Green micro ATX motherboard with silver LGA 1700 socket and black heatsinks

MSI

MSI PRO B760M-P DDR4 Intel B760 LGA 1700 Micro ATX Motherboard

SKU CH-X0DS-ZB4BC

Micro ATX board for Intel Core 12, 13 and 14 generation processors with dual-channel DDR4 up to 128GB and 7.1 audio

  • CPU Socket TypeLGA 1700
  • CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel P
  • ChipsetIntel B760
  • Memory StandardSupports dual-channel DDR4 4800 (OC)/4600 (OC)/4400 (OC)/426
  • Maximum Memory Supported128GB
  • PCI Slots1X PCI-E x16 slots (quantity) 2X PCI-E x1 slots (quantity) P
  • Supports Intel Core 14th 13th 12th Gen CPUs via LGA 1700 socket
  • Dual-channel DDR4 up to 4800 OC and 128GB capacity for heavy multitasking
  • PCIe 4.0 x16 from CPU plus two x1 slots for graphics and add-in cards
  • Realtek ALC897 7.1-channel audio with Gigabit LAN for clear sound and wired networking
  • Rear USB 10Gbps Type C plus multiple 5Gbps and 2.0 ports for fast peripheral connections

Built for LGA 1700 DDR4 Systems

This micro-ATX motherboard uses the Intel B760 chipset and LGA 1700 socket to support Intel Core 12th, 13th and 14th generation processors alongside Pentium Gold and Celeron CPUs. It targets builders who want a compact platform with modern connectivity while keeping existing DDR4 memory kits.

128 GB DDR4 Capacity with Broad Frequency Range

Four DIMM slots accept up to 128 GB of dual-channel DDR4 running at JEDEC speeds from 2133 to 3200 MHz and overclocked steps up to 4800 MHz. Headroom is generous for multitasking and content workloads, while the top OC ceiling marks the practical limit for memory scaling.

Micro-ATX Layout with PCIe 4.0 and Fast USB

The board fits micro-ATX cases and provides one CPU-linked PCIe 4.0 x16 slot plus two chipset-linked PCIe 4.0 x1 slots for expansion. Rear I/O includes USB 10 Gbps Type-C, USB 5 Gbps Type-A, four USB 2.0 ports and Realtek Gigabit LAN, while front headers add four more USB 2.0 and two USB 5 Gbps Type-A connections.

Highlights

  • Supports Intel Core 14th 13th 12th Gen CPUs via LGA 1700 socket
  • Dual-channel DDR4 up to 4800 OC and 128GB capacity for heavy multitasking
  • PCIe 4.0 x16 from CPU plus two x1 slots for graphics and add-in cards
  • Realtek ALC897 7.1-channel audio with Gigabit LAN for clear sound and wired networking
  • Rear USB 10Gbps Type C plus multiple 5Gbps and 2.0 ports for fast peripheral connections

Specifications

BrandMSI
SeriesMSI PRO B760M-P DDR4
ModelMSI PRO B760M-P DDR4
CPU Socket TypeLGA 1700
CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors
LGA 1700
ChipsetIntel B760
Memory StandardSupports dual-channel DDR4 4800 (OC)/4600 (OC)/4400 (OC)/4266 (OC)/4200 (OC)/4000 (OC)/3800 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3200 (JEDEC)/2933 (JEDEC)/2666 (JEDEC)/2400 (JEDEC)/2133 (JEDEC) MHz memory
Maximum Memory Supported128GB
PCI Slots1X PCI-E x16 slots (quantity)
2X PCI-E x1 slots (quantity)
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset)
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN ChipsetRealtek RTL8111H Gigabit LAN
Onboard USB4X USB 2.0 (rear)
4X USB 2.0 (front)
1x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
1x USB 10Gbps Type C (Rear)

Questions about this item

Will my existing DDR4-3200 memory work with the PRO B760M-P DDR4 board?

Yes, the motherboard supports JEDEC DDR4-3200 out of the box and can run faster kits up to DDR4-4800 when overclocked.

How can I confirm the Realtek ALC897 7.1 audio is active after building?

Open Windows Sound settings, select the Realtek device, and verify 7.1-channel is listed; play a test tone to hear all eight channels.

Does the box include Wi-Fi antennas or must I buy them separately?

The package contains the motherboard, CMOS battery, one SATA cable, and the I/O shield; no Wi-Fi antenna is supplied because the board has no onboard Wi-Fi module.
