Green printed circuit board M.2 2280 SSD with black controller and memory chips

MSI

MSI SPATIUM M480 PCIe 4.0 NVMe M.2 2TB internal SSD

SKU CH-2RET-DXFJP MPN SPATIUM M480 PCIe 4.0 NVMe M.2 2TB

A 2 TB PCIe 4.0 NVMe drive delivering 7000 MB/s reads and 6800 MB/s writes with 1400 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D NAND
  • InterfacePCIe Gen4x4, NVMe 1.4
  • PCIe Gen4x4 interface delivers sequential reads up to 7000 MB/s
  • Sequential writes up to 6800 MB/s accelerate large-file transfers
  • 4KB random reads up to 650,000 IOPS sharpen OS responsiveness
  • 4KB random writes up to 700,000 IOPS sustain heavy workloads
  • 1400 TBW endurance rating supports long-term reliability

Capacity and form factor

The MSI SPATIUM M480 is a 2TB internal solid state drive built in the M.2 2280 form factor. It targets consumer desktops and notebooks that need high-capacity storage for games, media and heavy workloads.

PCIe Gen4x4 NVMe 1.4 interface

The drive connects through a PCIe Gen4x4 link and complies with the NVMe 1.4 specification. This single interface choice determines whether the host platform can deliver the rated 7000 MBps read and 6800 MBps write throughput.

Sustained operation with 2GB DDR4 cache

A 2GB DDR4 cache and the PHISON E18 controller absorb write bursts before flushing to 3D NAND, keeping performance stable during long transfers. End-to-end data path protection and LDPC error correction maintain data integrity across the 1400 TBW endurance rating.

Highlights

  • PCIe Gen4x4 interface delivers sequential reads up to 7000 MB/s
  • Sequential writes up to 6800 MB/s accelerate large-file transfers
  • 4KB random reads up to 650,000 IOPS sharpen OS responsiveness
  • 4KB random writes up to 700,000 IOPS sustain heavy workloads
  • 1400 TBW endurance rating supports long-term reliability

Specifications

BrandMSI
SeriesSPATIUM Series
ModelM480
Part NumberSM480N2TB
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D NAND
InterfacePCIe Gen4x4, NVMe 1.4
ControllerPHISON E18
Cache2GB DDR4
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 6800 MBps
4KB Random ReadUp to 650,000 IOPS
4KB Random WriteUp to 700,000 IOPS
Terabytes Written (TBW)1400TB
MTBF1,600,000 hours
HeatSinkwithout HeatSink
FeaturesTRIM (Performance Optimization, OS support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
AES256/TCG OPAL2.0/Pyrite (Encryption, Data Security)
Power Consumption (Idle)22 mW
Power Consumption (Active)8.2W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Height2.15mm
Width22.00mm
Depth80.00mm
Shipping weight0.05 kg
Package size159 × 83 × 18 mm

Questions about this item

What does the 7000 MBps sequential read mean once the drive is installed?

The drive can move large files at up to 7000 MBps when the host supports PCIe Gen4x4 and NVMe 1.4, though actual throughput depends on the system configuration.

How does the PCIe Gen4x4 interface limit performance in practice?

The four-lane Gen4 link caps bandwidth at the rated 7000 MBps read and 6800 MBps write; a Gen3 slot would restrict speeds to that generation's ceiling.

What physical slot and clearance does the M.2 2280 form factor need?

It fits a standard M.2 2280 key-M slot on desktop or notebook motherboards and requires no heatsink clearance because the drive ships without one.
