Green micro-ATX board with black slots, silver heatsinks and rear I/O shield

MSI

MSI PRO H610M-S WIFI DDR4 LGA 1700 Intel Motherboard

SKU CH-HHPT-BYNFT

Micro-ATX board for 12th, 13th and 14th generation Intel Core, Pentium Gold and Celeron processors with DDR4 memory up to 3200 MHz, PCIe 4.0 graphics slot, Wi-Fi 6E and 7.1-channel audio

  • Supports 12th, 13th and 14th generation Intel Core processors via LGA 1700 socket
  • DDR4 memory up to 3200 MHz on two slots with 64 GB maximum capacity
  • Core Boost Engine uses advanced layout and digital power design for multi-core stability
  • Wi-Fi 6E wireless network plus Realtek RTL8111H Gigabit LAN for flexible connectivity
  • PCIe 4.0 x16 slot from CPU and PCIe 3.0 x4 M.2 from chipset for modern expansion

Entry micro-ATX board for Intel LGA 1700 builds

The MSI PRO H610M-S WIFI DDR4 fits micro-ATX cases and accepts 12th, 13th and 14th generation Intel Core, Pentium Gold and Celeron CPUs on the LGA 1700 socket. Two DDR4 slots support up to 64 GB at JEDEC speeds from 1866 to 3200 MHz in dual-channel mode. A single M.2 slot from the chipset runs at PCIe 3.0 x4 for 2280, 2260 or 2242 devices, while two SATA 6G ports handle additional drives.

Thermals, noise and power in daily use

The H610 chipset and Core Boost power layout keep the voltage regulators cool under typical office or home workloads, so the CPU fan header and one system fan header can run at low speeds for quiet operation. An 8-pin CPU power connector and 24-pin ATX connector deliver stable current without demanding a high-wattage supply. Realtek RTL8111H Gigabit LAN and Wi-Fi 6E add network connectivity without extra add-in cards that would increase chassis airflow requirements.

Build quality, connectors and mounting reality

The board uses a Realtek ALC897 codec for 7.1-channel HD audio and provides HDMI 1.4 output at up to 4K 30 Hz when the processor includes integrated graphics. Rear I/O includes four USB 2.0 ports, two USB 5 Gbps Type-A ports, HDMI and LAN. Front-panel headers add four more USB 2.0 ports, two USB 5 Gbps Type-A ports, audio, power, reset, chassis intrusion and a COM port. Expansion consists of one PCIe 4.0 x16 slot from the CPU and one PCIe 3.0 x1 slot from the chipset.

Highlights

  • Supports 12th, 13th and 14th generation Intel Core processors via LGA 1700 socket
  • DDR4 memory up to 3200 MHz on two slots with 64 GB maximum capacity
  • Core Boost Engine uses advanced layout and digital power design for multi-core stability
  • Wi-Fi 6E wireless network plus Realtek RTL8111H Gigabit LAN for flexible connectivity
  • PCIe 4.0 x16 slot from CPU and PCIe 3.0 x4 M.2 from chipset for modern expansion

Specifications

No published specifications for this item yet.

Questions about this item

How do I install the CPU onto the LGA 1700 socket and what step is often missed?

Align the processor notches with the socket keys, lower the retention lever fully, and install the cooler; the step often missed is checking the MSI support site for a BIOS update before booting with 14th generation Intel Core processors.

What maintenance will the DDR4 memory slots need over time?

The two DDR4 slots support up to 64 GB at speeds from 1866 to 3200 MHz; keep the contacts dust-free with compressed air and reseat modules only if the system fails to post.

What thermal limit appears first on the PCIe 4.0 x16 slot during sustained heavy GPU loads?

The PCI_E1 slot runs at PCIe 4.0 x16 from the CPU; its performance ceiling under load is the graphics card's own thermal throttling point, not the motherboard lane bandwidth.
