Green Micro ATX motherboard with silver LGA 1700 socket, two black DDR5 slots, single PCIe x16 slot, four SATA ports

MSI

MSI PRO H610M-G WIFI Micro ATX Intel motherboard

SKU CH-256M-JTF88

Supports 12th, 13th and 14th Gen Intel CPUs on LGA 1700 with dual-channel DDR5-5600, one M.2 Gen3 x4 slot, four SATA 6Gb/s ports, Wi-Fi 6E and Bluetooth 5.3

  • CPU Socket TypeLGA 1700
  • CPU TypeIntel® Pentium® Gold and Celeron® Processors
  • ChipsetIntel H610
  • Number of Memory Slots2x288pin (DDR5)
  • Memory StandardDDR5-5600MHz (MAX)
  • Maximum Memory Supported64GB
  • Supports Intel Core 12 13 14 Gen and Pentium Gold Celeron processors via LGA 1700 socket
  • Dual channel DDR5 5600MHz memory up to 64GB across two 288pin slots
  • One M.2 Gen3 x4 slot delivering 32Gbps bandwidth for fast storage
  • Four SATA 6Gb/s ports plus Intel I219-V 1G LAN for wired networking
  • Wi-Fi 6E and Bluetooth 5.3 with 8-Channel 7.1 HD Audio Boost built in

LGA 1700 DDR5 Micro ATX Board

The MSI PRO H610M-G WIFI is a Micro ATX motherboard built on the Intel H610 chipset for LGA 1700 processors. It supports 12th 13th and 14th Gen Core CPUs as well as Pentium Gold and Celeron models. Two 288-pin DDR5 slots run dual channel at up to 5600MHz with a 64GB maximum capacity.

Who Should Choose This

Builders wanting a compact board with integrated Wi-Fi 6E and Bluetooth 5.3 for general desktop use will find the essentials covered. The single PCI Express 4.0 x16 slot handles one graphics card while two legacy PCI slots remain for older add-in cards. Users needing multiple M.2 drives or more than four SATA ports should consider a different platform.

M.2 Storage Constraint

Only one M.2 Key M slot is provided wired for PCIe 3.0 x4 at 32Gbps and it also supports SATA mode. A second Key E slot is reserved for the wireless module so no additional M.2 storage can be added.

Highlights

  • Supports Intel Core 12 13 14 Gen and Pentium Gold Celeron processors via LGA 1700 socket
  • Dual channel DDR5 5600MHz memory up to 64GB across two 288pin slots
  • One M.2 Gen3 x4 slot delivering 32Gbps bandwidth for fast storage
  • Four SATA 6Gb/s ports plus Intel I219-V 1G LAN for wired networking
  • Wi-Fi 6E and Bluetooth 5.3 with 8-Channel 7.1 HD Audio Boost built in

Specifications

BrandMSI
ModelPRO H610M-G WIFI
Part NumberPRO H610M-G WIFI
CPU Socket TypeLGA 1700
CPU TypeIntel® Pentium® Gold and Celeron® Processors
ChipsetIntel H610
Number of Memory Slots2x288pin (DDR5)
Memory StandardDDR5-5600MHz (MAX)
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express x11x PCIe 3.0 x1 slot
PCI Slots2 x PCI Slots
Serial ATA (SATA)4 x SATA 6Gb/s
M.21xKey M(PCIe/SATA)+ 1x Key E(WiFi/BT)
Audio Channels8-Channel(7.1) HD Audio with Audio Boost
LAN ChipsetIntel®
I219-V 1G LAN
Max LAN SpeedWi-Fi 6E
BluetoothBluetooth 5.3
PS/21 x PS/2 keyboard/mouse port
Video PortsVGA
HDMISupport 4K@60Hz as specified in HDMITM 2.1
RJ451 x RJ45
DisplayPortDisplayPort 1.4, VGA – Requires Processor Graphics
USB 3.12x USB 3.2 Gen 1 5Gbps Type-A
USB 1.1/2.04 x USB 2.0
Audio Ports3 Ports
Onboard USB2x USB 3.2 Gen 1 5Gbps(4 Type-A)
2 x USB 2.0
Form FactorMicro ATX

Questions about this item

What DDR5 memory speed must I already have for the board to run at its 5600MHz maximum?

Install DDR5 modules rated for 5600MHz; the two 288-pin slots run in dual-channel mode up to that speed and support a total of 64GB.

Will my existing SATA 6Gb/s drives and PCIe 3.0 x1 add-in cards work with the four SATA ports and the single PCIe 3.0 x1 slot?

Yes, the four SATA 6Gb/s ports and the PCIe 3.0 x1 slot accept current SATA SSDs, hard drives and PCIe 3.0 x1 cards without adapters.

How can I confirm the Wi-Fi 6E and Bluetooth 5.3 radios are active after the build?

In Windows Device Manager the Intel Wi-Fi 6E adapter and Bluetooth 5.3 radio should appear without error codes, and the board’s antenna connectors will show a live connection to your router.
