Green micro-ATX board with silver CPU socket and four black DDR4 slots

MSI

MSI PRO B760M-G DDR4 Intel motherboard

SKU CH-BCHF-VMJ44

Micro ATX board with LGA 1700 socket supports Intel 12, 13 and 14 gen CPUs, dual-channel DDR4 up to 64 GB, 2.5 Gbps LAN, 7.1 audio and PCIe 4.0 slots

  • CPU Socket TypeLGA 1700
  • CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel P
  • ChipsetIntel B760
  • Memory StandardSupports dual-channel DDR4 4800 (OC)/4600 (OC)/4400 (OC)/426
  • Maximum Memory Supported64GB
  • PCI Slots1X PCI-E x16 slots (quantity) 1X PCI-E x1 slot (quantity) PC
  • Supports Intel Core 12 13 14 Gen processors via LGA 1700 socket
  • Dual-channel DDR4 up to 4800 MHz overclocked with 64 GB maximum capacity
  • Intel B760 chipset provides PCIe 4.0 on primary x16 and x1 slots
  • Realtek ALC897 codec delivers 7.1-channel high definition audio
  • Realtek RTL8125B controller enables 2.5 Gbps LAN connectivity

Socket & generation match

This motherboard uses the LGA 1700 socket and Intel B760 chipset. It supports Intel Core 12, 13 and 14 generation processors plus Pentium Gold and Celeron CPUs. The Micro ATX form factor fits smaller chassis while keeping essential connectivity.

Memory ceiling

Maximum supported capacity is 64 GB across dual-channel DDR4 slots. JEDEC speeds run from 2133 to 3200 MHz and a long list of overclocked steps reaches 4800 MHz. Buyers must choose DDR4 modules; no other memory type is compatible.

Expansion & I/O layout

One PCIe 4.0 x16 slot from the CPU and one PCIe 4.0 x1 slot from the chipset handle graphics and add-in cards. Storage uses two M.2 interfaces and four SATA ports. Rear I/O provides four USB 5 Gbps Type-A ports and two USB 2.0 ports; front headers add two more USB 5 Gbps and four USB 2.0 connections. Realtek 2.5 Gbps LAN and 7.1-channel audio complete the build.

Highlights

  • Supports Intel Core 12 13 14 Gen processors via LGA 1700 socket
  • Dual-channel DDR4 up to 4800 MHz overclocked with 64 GB maximum capacity
  • Intel B760 chipset provides PCIe 4.0 on primary x16 and x1 slots
  • Realtek ALC897 codec delivers 7.1-channel high definition audio
  • Realtek RTL8125B controller enables 2.5 Gbps LAN connectivity

Specifications

BrandMSI
SeriesMSI PRO B760M-G DDR4
ModelMSI PRO B760M-G DDR4
CPU Socket TypeLGA 1700
CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors
LGA 1700
ChipsetIntel B760
Memory StandardSupports dual-channel DDR4 4800 (OC)/4600 (OC)/4400 (OC)/4266 (OC)/4200 (OC)/4000 (OC)/3800 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3200 (JEDEC)/2933 (JEDEC)/2666 (JEDEC)/2400 (JEDEC)/2133 (JEDEC) MHz memory
Maximum Memory Supported64GB
PCI Slots1X PCI-E x16 slots (quantity)
1X PCI-E x1 slot (quantity)
PCI_E1 Gen PCIe 4.0 supports up to (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to (From Chipset)
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN ChipsetRealtek RTL8125B 2.5Gbps LAN
Onboard USB2X USB 2.0 (rear)
4X USB 2.0 (front)
4x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)

Questions about this item

What does the 64 GB maximum memory mean for a system built on this board?

The board supports up to 64 GB of dual-channel DDR4 across its slots, so a four-module kit totalling 64 GB will run at the highest JEDEC or overclocked speed the modules and CPU allow.

How does the PCIe 4.0 interface affect the single x16 slot and the x1 slot?

The top x16 slot is wired to the CPU and runs at PCIe 4.0, while the x1 slot comes from the B760 chipset and also runs at PCIe 4.0, capping both at 4.0 bandwidth.

What clearance does the Micro ATX form factor need inside a case?

A standard Micro ATX chassis with the correct standoff pattern and I/O shield cut-out will fit this board; the rear panel includes 2.5 Gbps LAN, 7.1 audio and multiple USB 5 Gbps ports.
