Green mATX motherboard with silver heatsinks and black PCIe slots

MSI

MSI PRO B760M-G ProSeries Intel motherboard

SKU CH-0YVJ-DPZ1G

Micro-ATX board for 12th and 13th Gen Intel Core CPUs with DDR4, PCIe 4.0, 2.5G LAN and dual M.2 slots

  • CPU TypeIntel Core 13th Gen (LGA 1700)
  • Supports 12th and 13th Gen Intel Core processors on LGA 1700 socket
  • Dual-channel DDR4 memory up to 4800 MHz overclocked for faster responsiveness
  • PCIe 4.0 x4 M.2 slot with Shield Frozr enables high-speed storage
  • 5G LAN provides stable wired networking for professional use
  • Steel Armor protects graphics cards from bending and EMI interference

Micro-ATX Intel B760 motherboard for 12th

The MSI PRO B760M-G ProSeries board uses the Intel B760 chipset and an LGA 1700 socket to support 12th and 13th Gen Intel Core, Pentium Gold and Celeron processors. It provides two DDR4 slots with dual-channel architecture and a maximum capacity of 64 GB. Overclocked memory speeds up to 4800+ MHz are supported on a single-rank DIMM.

Suited for compact builds using existing DDR4 memory

This board fits micro-ATX cases and lets builders reuse DDR4 modules while gaining PCIe 4.0 connectivity for graphics and storage. It is not for systems that require four memory slots to reach capacities above 64 GB or that need more than one full-length PCIe x16 slot for multiple graphics cards.

Single PCIe 4.0 x16 slot from the CPU

The top expansion slot runs at PCIe 4.0 x16 directly from the processor and is reinforced with Steel Armor. A second x1 slot is also wired to the chipset at PCIe 4.0, so only one high-bandwidth add-in card can be installed.

Highlights

  • Supports 12th and 13th Gen Intel Core processors on LGA 1700 socket
  • Dual-channel DDR4 memory up to 4800 MHz overclocked for faster responsiveness
  • PCIe 4.0 x4 M.2 slot with Shield Frozr enables high-speed storage
  • 5G LAN provides stable wired networking for professional use
  • Steel Armor protects graphics cards from bending and EMI interference

Specifications

CPU TypeIntel Core 13th Gen (LGA 1700)

Questions about this item

What DDR4 memory speed does the board support for a single-rank module in one slot?

The board supports DDR4 up to 4800+ MHz for a single-rank module in one slot.

Will a PCIe 4.0 graphics card work in the x16 slot if I keep an older PCIe 3.0 card in the x1 slot?

The x16 slot runs at PCIe 4.0 from the CPU and the x1 slot runs at PCIe 4.0 from the chipset, so both cards will operate at their respective supported speeds.

How can I confirm the M.2 drive is running at PCIe 4.0 x4 after installation?

Check the BIOS or operating-system device manager to verify the M.2_1 slot reports a PCIe 4.0 x4 link width.
