Green ATX motherboard with silver heatsinks, eight DDR4 slots, four PCIe 3.0 x16 slots, LGA 2066 socket, six SATA ports

MSI

MSI PRO X299 PRO LGA 2066 Intel motherboard

SKU CH-4RB1-HR7RN

ATX board for LGA 2066 Intel Core X-series CPUs with eight DDR4 slots, four PCIe 3.0 x16 slots, six SATA ports and two M.2 slots

  • CPU Socket TypeLGA 2066
  • CPU TypeSupports Intel Core X-series 10000/9000/78xx (above) process
  • ChipsetIntel X299
  • Onboard Video ChipsetNone
  • Number of Memory Slots8x288pin (DDR4)
  • Memory StandardSupports DDR4 4200+(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(
  • Supports Intel Core X-series 10000/9000/78xx processors for LGA 2066 socket
  • 8 DDR4 slots deliver up to 256 GB quad-channel memory capacity
  • 4 PCIe 3.0 x16 slots scale from x16/x8/x16/x8 with 48-lane CPUs
  • Dual M.2 slots accept 2242/2260/2280/22110 drives at PCIe 3.0 x4 or SATA 6Gb/s
  • Dual LAN with Intel I219V and Realtek 8125-CG plus Realtek ALC1220 7.1 audio

Intel X299 chipset for Core X-series

This MSI PRO X299 PRO motherboard uses the Intel X299 chipset and LGA 2066 socket to support Intel Core X-series 10000, 9000 and 78xx processors. It provides eight DDR4 memory slots in a quad-channel layout with a maximum capacity of 256 GB. The ATX form factor fits standard workstation cases.

Sustained multi-GPU and storage bandwidth

Four PCIe 3.0 x16 slots operate at x16/x8/x16/x8 with a 48-lane CPU, x16/x4/x16/x8 with a 44-lane CPU, and x16/x4/x8/x0 with a 28-lane CPU. Two M.2 Key M slots accept 2242, 2260, 2280 and 22110 devices at PCIe 3.0 x4 or SATA 6Gb/s. Six SATA 6Gb/s ports support RAID 0, 1, 5 and 10, though SATA1 is disabled when a SATA M.2 drive occupies M2_1.

Dual LAN and high-definition audio

Networking combines a Realtek RTL8125-CG controller with an Intel I219V PHY. Audio uses the Realtek ALC1220 codec for 7.1-channel output with S/PDIF. The board has no onboard video, so a discrete graphics card is required. Only the motherboard and I/O shield are included.

Highlights

  • Supports Intel Core X-series 10000/9000/78xx processors for LGA 2066 socket
  • 8 DDR4 slots deliver up to 256 GB quad-channel memory capacity
  • 4 PCIe 3.0 x16 slots scale from x16/x8/x16/x8 with 48-lane CPUs
  • Dual M.2 slots accept 2242/2260/2280/22110 drives at PCIe 3.0 x4 or SATA 6Gb/s
  • Dual LAN with Intel I219V and Realtek 8125-CG plus Realtek ALC1220 7.1 audio

Specifications

BrandMSI
SeriesPRO
ModelX299 PRO
CPU Socket TypeLGA 2066
CPU TypeSupports Intel Core X-series 10000/9000/78xx (above) processors for socket LGA2066
ChipsetIntel X299
Onboard Video ChipsetNone
Number of Memory Slots8x288pin (DDR4)
Memory StandardSupports DDR4 4200+(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2933/ 2666/ 2400/ 2133 MHz
* For the latest information about memory, please visit http://www.msi.com
Maximum Memory Supported256GB
Channel SupportedQuad Channel
PCI Express 3.0 x164 x PCIe 3.0 x16 slots
Support x16/x8/x16/x8 mode with the 48-lane CPU.
Support x16/x4/x16/x8 mode with the 44-lane CPU.
Support x16/x4/x8/x0 mode with the 28-lane CPU.
Serial ATA (SATA)6 x SATA 6Gb/s ports
* The SATA1 connector will be unavailable when a SATA M.2 SSD has been installed in the M2_1 slot.
M.22 x M.2 slot (Key M)
Support up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/2260/2280/22110 storage devices*
* The M2_2 default setting is CPU lane. However, when a PCIe expansion card is installed in the PCI_E2 slot, the M2_2 will be automatically switched to PCH lane.
* The SATA2 connector will be unavailable when M2_2 uses PCH lanes and a M.2 SATA SSD is installed in the M2_2 slot.
Intel Optane ReadyIntel Optane Memory Ready*
* M2_2 supports Intel Optane Memory by switching to PCH lanes.
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC1220
Audio Channels7.1-Channel High Definition Audio
Supports S/PDIF output
LAN ChipsetRealtek RTL8125-CG
Second LAN ChipsetIntel I219V
* I219 LAN doesn't support G3 to S5 Wake
Max LAN Speed2.5Gbps + 1Gbps
Onboard USB2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
2 x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports)
1 x USB 3.2 Gen2 Type-C port
Other Connectors1 x 4-pin CPU fan connector
1 x 4-pin Water Pump connector
4 x 4-pin system fan connectors
1 x Front panel audio connector
2 x System panel connectors
1 x TPM module connector
1 x Chassis Intrusion connector
1 x Virtual RAID on CPU connector
1 x Thunderbolt Add-on Card Connector
Form FactorATX
Dimensions (W x L)12.0" x 9.6"
Power Pin1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
FeaturesSupports Intel Core X-series Processors 10000/9000/78xx (above) series for LGA2066 Socket.
Supports DDR4 Memory, 8 DIMMs, Quad Channel Max Frequency DDR4-4200+(OC).
Lightning USB 20G: Powered by ASMedia ASM3242 USB 3.2 Gen2x2 controller, offers the fastest USB speeds with stability.
Twin Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
Set Core Power Free: Core Boost, 2x8-pin CPU power connector, Core Boost, DDR4 Boost.
Extended Heatsink Design: MSI extended PWM and enhanced circuit design ensures even high-end processors to run in full speed.
Dual LAN:

Questions about this item

Which Intel Core X-series processors are supported?

The board supports Core X-series 10000, 9000 and 78xx processors for the LGA 2066 socket.

How many DDR4 memory slots are available and what is the maximum capacity?

There are eight 288-pin DDR4 slots with a maximum supported capacity of 256 GB.

What happens to the M.2_2 slot when a card is installed in the PCI_E2 slot?

When a PCIe expansion card occupies PCI_E2, the M.2_2 slot switches from CPU lanes to PCH lanes.
