Green Micro-ATX motherboard with black LGA 1700 socket, four DDR4 slots, silver PCIe slots, rear I/O shield attached

MSI

MSI PRO B760M-E DDR4 Intel motherboard

SKU CH-X68Q-1ZP6Y

Micro-ATX board for Intel Core 12, 13 and 14 processors with LGA 1700 socket, DDR4 memory up to 64 GB and Realtek audio and LAN

  • CPU Socket TypeLGA 1700
  • CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel P
  • ChipsetIntel B760
  • Memory StandardSupports dual-channel DDR4 4800 (OC)/4600 (OC)/4400 (OC)/426
  • Maximum Memory Supported64GB
  • PCI Slots1X PCI-E x16 slots (quantity) 1X PCI-E x1 slot (quantity) PC
  • Supports Intel Core 12, 13, 14 Gen processors via LGA 1700 socket
  • Dual-channel DDR4 memory up to 64GB with speeds up to 4800 MHz
  • Micro ATX form factor measuring 23.6 by 20.0 cm
  • Realtek ALC897 codec delivers 7.1-channel high definition audio
  • Realtek RTL8111H provides Gigabit LAN connectivity

Socket LGA 1700 platform

This Micro ATX motherboard uses the Intel B760 chipset and fits Intel Core 12th, 13th and 14th generation processors along with Pentium Gold and Celeron CPUs. It targets builders who want a compact board for everyday computing or office work.

64 GB DDR4 headroom

Four slots accept dual-channel DDR4 up to 4800 MHz when overclocked, with JEDEC speeds down to 2133 MHz. The 64 GB ceiling suits mainstream multitasking and light content creation, while heavier workloads will hit the capacity limit.

Basic I/O and audio bundle

Rear ports include four USB 2.0 and two USB 5 Gbps Type A connectors; front headers add four more USB 2.0 and two USB 5 Gbps Type A. A single SATA cable and an I/O shield are supplied. Realtek ALC897 provides 7.1 channel audio and RTL8111H handles Gigabit LAN.

Highlights

  • Supports Intel Core 12, 13, 14 Gen processors via LGA 1700 socket
  • Dual-channel DDR4 memory up to 64GB with speeds up to 4800 MHz
  • Micro ATX form factor measuring 23.6 by 20.0 cm
  • Realtek ALC897 codec delivers 7.1-channel high definition audio
  • Realtek RTL8111H provides Gigabit LAN connectivity

Specifications

BrandMSI
SeriesMSI PRO B760M-E DDR4
ModelMSI PRO B760M-E DDR4
CPU Socket TypeLGA 1700
CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors
LGA 1700
ChipsetIntel B760
Memory StandardSupports dual-channel DDR4 4800 (OC)/4600 (OC)/4400 (OC)/4266 (OC)/4200 (OC)/4000 (OC)/3800 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3200 (JEDEC)/2933 (JEDEC)/2666 (JEDEC)/2400 (JEDEC)/2133 (JEDEC) MHz memory
Maximum Memory Supported64GB
PCI Slots1X PCI-E x16 slots (quantity)
1X PCI-E x1 slot (quantity)
PCI_E1 Gen PCIe 4.0 supports up to (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to (From Chipset)
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN ChipsetRealtek RTL8111H Gigabit LAN
Onboard USB4X USB 2.0 (rear)
4X USB 2.0 (front)
2x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
