gen
  • Dual Intel LAN with 2.5Gbps I225-V and 1Gbps I219-V controllers
  • Realtek ALC4080 codec delivers 7.1-channel high-definition audio with S/PDIF output

Specifications

BrandMSI
SeriesMSI MAG Z590 TORPEDO
ModelMSI MAG Z590 TORPEDO
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core™, 11th Gen Intel Core™, Pentium Gold and Celeron processors
Processor socket LGA1200
ChipsetIntel Z590
Memory StandardSupport dual channel DDR4 5333 (OC)/5200 (OC)/5000 (OC)/4800 (OC)/4600 (OC)/4533 (OC)/4400 (OC)/4300 (OC)/4266 (OC)/4200 (OC)/4133 (OC)/4000 (OC)/3866 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3300 (OC)/3200 (OC)/3000 (OC)/2933 (JEDEC)/2666 (JEDEC)/2400 (JEDEC)/2133 (JEDEC) MHz memory
Maximum Memory Supported128GB
PCI Slots2x PCIe x16 slots
1x PCIe 3.0 x16 slot (from CPU)
Support up to PCIe 4.0 for 11th Gen Intel CPU
Support up to PCIe 3.0 for 10th Gen Intel CPU
PCI_E3 (From Z590 chipset)
Support up to PCIe 3.0 x4
2x PCIe 3.0 x1 slots (From Z590 chipset)
SATA RAID3XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC4080 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN Chipset1x Intel I225-V 2.5Gbps LAN controller
1x Intel I219-V 1Gbps LAN controller
Onboard USBIntel Z590 Chipset
1x USB3.2 Gen2x2 20Gbps Type-C port on the back panel
2x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 1 Type-A port on the back panel)
6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports through the internal connector)
1x USB 2.0 Type-A port on the back panel
Hub-GL850G
5x USB 2.0 ports (1 Type-A port on the back panel, 4 Type-A ports available through internal connectors)

Questions about this item

What does the 128GB maximum memory mean for a real build?

You can install up to 128GB of DDR4 across the four slots, giving plenty of headroom for heavy multitasking or content creation workloads.

How does the PCIe 4.0 x16 slot behave with 10th and 11th Gen CPUs?

With an 11th Gen processor the top slot runs at PCIe 4.0 x16; with a 10th Gen processor it is limited to PCIe 3.0 x16.

What physical space and mounting pattern does the board need?

The board uses the E-ATX form factor, so it requires a case that supports E-ATX dimensions and the standard ATX mounting holes.
