Black ATX motherboard with silver heatsinks and four DDR4 slots

MSI

MSI X99A SLI PLUS Intel X99 LGA 2011-v3 ATX Motherboard

SKU CH-WVC3-9BJF2

Supports LGA 2011-v3 CPUs with Intel X99 chipset, four-channel DDR4 up to 128GB, 4 PCIe 3.0 x16 slots for 3-way SLI, 10 SATA III ports, Realtek ALC892 7.1 audio, and Intel I218 Gigabit LAN

  • CPU Socket TypeLGA 2011-v3
  • CPU TypeNew generation Intel Core ™ i7 processor with LGA 2011-3 arc
  • ChipsetIntel X99
  • Memory StandardSupports four-channel DDR4 2133/2200 (OC)/2400 (OC)/2600 (OC
  • Maximum Memory Supported128GB
  • PCI Slots4 PCIe 3.0 x16 slots, up to 3-way mode - 1-way mode: x16/x0/
  • Supports four-channel DDR4 up to 3333 MHz for high-speed memory performance
  • 128 GB maximum capacity allows large workloads and multitasking
  • Four PCIe 3.0 x16 slots enable up to 3-way graphics configurations
  • 10 SATA III ports plus M.2 and SATA Express give extensive storage connectivity
  • Intel I218 Gigabit LAN and Realtek ALC892 7.1 audio provide wired networking and surround sound

Socket LGA 2011-v3 ATX board for Intel Core i7

The MSI X99A SLI PLUS uses the Intel X99 chipset and fits CPUs with LGA 2011-v3 packaging. Four-channel DDR4 support scales to 128GB across a wide OC range from 2133 to 3333 MHz. Four PCIe 3.0 x16 slots plus two PCIe 2.0 x1 slots give room for multi-GPU or add-in cards. Ten SATA III ports, one SATA Express and one M.2 interface cover storage. Realtek ALC892 delivers 7.1 channel audio with S/PDIF. Intel I218 provides gigabit LAN. Six USB 3.0 and six USB 2.0 ports handle peripherals.

Check CPU PCIe lanes and cooler clearance

This board is limited to CPUs that support 40 PCIe lanes for full 3-way x16/x16/x8 operation; lesser lane counts change slot wiring to x16/x8 or x8/x8/x8. Verify your processor matches the LGA 2011-v3 socket and lane requirement before ordering. Ensure the chassis fits ATX dimensions and that the CPU cooler clears the socket keep-out zone. Confirm the power supply carries the necessary EPS connectors for the X99 platform. Match DDR4 modules to the qualified speed list for stability.

ATX layout with reinforced slots and rear I/O

The ATX form factor uses standard mounting holes for typical chassis. Steel-armoured PCIe x16 slots resist sag from heavy graphics cards. Rear I/O panel integrates two USB 3.0, two USB 2.0, LAN, audio jacks and S/PDIF. Four internal USB 3.0 and four USB 2.0 headers support front-panel ports. One M.2 and one SATA Express connector sit alongside ten angled SATA III ports for tidy cable routing. Package supplies the board, CMOS battery, one SATA cable and the chassis I/O back panel.

Highlights

  • Supports four-channel DDR4 up to 3333 MHz for high-speed memory performance
  • 128 GB maximum capacity allows large workloads and multitasking
  • Four PCIe 3.0 x16 slots enable up to 3-way graphics configurations
  • 10 SATA III ports plus M.2 and SATA Express give extensive storage connectivity
  • Intel I218 Gigabit LAN and Realtek ALC892 7.1 audio provide wired networking and surround sound

Specifications

BrandMSI
SeriesMSI X99A SLI PLUS
ModelMSI X99A SLI PLUS
CPU Socket TypeLGA 2011-v3
CPU TypeNew generation Intel Core ™ i7 processor with LGA 2011-3 architecture.
ChipsetIntel X99
Memory StandardSupports four-channel DDR4
2133/2200 (OC)/2400 (OC)/2600 (OC)/2666 (OC)/2750 (OC)/3000 (OC)/3110 (OC)/3333 (OC) MHz memory
Maximum Memory Supported128GB
PCI Slots4 PCIe 3.0 x16 slots, up to 3-way mode
- 1-way mode: x16/x0/x0/x0
- 2-way mode: x16/x16/x0/x0 *, 16/x8/x0/x0 **
- 3-way mode: x16/x16/x0/x8 *, x8/x8/x8/x0 **
2 PCIe 2.0 x1 slots
Limited to CPUs that support 40 PCIe channel specifications.
Limited to CPUs that support 28 PCIe channel specifications.
SATA RAID1XM.2 interface, 1xSATA Express interface, 10xSATA III interface
Audio ChipsetRealtek ALC892 Decoder Chip
- 7.1 channel high-quality sound effects
- Supports S/PDIF output
LAN Chipset1 Intel I218 Gigabit Network
Onboard USBIntel X99 Express Chipset
- 6 USB 3.0 ports (2 on the backplane, 4 supported through built-in USB 3.0 ports *)
- 6 USB 2.0 ports (2 on the backplane, 4 supported through built-in USB 2.0 ports)
ASMedia ASM1142
- 2 USB 3.1 ports located on the back panel
VIA VL805
- 4 USB 3.0 ports located on the back panel
Built-in JUSB1 interface supports MSI Super Charger.

Questions about this item

What comes in the box and which essential parts must be sourced separately?

The package includes the motherboard, a CMOS battery, one SATA cable and the rear I/O shield. You must buy a compatible LGA 2011-v3 processor, DDR4 memory modules, storage drives, a power supply and a chassis.

Which memory speeds and capacities does this board support for a high-capacity build?

It supports quad-channel DDR4 at 2133 MHz natively and up to 3333 MHz when overclocked, with a maximum of 128 GB across four slots.

What does the four-slot PCIe 3.0 x16 layout mean for a three-way graphics setup?

With a 40-lane CPU the board can run three cards at x16/x16/x8; with a 28-lane CPU the split becomes x8/x8/x8.
