Green printed circuit board with black controller and memory chips in M.2 2280 stick form factor

MSI

MSI SPATIUM M480 PCIe 4.0 NVMe M.2 1TB internal SSD

SKU CH-ZN16-3BCZ0 MPN SPATIUM M480 PCIe 4.0 NVMe M.2 1TB

1TB PCIe 4.0 NVMe M.2 drive with 7000 MB/s reads, 5500 MB/s writes and 700 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D NAND
  • InterfacePCIe Gen4x4, NVMe 1.4
  • Sequential reads up to 7000 MBps accelerate large-file transfers
  • Sequential writes up to 5500 MBps speed up content creation workflows
  • 350,000 random read IOPS deliver snappy OS responsiveness
  • 700 TBW endurance rating supports heavy daily workloads
  • 6 million hour MTBF indicates long-term drive reliability

1TB PCIe 4.0 NVMe drive

The SPATIUM M480 is a 1TB internal SSD that uses a PCIe Gen4x4 interface and the NVMe 1.4 protocol. It is built around a PHISON E18 controller paired with 1GB of DDR4 cache and 3D NAND flash. The M.2 2280 form factor fits both desktop and notebook platforms.

Suits builds that need fast sequential throughput

The 7000 MBps read and 5500 MBps write speeds benefit large-file workflows, game installs and OS responsiveness. Random performance reaches 350000 read IOPS and 700000 write IOPS. The drive ships without a heatsink, so systems with tight M.2 clearance or limited airflow should verify thermal headroom before purchase.

Sustained write endurance rated at 700 TBW

The 700 terabytes written rating and 1600000 hour MTBF reflect long-term reliability under continuous workloads. LDPC error correction and end-to-end data path protection maintain data integrity during extended write sessions. TRIM and APST support help the controller manage performance consistency over time.

Highlights

  • Sequential reads up to 7000 MBps accelerate large-file transfers
  • Sequential writes up to 5500 MBps speed up content creation workflows
  • 350,000 random read IOPS deliver snappy OS responsiveness
  • 700 TBW endurance rating supports heavy daily workloads
  • 6 million hour MTBF indicates long-term drive reliability

Specifications

BrandMSI
SeriesSPATIUM Series
ModelM480
Part NumberSM480N1TB
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D NAND
InterfacePCIe Gen4x4, NVMe 1.4
ControllerPHISON E18
Cache1GB DDR4
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 5500 MBps
4KB Random ReadUp to 350,000 IOPS
4KB Random WriteUp to 700,000 IOPS
Terabytes Written (TBW)700TB
MTBF1,600,000 hours
HeatSinkwithout HeatSink
FeaturesTRIM (Performance Optimization, OS support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
AES256/TCG OPAL2.0/Pyrite (Encryption, Data Security)
Power Consumption (Idle)14 mW
Power Consumption (Active)6.6W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Height2.15mm
Width22.00mm
Depth80.00mm
Shipping weight0.05 kg
Package size159 × 83 × 18 mm
