Rectangular micro-ATX board, dark grey finish, silver heatsinks, rear I/O shield attached

MSI

MSI MPG B850M EDGE TI MAX WIFI AMD motherboard

SKU CH-A6HN-KPQWH

Micro-ATX AM5 board with DDR5 up to 256 GB, PCIe 5.0 x16 and dual PCIe 5.0 M.2 slots, 5 GbE LAN, Wi-Fi 7 and Bluetooth 5.4

  • CPU Socket TypeAM5
  • ChipsetAMD B850
  • Number of Memory Slots4x288pin (DDR5)
  • Maximum Memory Supported256GB
  • Memory FeatureSupports AMD POR Speed and JEDEC Speed Supports Memory Overc
  • PCI Express 5.0 x16PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E1 slo
  • Supports Ryzen 7000, 8000 and 9000 series CPUs on AM5 socket
  • DDR5 memory up to 8200 MT/s overclocked across four slots for 256 GB total
  • Wi-Fi 7 with Bluetooth 5.4 pre-installed in M.2 Key-E slot for 5.8 Gbps wireless
  • PCIe 5.0 x16 graphics slot plus two CPU-linked M.2 slots at PCIe 5.0 x4
  • 5 Gbps LAN and 20 Gbps USB-C front header for high-speed wired connectivity

AM5 B850 motherboard for Ryzen 7000.

This micro-ATX board uses the AMD B850 chipset and the AM5 socket to support Ryzen 7000, 8000 and 9000 series processors. Four DDR5 slots accept up to 256 GB of memory running at JEDEC speeds of 5600 MT/s or 4800 MT/s and overclocked speeds up to 8200 MT/s. The layout provides a PCIe 5.0 x16 slot and two CPU-attached M.2 slots for high-bandwidth graphics and storage.

Thermals, noise and power delivery

Twin 8-pin CPU power connectors and a dedicated 8-pin PCIe power connector feed the voltage regulator modules for stable current under load. Multiple system-fan headers, a pump header and an ARGB-plus-fan-plus-USB 2.0 header allow flexible cooling configurations. The pre-installed I/O shield and heatsinks on the VRM and M.2 slots help dissipate heat without adding active noise sources.

Wi-Fi 7 module and USB 20Gbps front header

A Wi-Fi 7 module sits in the onboard M.2 Key-E slot and delivers 2.4 GHz, 5 GHz and 6 GHz operation with 320 MHz channels and MU-MIMO up to 5.8 Gbps using 802.11 a/b/g/n/ac/ax/be. Bluetooth 5.4 is integrated on the same module. The front-panel USB header supplies a 20 Gbps Type-C port, while the rear I/O includes 10 Gbps Type-A, 10 Gbps Type-C, 5 Gbps Type-A, 2.0 ports, 5 Gbps LAN, HDMI, optical S/PDIF and a Flash BIOS button.

Highlights

  • Supports Ryzen 7000, 8000 and 9000 series CPUs on AM5 socket
  • DDR5 memory up to 8200 MT/s overclocked across four slots for 256 GB total
  • Wi-Fi 7 with Bluetooth 5.4 pre-installed in M.2 Key-E slot for 5.8 Gbps wireless
  • PCIe 5.0 x16 graphics slot plus two CPU-linked M.2 slots at PCIe 5.0 x4
  • 5 Gbps LAN and 20 Gbps USB-C front header for high-speed wired connectivity

Specifications

BrandMSI
SeriesMPG B850M EDGE TI MAX WIFI
ModelMPG B850M EDGE TI MAX WIFI
CPU Socket TypeAM5
ChipsetAMD B850
Number of Memory Slots4x288pin (DDR5)
Maximum Memory Supported256GB
Memory FeatureSupports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPOTM
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only*
PCI Express 5.0 x16PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E1 slot
- Supports PCIe 5.0 x16 (For Ryzen 9000/ 7000 Series processors)
- Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors)
- Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processors)
Serial ATA (SATA)4 x SATA 6Gb/s
M.2M.2_1 slot (From CPU)
• Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
• Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors)
M.2_2 slot (From CPU)
• Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
• Supports up to PCIe 4.0 x4 (For Ryzen™ 8700/ 8600 / 8400 Series processors)
• Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors)
M.2_3 slot (From B850 chipset)
• Supports up to PCIe 4.0 x4
M.2_4 slot (From B850 chipset)
• Supports up to PCIe 4.0 x4
SATA RAID• Supports RAID 0 and RAID 1 for SATA storage devices
• Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*
*RAID 5 and RAID 10 configurations are only supported by Ryzen™ 9000/ 7000 series processors.
BluetoothBluetooth 5.4
Back I/O PortsClear CMOS Button
USB 10Gbps Type-A
USB 5Gbps Type-A
5G LAN
Wi-Fi / Bluetooth
Audio Connectors
Flash BIOS Button
HDMI™
USB 10Gbps Type-C
USB 10Gbps Type-A
USB 10Gbps Type-C
Optical S/PDIF Out
Onboard USB4x USB 2.0
4x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
4x USB 10Gbps Type A (Rear)
3x USB 10Gbps Type C (Rear)
1x USB 20Gbps Type C (Front)
Other Connectors1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x PUMP_SYS Fan
4x System Fan
1x ARGB+FAN+USB2.0 Header (JAF_2)
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0
2x USB 5Gbps Type A ports
1x USB 20Gbps Type C ports
Dimensions (W x L)9.6" x 9.6"
Power Pin1 x Power Connector(ATX_PWR)
2 x Power Connector(CPU_PWR)
1 x Power Connector(PCIE_PWR 8pin)
Windows 11Support for Windows 11 64-bit

Questions about this item

How do I install the Wi-Fi 7 module on this board?

The Wireless module is pre-installed in the M.2 (Key-E) slot, so no separate installation step is required.

What maintenance will the pre-installed Wi-Fi 7 module need later?

No routine maintenance is required for the pre-installed module; firmware updates are delivered through the BIOS when released by MSI.

What thermal limit appears first on the M.2_1 slot under sustained PCIe 5.0 x4 loads?

The M.2_1 slot runs from the CPU at PCIe 5.0 x4 for Ryzen 9000/7000 Series processors; the onboard M.2 shield acts as the primary heatsink to manage drive temperatures.
