Green ATX motherboard with silver heatsinks and four black DDR5 slots

MSI

MSI PRO B760-P WIFI Intel motherboard

SKU CH-R835-J1SND MPN PRO B760-P WIFI

ATX board for Intel LGA 1700 CPUs with DDR5 memory support up to 128 GB, two M.2 slots, 2.5 GbE LAN and 7.1-channel audio

  • CPU Socket TypeLGA 1700
  • CPU TypeCeleron / Intel Core 12th Gen (LGA 1700) / Intel Core 13th G
  • ChipsetIntel B760
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardMemory Support 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(
  • Maximum Memory Supported128GB
  • Supports 12th, 13th and 14th Gen Intel CPUs on LGA 1700
  • Four DDR5 slots up to 128 GB with XMP 3.0 profiles
  • Two PCIe 4.0 x4 M.2 slots plus four SATA 6 Gb/s ports
  • 12+1 Duet Rail power with 8+4 pin CPU connectors
  • Realtek 2.5 G LAN and 7.1 channel ALC897 audio

Socket LGA 1700 DDR5 board

This ATX motherboard uses the Intel B760 chipset and accepts 12th, 13th and 14th generation Core, Pentium Gold or Celeron processors. It provides four 288-pin slots for dual-channel DDR5 up to 128 GB with XMP 3.0 support. The board targets builders who want a mainstream platform with current-generation memory.

12+1 Duet Rail power and extended heatsink

The power delivery uses a 12+1 Duet Rail design with P-PAK devices, fed by 8-pin and 4-pin CPU connectors. MOSFET pads rated at 7 W/mK and additional choke pads work with an extended heatsink to keep temperatures down during sustained loads. A six-layer PCB with 2 oz copper completes the thermal and electrical package.

Suits DDR5 upgrades with 2.5 GbE and Wi-Fi

The board fits users moving to DDR5 who need two PCIe 4.0 x4 M.2 slots, four SATA 6 Gb/s ports and 2.5 Gb Ethernet plus Wi-Fi. Audio runs through a Realtek ALC897 7.1 codec. Builds requiring more than two full-length PCIe 4.0 x16 slots or legacy PCI cards should consider other chipsets.

Highlights

  • Supports 12th, 13th and 14th Gen Intel CPUs on LGA 1700
  • Four DDR5 slots up to 128 GB with XMP 3.0 profiles
  • Two PCIe 4.0 x4 M.2 slots plus four SATA 6 Gb/s ports
  • 12+1 Duet Rail power with 8+4 pin CPU connectors
  • Realtek 2.5 G LAN and 7.1 channel ALC897 audio

Specifications

BrandMSI
ModelPRO B760-P WIFI
CPU Socket TypeLGA 1700
CPU TypeCeleron / Intel Core 12th Gen (LGA 1700) / Intel Core 13th Gen (LGA 1700) / Pentium Gold
ChipsetIntel B760
Number of Memory Slots4x288pin (DDR5)
Memory StandardMemory Support 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC)
Maximum Memory Supported128GB
Channel SupportedDual Channel
Memory Performance ProfileIntel XMP 3.0
Memory FeatureSupports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
PCI Express 4.0 x162 x PCI Express 4.0 x16
PCI Express 3.0 x163 x PCI Express 3.0 x16
PCI Slots5 x PCI Slots
Serial ATA (SATA)4 x SATA 6Gb/s
M.22 x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
* SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC897
Audio Channels7.1 Channels
LAN ChipsetRealtek® RTL8125BG 2.5G LAN
Max LAN Speed2.5Gbps
Wireless LAN802.11 a/ b/ g/ n/ ac/ ax
BluetoothBluetooth® 5.3, FIPS, FISMA
Back I/O Ports1 x DisplayPort / 1 x HDMI / 1 x LAN (RJ45) / 1 x Optical S/PDIF Out / 1 x PS/2 / 1 x USB 3.2 Gen 2 Type-C / 2 x Antenna Bracket / 2 x USB 3.2 Gen 2 Type-A / 4 x USB 2.0/1.1 / 5 x Audio Jacks
PS/21
HDMI1 x HDMI
DisplayPort1 x DisplayPort
USB 1.1/2.04 x USB 2.0
Form FactorATX
Shipping weight2.27 kg
Package size346 × 270 × 71 mm

Questions about this item

Will the 12+1 Duet Rail Power System need its MOSFET thermal pads replaced over time?

The MOSFET thermal pads are rated for 7W/mK conductivity and are designed for sustained high-performance operation without a stated replacement interval.

What limits the PCIe 4.0 x16 slots first when running a GPU continuously at full load?

The two PCIe 4.0 x16 slots connect directly to the CPU, so sustained throughput is bound by the processor's lane allocation and thermal envelope.

How loud or hot does the board get when the Realtek RTL8125BG 2.5G LAN and all four SATA 6Gb/s ports run all day?

The 6-layer PCB with 2oz copper and extended heatsinks dissipates chipset and LAN heat passively; no active cooling is fitted, so noise stays at chassis-fan level.
