Black ATX motherboard with carbon-fiber pattern, red accents, AM4 socket, four DDR4 slots, three PCIe x16 slots, M.2 heatshields

MSI

MSI X370 GAMING PRO CARBON AMD motherboard

SKU CH-5SJ5-XXK2X

AM4 board with X370 chipset runs first- and second-gen Ryzen, takes 64 GB DDR4 up to 3200 MHz, dual x16 PCIe 3.0 slots, six SATA III ports, Realtek ALC1220 7.1 audio, Intel I211AT Gigabit LAN.

  • CPU Socket TypeSocket AM4
  • CPU TypeFirst and second generation AMD Ryzen ™ with AM4 pins/Ryzen
  • ChipsetAMD X370
  • Memory StandardSupports dual-channel DDR4 1866/2133/2400/2667 (OC)/2933 (OC
  • Maximum Memory Supported64GB
  • PCI Slots2 PCIe 3.0 x16 slots (PCIE_2, PCIE_4) - RYZEN series process
  • Supports dual-channel DDR4 up to 3200 MHz for responsive multitasking
  • AMD X370 chipset enables overclocking headroom for Ryzen processors
  • Realtek ALC1220 codec delivers 7.1 channel high-definition audio
  • Intel I211AT controller provides reliable Gigabit LAN connectivity
  • USB 3.1 Gen2 Type-C and Type-A ports supply 10 Gbps bandwidth

Socket AM4 Ryzen Platform

This ATX motherboard pairs first- and second-generation Ryzen processors with the AMD X370 chipset. It is aimed at builders who want a full-size board for gaming or workstation tasks.

64GB Dual-Channel DDR4 Limit

Four slots accept DDR4 modules at 1866, 2133, 2400, 2667, 2933 or 3200 MHz, with overclocked speeds supported. The ceiling is 64GB total, so memory capacity is fixed by this specification.

Two PCIe 3.0 x16 Slots Plus Storage

The board provides two full-length PCIe 3.0 x16 slots that run at x16/x0 or x8/x8 with Ryzen CPUs. Six SATA III ports and two M.2 interfaces handle drives, while a single Intel I211AT Gigabit LAN port and 7.1-channel Realtek ALC1220 audio complete the I/O.

Highlights

  • Supports dual-channel DDR4 up to 3200 MHz for responsive multitasking
  • AMD X370 chipset enables overclocking headroom for Ryzen processors
  • Realtek ALC1220 codec delivers 7.1 channel high-definition audio
  • Intel I211AT controller provides reliable Gigabit LAN connectivity
  • USB 3.1 Gen2 Type-C and Type-A ports supply 10 Gbps bandwidth

Specifications

BrandMSI
SeriesMSI X370 GAMING PRO CARBON
ModelMSI X370 GAMING PRO CARBON
CPU Socket TypeSocket AM4
CPU TypeFirst and second generation AMD Ryzen ™ with AM4 pins/Ryzen ™ processors with Radeon ™ Vega graphics and AMD A series/Ryzen ™ processors
ChipsetAMD X370
Memory StandardSupports dual-channel DDR4 1866/2133/2400/2667 (OC)/2933 (OC)/3200 (OC) MHz memory
Maximum Memory Supported64GB
PCI Slots2 PCIe 3.0 x16 slots (PCIE_2, PCIE_4)
- RYZEN series processors support x16/x0, x8/x8 modes
- 7th generation A-series/Athlon ™ processors support x8/x0 modes
1 PCIe 2.0 x16 slot (PCIE_6, x4 mode supported) *
3 PCIe 2.0 x1 slots
SATA RAID2XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC1220 decoding chip
- 7.1 channel high-quality sound effects
- Supports S/PDIF output
LAN Chipset1 Intel I211AT Gigabit network interface card
Onboard USBASMedia ASM2142 Chipset
- 1 USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C interface located on the backplane
- 1 USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A interface located on the backplane
AMD X370 chipset
- 4 USB 3.1 Gen1 (SuperSpeed USB) ports are provided via the onboard USB 3.1 Gen1 port
- 6 USB 2.0 (High-speed USB) ports (2 Type-A ports on the backplane, 4 ports provided via onboard USB 2.0 ports)
AMD CPU
- 4 USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the back panel

Questions about this item

What does the 3200 MHz DDR4 memory rating mean when I install modules on this board?

The 3200 MHz figure is an overclocked speed; the board runs DDR4 at 1866/2133/2400 MHz by default and reaches 2667/2933/3200 MHz only when you enable the appropriate memory profile in BIOS.

Which PCIe generation and lane widths do the two main x16 slots provide?

The two primary slots are PCIe 3.0 x16 and operate in x16/x0 or x8/x8 modes with Ryzen processors, while 7th generation A-series and Athlon CPUs run them at x8/x0.

What physical space and mounting pattern does this ATX motherboard need inside a case?

It uses the standard ATX form factor with the usual nine mounting holes and rear I/O shield cut-out, so any ATX-compatible chassis will accept it.
