Black rectangular ATX motherboard with silver heatsinks and black PCB

MSI

MSI MEG Z590 UNIFY Intel motherboard LGA 1200 DDR4 128GB ATX

SKU CH-ZHME-MSXV7

ATX Intel Z590 board for LGA 1200 CPUs with DDR4 up to 128GB, PCIe 4.0 x16, 2.5Gbps LAN and USB 3.2 20Gbps Type‑C

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core™ Processors, 11th Gen Intel Cor
  • ChipsetIntel Z590
  • Memory StandardSupport dual channel DDR4 5600 (OC)/5333 (OC)/5200 (OC)/5000
  • Maximum Memory Supported128GB
  • PCI Slots1x PCIe x16 slot (PCI_E2, from CPU) Supports up to PCIe 4.0
  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 128GB with overclocked speeds reaching 5600
  • PCIe 4.0 x16 graphics slot available with 11th Gen CPU installed
  • 5Gbps Intel I225-V LAN and USB 3.2 Gen 2x2 20Gbps Type-C port
  • Realtek ALC4080 codec delivers 7.1-channel high-definition audio with S/PDIF output

LGA 1200 ATX motherboard for Intel Core

The board uses the Intel Z590 chipset and fits LGA 1200 processors from the 10 and 11 generations alongside Pentium Gold and Celeron chips. It delivers four DIMM slots that accept dual-channel DDR4 up to 128GB total capacity. The ATX layout provides one PCIe x16 slot driven by the CPU plus one PCIe x4 and two PCIe x1 slots from the chipset.

Bundled hardware changes installation scope

The package ships with the motherboard, a CMOS battery, one SATA cable and the chassis I/O back panel. A WiFi antenna is also included because the board has a built-in WiFi module. No other accessories such as additional cables, brackets or driver media are supplied, so builders must source any extra SATA cables, M.2 screws or RGB headers separately.

Suits high-memory overclocking builds not compact

The 128GB ceiling and extensive DDR4 frequency ladder appeal to enthusiasts pushing memory speeds with 10 or 11 generation CPUs. The single CPU-driven x16 slot limits multi-GPU configurations, and the ATX footprint rules out small-form-factor cases. Users needing more than one full-speed x16 link or a smaller board should consider alternative chipsets or form factors.

Highlights

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 128GB with overclocked speeds reaching 5600
  • PCIe 4.0 x16 graphics slot available with 11th Gen CPU installed
  • 5Gbps Intel I225-V LAN and USB 3.2 Gen 2x2 20Gbps Type-C port
  • Realtek ALC4080 codec delivers 7.1-channel high-definition audio with S/PDIF output

Specifications

BrandMSI
SeriesMSI MEG Z590 UNIFY
ModelMSI MEG Z590 UNIFY
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core™ Processors, 11th Gen Intel Core™ Processors, Pentium Gold and Celeron Processors
Processor socket LGA1200
ChipsetIntel Z590
Memory StandardSupport dual channel DDR4 5600 (OC)/5333 (OC)/5200 (OC)/5000 (OC)/4800 (OC)/4600 (OC)/4533 (OC)/4400 (OC)/4300 (OC)/4266 (OC)/4200 (OC)/4133 (OC)/4000 (OC)/3866 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3300 (OC)/3200 (OC)/3000 (OC)/2933 (JEDEC)/2666 (JEDEC)/2400 (JEDEC)/2133 (JEDEC) MHz memory
Maximum Memory Supported128GB
PCI Slots1x PCIe x16 slot (PCI_E2, from CPU)
Supports up to PCIe 4.0 x16 with11th Gen CPU
Supports up to PCIe 3.0 x16 with10th Gen CPU
1x PCIe 3.0 x4 slot (PCI_E4, from Z590 chipset)
2x PCIe 3.0 x1 slots (from Z590 chipset)
SATA RAID4XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC4080 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN Chipset1x Intel I225-V 2.5Gbps LAN controller
Onboard USBIntel Z590 Chipset
1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel
2x USB 3.2 Gen 2 10Gbps ports (1 Type-A port on the back panel and 1 Type-C internal connector)
10x USB 3.2 Gen 1 5Gbps ports (8 Type-A ports on the back panel, 2 ports are available through internal USB 3.2 Gen 1 connector)
2x USB 2.0 ports on the back panel
Hub-GL850G
4x USB 2.0 ports through internal USB 2.0 connector

Questions about this item

Will the CMOS battery need replacing and how often?

The board ships with a CMOS battery; typical life is several years before a swap is needed.

What limits sustained PCIe 4.0 x16 throughput with an 11th Gen CPU?

The CPU-linked PCIe 4.0 x16 slot caps bandwidth at 4.0 x16; chipset lanes remain at 3.0 x4.

How much heat and noise does the 2.5 GbE controller add under all-day load?

The Intel I225-V 2.5 Gbps LAN runs cool and silent; no active cooling is required on the motherboard.
