ATX motherboard with dark heatsinks and silver accents

MSI

MSI MPG X570S EDGE MAX WIFI AMD motherboard

SKU CH-C1KF-ESEJA

Supports AMD Ryzen desktop processors on Socket AM4 with AMD X570 chipset, dual-channel DDR4 memory up to 128GB, PCIe 4.0 and 3.0 slots, 2.5 Gbps LAN and 7.1-channel audio

  • CPU Socket TypeSocket AM4
  • CPU TypeSupports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Serie
  • ChipsetAMD X570
  • Memory StandardSupport dual-channel DDR4 1866/2133/2400/2667/2800/2933/3000
  • Maximum Memory Supported128GB
  • PCI SlotsSupports PCIe 4.0 / PCIe 3.0 PCIe 4.0 is available only on A
  • Supports Ryzen 5000 to 2000 series on Socket AM4
  • Dual-channel DDR4 up to 5100MHz with 128GB maximum capacity
  • PCIe 4.0 x16 slot plus three M.2 interfaces and six SATA III ports
  • Realtek ALC4080 codec delivers 7.1-channel high-definition audio
  • 5Gbps LAN via Realtek RTL8125B controller

AM4 platform for Ryzen 5000 and 3000 series

The board uses the AMD X570 chipset on a Socket AM4 foundation. It accepts Ryzen 5000, 5000 G-Series, 4000 G-Series, 3000 and 3000 G-Series desktop processors. Dual-channel DDR4 runs up to 5100 MHz with a 128 GB ceiling. PCIe 4.0 x16 from the CPU is active on Ryzen 5000 and 3000 series chips.

ATX layout with 2.5 Gbps LAN

A Realtek RTL8125B controller provides a single 2.5 Gbps Ethernet port. Rear I/O includes two USB 2.0 ports. Internal headers expose one USB 3.2 Gen 2 10 Gbps Type-C connector and four USB 3.2 Gen 1 5 Gbps ports via an Asmedia 1074 hub. Six SATA III and three M.2 interfaces handle storage.

Passive X570 cooling with Realtek ALC4080 audio

The X570 chipset is cooled without a fan, eliminating a moving part. Audio uses the Realtek ALC4080 codec for 7.1-channel output and S/PDIF. Power delivery serves the supported CPU range without auxiliary fan headers documented in the data.

Highlights

  • Supports Ryzen 5000 to 2000 series on Socket AM4
  • Dual-channel DDR4 up to 5100MHz with 128GB maximum capacity
  • PCIe 4.0 x16 slot plus three M.2 interfaces and six SATA III ports
  • Realtek ALC4080 codec delivers 7.1-channel high-definition audio
  • 5Gbps LAN via Realtek RTL8125B controller

Specifications

BrandMSI
SeriesMSI MPG X570S EDGE MAX WIFI
ModelMSI MPG X570S EDGE MAX WIFI
CPU Socket TypeSocket AM4
CPU TypeSupports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, 3000 G-Series, 2000 Series and 2000 G-Series desktop processors
Supports Socket AM4
ChipsetAMD X570
Memory StandardSupport dual-channel DDR4 1866/2133/2400/2667/2800/2933/3000/3066/3200/3466/3600/3733/3866/4000/4133/4266/4400/4533/4600/4733/4866/5000/5100MHz memory
Maximum Memory Supported128GB
PCI SlotsSupports PCIe 4.0 / PCIe 3.0
PCIe 4.0 is available only on AMD Ryzen™ 5000 Series and 3000 Series desktop processors
1x PCIe x16 slot (From processor)
PCI_E1 supports x16 for AMD Ryzen™ 5000 Series,5000 G-Series, 4000 G-Series, 3000 Series and 2000 Series desktop processors
PCI_E1 supports x8 for AMD Ryzen™ 2000 G-Series and 3000 G-Series desktop processors
2x PCIe x16 slots (From X570 chipset)
PCI_E3 supports x4
PCI_E4 supports 3.0 x1 only
1x PCIe 3.0 x1 slot (From X570 chipset)
SATA RAID3XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC4080 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN Chipset1x Realtek RTL8125B 2.5 Gbps LAN controller
Onboard USBAMD X570 Chipset
1x USB 3.2 Gen 2 10Gbps Type-C internal connector
4x USB 3.2 Gen 1 5Gbps ports are available through internal USB connectors
2x USB 2.0 ports on the back panel
Asmedia 1074 Chipset
4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
GL850G Hub
4x USB 2.0 ports are available through the internal USB connectors
AMD Processor
4x USB 3.2 Gen 2 10Gbps ports (3 Type-A ports and 1 Type-C port on the back panel)

Questions about this item

What PCIe generation does the X570 chipset provide and when does it cap at 4.0?

The board routes PCIe 4.0 from Ryzen 5000 or 3000 series CPUs; other supported CPUs run the primary x16 slot and M.2 interfaces at PCIe 3.0 speeds.

What physical clearance does the ATX board need for the 2.5 Gbps LAN port and audio jacks?

Standard ATX I/O shield cut-out fits the Realtek 8125B 2.5 Gbps LAN port, 7.1 audio stack and two USB 2.0 ports on the rear panel.

How is the Wi-Fi antenna attached and which step is often missed?

Screw the supplied antenna onto the gold M.2 key-E connector near the rear I/O; the step many skip is tightening the SMA connector until the antenna base sits flush.
