Black ATX motherboard with silver heatsinks and grey PCB

MSI

MSI MPG Z590 GAMING EDGE WIFI Intel motherboard

SKU CH-V1XA-5RNTQ

ATX board with LGA 1200 socket and Z590 chipset supporting 10th and 11th Gen Intel CPUs, dual-channel DDR4 up to 5333 OC and 128 GB, three PCIe x16 slots, 2.5 Gbps LAN.

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core™ Processors, 11th Gen Intel Cor
  • ChipsetIntel Z590
  • Memory StandardSupport dual channel DDR4 5333 (OC)/5200 (OC)/5000 (OC)/4800
  • Maximum Memory Supported128GB
  • PCI Slots3x PCIe x16 slots Support x16/x4/x4 PCI_E1 (From CPU) Suppor
  • Supports 10th and 11th Gen Intel Core processors on LGA 1200 socket
  • Intel Z590 chipset enables PCIe 4.0 with 11th Gen CPUs
  • Dual-channel DDR4 memory up to 128GB with OC speeds to 5333
  • 5Gbps Intel I225V LAN plus Realtek ALC4080 7.1-channel audio
  • USB 3.2 Gen2x2 20Gbps Type-C and multiple USB 3.2 Gen 2 10Gbps ports

Socket and chipset

The board uses an LGA 1200 socket paired with the Intel Z590 chipset. It accepts 10th Gen and 11th Gen Intel Core processors plus Pentium Gold and Celeron CPUs. Four DDR4 slots support up to 128 GB of memory in dual-channel mode.

PCIe lane limits

The primary PCIe x16 slot runs at 4.0 with an 11th Gen CPU and at 3.0 with a 10th Gen CPU. Two additional x16 slots operate at 3.0 from the chipset. Three M.2 interfaces and six SATA ports share the remaining chipset bandwidth.

Build and I/O

A 2.5 Gbps Intel LAN controller and a Realtek ALC4080 7.1 audio codec handle networking and sound. The rear panel includes a USB 3.2 Gen 2x2 20 Gbps Type-C port plus multiple Type-A ports. Internal headers supply further USB 3.2 Gen 1 and Gen 2 connections. The package provides the board, a CMOS battery, one SATA cable, an I/O shield and a WiFi antenna.

Highlights

  • Supports 10th and 11th Gen Intel Core processors on LGA 1200 socket
  • Intel Z590 chipset enables PCIe 4.0 with 11th Gen CPUs
  • Dual-channel DDR4 memory up to 128GB with OC speeds to 5333
  • 5Gbps Intel I225V LAN plus Realtek ALC4080 7.1-channel audio
  • USB 3.2 Gen2x2 20Gbps Type-C and multiple USB 3.2 Gen 2 10Gbps ports

Specifications

BrandMSI
SeriesMSI MPG Z590 GAMING EDGE WIFI
ModelMSI MPG Z590 GAMING EDGE WIFI
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core™ Processors, 11th Gen Intel Core™ Processors, Pentium Gold and Celeron Processors
Processor socket LGA1200
ChipsetIntel Z590
Memory StandardSupport dual channel DDR4 5333 (OC)/5200 (OC)/5000 (OC)/4800 (OC)/4600 (OC)/4533 (OC)/4400 (OC)/4300 (OC)/4266 (OC)/4200 (OC)/4133 (OC)/4000 (OC)/3866 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3300 (OC)/3200 (OC)/3000 (OC)/2933 (JEDEC)/2666 (JEDEC)/2400 (JEDEC)/2133 (JEDEC) MHz memory
Maximum Memory Supported128GB
PCI Slots3x PCIe x16 slots
Support x16/x4/x4
PCI_E1 (From CPU)
Supports up to PCIe 4.0 for 11th Gen Intel CPU
Supports up to PCIe 3.0 for 10th Gen Intel CPU
PCI_E3 & PCI_E5 (From Z590 Chipset)
Support up to PCIe 3.0
2x PCIe 3.0 x1 slots (From Z590 Chipset)
SATA RAID3XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC4080 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN Chipset1x Intel I225V 2.5Gbps LAN controller
Onboard USBIntel Z590 Chipset
1x USB3.2 Gen2x2 20Gbps port (Type-C port on the back panel)
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A port on the back panel and 2 ports are available through the internal connectors)
4x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 3 Type-A ports on the back panel)
Hub-GL850G
6x USB 2.0 ports (2 Type-A port on the back panel and 4 ports are available through the internal connectors)

Questions about this item

Which memory speed should I pick for this board?

The specifications list DDR4 speeds from 3300 up to 5333 MT/s when overclocked; choose a kit that matches your CPU's memory controller and your budget

What does the 2.5 Gbps LAN figure mean in daily use?

The Intel I225V controller provides up to 2.5 Gbps wired throughput, so large file transfers on a 2.5 Gbps switch or router will be faster than standard 1 Gbps Ethernet

Which PCIe generation does the top x16 slot actually run at?

With an 11th Gen CPU the primary slot operates at PCIe 4.0 x16; with a 10th Gen CPU it runs at PCIe 3.0 x16
