Black ATX motherboard with silver heatsinks and a white Gaming Edge logo on the chipset cover

MSI

MSI MPG B550 GAMING EDGE WIFI AMD motherboard

SKU CH-548J-316S8

ATX board for AM4 Ryzen CPUs with B550 chipset, dual-channel DDR4 up to 128GB, 2.5Gb LAN, Wi-Fi, and 7.1 audio

  • CPU Socket TypeSocket AM4
  • CPU TypeSupports AM4 socket 3rd Gen AMD Ryzen processors, and future
  • ChipsetAMD B550
  • Memory StandardSupport dual-channel DDR4 1866/2133/2400/2667/2800/2933/3000
  • Maximum Memory Supported128GB
  • PCI Slots1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 1x PCIe 3.0 x16 slot (PCI
  • Supports 128GB DDR4 for heavy multitasking
  • PCIe 4.0 x16 slot enables fast GPU performance
  • 5Gbps LAN delivers low-latency wired networking
  • Realtek ALC1200 provides 7.1-channel high-definition audio
  • AMD B550 chipset supports Ryzen 3000 and future CPUs with BIOS update

Socket AM4 motherboard for Ryzen builds

The MSI MPG B550 GAMING EDGE WIFI is an ATX board built on the AMD B550 chipset for Socket AM4 processors. It supports 3rd Gen AMD Ryzen CPUs and future Ryzen processors with a BIOS update. The board targets enthusiasts who want high memory speeds and 2.5Gbps networking in a standard form factor.

Standard ATX install with Wi-Fi antenna

Installation follows normal ATX mounting in any compatible case using the supplied I/O back panel. A CMOS battery and one SATA cable are included in the box. The Wi-Fi antenna must be attached to the rear panel if wireless is required. Builders should verify CPU cooler clearance against their chosen case before fitting the board.

128GB DDR4 maximum capacity

Four DIMM slots accept dual-channel DDR4 up to 128GB total across a wide frequency range from 1866 to 4866+ MHz. This ceiling determines whether the board suits high-capacity workloads or memory-intensive applications. Expansion includes one PCIe 4.0 x16 slot, one PCIe 3.0 x16 slot at x4 speed, two PCIe 3.0 x1 slots, six SATA III ports and two M.2 interfaces.

Highlights

  • Supports 128GB DDR4 for heavy multitasking
  • PCIe 4.0 x16 slot enables fast GPU performance
  • 5Gbps LAN delivers low-latency wired networking
  • Realtek ALC1200 provides 7.1-channel high-definition audio
  • AMD B550 chipset supports Ryzen 3000 and future CPUs with BIOS update

Specifications

BrandMSI
SeriesMSI MPG B550 GAMING EDGE WIFI
ModelMSI MPG B550 GAMING EDGE WIFI
CPU Socket TypeSocket AM4
CPU TypeSupports AM4 socket 3rd Gen AMD Ryzen processors, and future AMD Ryzen processors with BIOS update
ChipsetAMD B550
Memory StandardSupport dual-channel DDR4 1866/2133/2400/2667/2800/2933/3000/3066/3200/3466/3600/3733/3866/4000/4133/4266/4400/4533/4600/4733/4800/4866 + MHz memory
Maximum Memory Supported128GB
PCI Slots1x PCIe 4.0/ 3.0 x16 slot (PCI_E1)
1x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed
2x PCIe 3.0 x1 slots
SATA RAID2XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC1200 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN Chipset1x Realtek RTL8125B 2.5Gbps LAN controller
Onboard USBAMD B550 Chipset
3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector)
6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)
AMD Processor
2x USB 3.2 Gen 2 10Gbps ports (1 Type-C port and 1 Type-A port on the back panel)
2x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel

Questions about this item

How do I verify the motherboard is functioning correctly after installation?

The board posts with a BIOS screen when power is applied and detects installed DDR4 memory and storage devices listed in the hardware monitor.

What accessories are included and what must I provide separately?

The package includes the motherboard, a CMOS battery, one SATA cable and the rear I/O shield; a Wi-Fi antenna is also supplied. You must add a compatible AM4 processor, DDR4 memory modules, storage drives and a power supply.

Which memory capacity should I choose for this board?

The motherboard supports up to 128 GB of dual-channel DDR4 across four slots; select a kit that matches your workload and the listed speed range.
