Rectangular ATX motherboard, dark PCB with black and silver heatsinks, LGA 1151 socket, four DDR4 slots, multiple PCIe slots

MSI

MSI Z370 OC GAMING Intel motherboard

SKU CH-TEJ4-N2K0W

Supports 8th Gen Intel Core, Pentium and Celeron CPUs on LGA 1151 with DDR4 memory up to 4000 MHz and 64 GB capacity

  • CPU Socket TypeLGA 1151
  • CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as wel
  • ChipsetIntel Z370
  • Memory StandardSupport dual-channel DDR4 4000 + (OC)/3866 (OC)/3733 (OC)/36
  • Maximum Memory Supported64GB
  • PCI Slots1 PCIe 3.0 x16 slot (PCI_E1, x16 mode supported) 1 PCIe 3.0
  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 4000 MHz overclocked with 64 GB maximum capacity
  • Intel Z370 chipset provides one PCIe 3.0 x16 slot plus one x4 slot and four x1 slots
  • Realtek ALC892 codec delivers 7.1 channel high-definition audio
  • Intel RTL8111H Gigabit LAN with eight USB 3.1 Gen1 and six USB 2.0 ports

Z370 Chipset ATX Board

The MSI Z370 OC GAMING is an ATX motherboard built on the Intel Z370 chipset for LGA 1151 processors. It supports 8th Generation Intel Core, Pentium and Celeron CPUs. The board targets enthusiasts who want overclocking headroom and multi-GPU capability in a standard form factor.

64GB DDR4 Overclock Range

Four memory slots accept dual-channel DDR4 up to a maximum of 64GB. Supported speeds span from 2133 MHz through 2400, 2667, 2800, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3866 to 4000 MHz when overclocked. Headroom ends at the 64GB capacity limit and the highest validated frequency.

Expansion And Connectivity Layout

One full-length PCIe 3.0 x16 slot runs at x16 and a second at x4, joined by four PCIe 3.0 x1 slots for add-in cards. Storage uses one M.2 interface and six SATA III ports with RAID support. Rear I/O provides four USB 3.1 Gen1 Type-A ports and two USB 2.0 Type-A ports, while internal headers add four more USB 3.1 Gen1 and four USB 2.0 connections. Audio relies on the Realtek ALC892 codec for 7.1 channel output and networking uses an Intel RTL8111H Gigabit LAN controller.

Highlights

  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 4000 MHz overclocked with 64 GB maximum capacity
  • Intel Z370 chipset provides one PCIe 3.0 x16 slot plus one x4 slot and four x1 slots
  • Realtek ALC892 codec delivers 7.1 channel high-definition audio
  • Intel RTL8111H Gigabit LAN with eight USB 3.1 Gen1 and six USB 2.0 ports

Specifications

BrandMSI
SeriesMSI Z370 OC GAMING
ModelMSI Z370 OC GAMING
CPU Socket TypeLGA 1151
CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as well as Intel Pentium and Celeron processors
ChipsetIntel Z370
Memory StandardSupport dual-channel DDR4 4000 + (OC)/3866 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3300 (OC)/3200 (OC)/3000 (OC)/2800 (OC)/2667/2400/2133 MHz memory
Maximum Memory Supported64GB
PCI Slots1 PCIe 3.0 x16 slot (PCI_E1, x16 mode supported)
1 PCIe 3.0 x16 slot (PCI_E4, supports x4 mode)
4 PCIe 3.0 x1 slots
SATA RAID1XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC892 decoding chip
- 7.1 channel high-quality sound effects
LAN Chipset1 Intel RTL8111H Gigabit network interface card
Onboard USB- 8 USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the backplane, 4 via onboard USB ports)
- 6 USB 2.0 (High-speed USB) ports (2 Type-A ports on the backplane, 4 via onboard USB ports)

Questions about this item

Will my existing DDR4-2400 sticks run on the Z370 OC GAMING without manual overclocking?

Yes, the board natively supports DDR4 speeds from 2133 up to 2400 MHz without overclocking.

How can I confirm the Realtek ALC892 audio is delivering 7.1-channel output after assembly?

Open the Realtek Audio Console in Windows, select the 7.1 speaker configuration, then run the built-in speaker test to verify each channel.

Which cables and brackets come in the package so I know what to buy separately?

The box contains the motherboard, a CMOS battery, one SATA cable and the rear I/O shield.
