Green Micro ATX motherboard with silver heatsinks and black slots

MSI

MSI PRO B760M-A DDR4 II Intel motherboard

SKU CH-SC6W-VY1X4

Micro-ATX LGA 1700 board with Intel B760 chipset supporting 12th, 13th and 14th Gen CPUs and up to 128 GB DDR5 memory

  • CPU Socket TypeLGA 1700
  • CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel P
  • ChipsetIntel B760
  • Memory StandardSupport 7800 + (OC)/7600 (OC)/7400 (OC)/7200 (OC)/7000 (OC)/
  • Maximum Memory Supported128GB
  • PCI Slots2X PCI-E x16 slots (quantity) 1X PCI-E x1 slot (quantity) PC
  • Supports Intel Core 12th 13th 14th Gen CPUs via LGA 1700 socket
  • Four DDR4 slots accept up to 128GB memory at JEDEC speeds to 5600MHz
  • Two M.2 connectors plus four SATA ports give flexible storage expansion
  • Realtek ALC897 codec delivers 7.1 channel high definition audio
  • Realtek RTL8125BG controller provides 2.5G wired networking

Socket LGA 1700 Micro-ATX Board

The MSI PRO B760M-A DDR4 II is a Micro-ATX motherboard built around the Intel B760 chipset and the LGA 1700 socket. It supports Intel Core 12th, 13th and 14th generation processors plus Pentium Gold and Celeron CPUs. The board fits compact chassis while offering four DDR4 DIMM slots for up to 128 GB of system memory.

Included SATA Cable and I/O Shield

The retail package supplies the motherboard, one SATA cable and a chassis I/O back panel. No additional brackets, Wi-Fi antennas or driver media are bundled. The single cable covers one SATA device; the shield aligns the rear ports including 2.5 GbE LAN, USB 5 Gbps Type-A, USB 10 Gbps Type-A and USB 5 Gbps Type-C connectors.

Straightforward Installation With Standard Standoffs

The board uses the standard Micro-ATX 23.6 × 20.0 cm mounting pattern, so it drops into any compatible case without adapter plates. Builders should verify CPU cooler clearance against the VRM heatsink area and confirm that the front-panel USB 5 Gbps Type-C header matches the case cable. Memory installs in the usual vertical slots; the primary PCIe 4.0 x16 slot is wired from the CPU for graphics cards.

Highlights

  • Supports Intel Core 12th 13th 14th Gen CPUs via LGA 1700 socket
  • Four DDR4 slots accept up to 128GB memory at JEDEC speeds to 5600MHz
  • Two M.2 connectors plus four SATA ports give flexible storage expansion
  • Realtek ALC897 codec delivers 7.1 channel high definition audio
  • Realtek RTL8125BG controller provides 2.5G wired networking

Specifications

BrandMSI
SeriesMSI PRO B760M-A DDR4 II
ModelMSI PRO B760M-A DDR4 II
CPU Socket TypeLGA 1700
CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors
LGA 1700
ChipsetIntel B760
Memory StandardSupport 7800 + (OC)/7600 (OC)/7400 (OC)/7200 (OC)/7000 (OC)/6800 (OC)/6600 (OC)/6400 (OC)/6200 (OC)/6000 (OC)/5800 (OC)/5600 (JEDEC)/5400 (JEDEC)/5200 (JEDEC)/5000 (JEDEC)/4800 (JEDEC) MHz
Maximum Memory Supported128GB
PCI Slots2X PCI-E x16 slots (quantity)
1X PCI-E x1 slot (quantity)
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN ChipsetRealtek RTL8125BG 2.5G LAN
Onboard USB2X USB 2.0 (rear)
4X USB 2.0 (front)
2x USB 5Gbps Type A (Rear)
4x USB 5Gbps Type A (Front)
1x USB 5Gbps Type C (Front)
2x USB 10Gbps Type A (Rear)

Questions about this item

Will the CMOS battery need replacing on this MSI PRO B760M-A DDR4 II board?

The package includes a metal battery, so the onboard CMOS cell is already present and will typically last several years before a swap is needed.

What caps the sustained throughput on the primary PCIe 4.0 x16 slot?

The PCI_E1 slot runs at PCIe 4.0 x16 from the CPU, so the lane width and generation set the ceiling for graphics or add-in cards.

How hot and loud does the Realtek RTL8125BG 2.5G LAN get under all-day load?

The controller is a low-power PHY without active cooling, so it stays quiet and only adds modest warmth inside the chassis.
