Dark green Micro ATX board with silver heatsinks and black I/O shield

MSI

MSI Z370M MORTAR LGA 1151 Z370 Micro ATX DDR4 64GB

SKU CH-3HGC-11NZT

Supports 8th Gen Intel Core CPUs with DDR4 up to 4000 MHz, dual M.2 and four SATA ports in a compact Micro ATX design

  • CPU Socket TypeLGA 1151
  • CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as wel
  • ChipsetIntel Z370
  • Memory StandardSupport dual-channel DDR4 4000 + (OC)/3866 (OC)/3733 (OC)/36
  • Maximum Memory Supported64GB
  • PCI Slots2 PCIe 3.0 x16 slots (supports x16/x4 modes) 2 PCIe 3.0 x1 s
  • Supports 8th Gen Intel Core processors with LGA 1151 socket
  • Micro ATX board measures 23.6 by 20.0 cm
  • Dual-channel DDR4 memory up to 4000 MHz overclocked
  • 1 channel audio via dual Realtek ALC892 decoding chips
  • Intel I219-V Gigabit LAN for wired networking

Intel Z370 Micro-ATX Motherboard

The MSI Z370M MORTAR uses the Intel Z370 chipset on a Micro-ATX form factor. It accepts 8th Generation Intel Core, Pentium and Celeron processors in an LGA 1151 socket. The board targets builders who want overclocking features in a compact chassis.

64GB Dual-Channel DDR4 Capacity

Four memory slots support dual-channel DDR4 up to a listed maximum of 64GB. Speeds range from 2133 MHz to 4000 MHz with overclocking. The 64GB ceiling suits most gaming and productivity workloads; heavy content creation or virtualisation may require more headroom.

Two PCIe 3.0 x16 Slots for Graphics

The board provides two PCIe 3.0 x16 slots operating in x16/x4 modes plus two PCIe 3.0 x1 slots. This layout allows a single graphics card at full bandwidth or a dual-card setup with the second card at x4 speed. Choose this board if your build needs that specific slot arrangement.

Highlights

  • Supports 8th Gen Intel Core processors with LGA 1151 socket
  • Micro ATX board measures 23.6 by 20.0 cm
  • Dual-channel DDR4 memory up to 4000 MHz overclocked
  • 1 channel audio via dual Realtek ALC892 decoding chips
  • Intel I219-V Gigabit LAN for wired networking

Specifications

BrandMSI
SeriesMSI Z370M MORTAR
ModelMSI Z370M MORTAR
CPU Socket TypeLGA 1151
CPU Type8th Gen Intel Core ™ processors with LGA1151 support, as well as Intel Pentium and Celeron processors
ChipsetIntel Z370
Memory StandardSupport dual-channel DDR4 4000 + (OC)/3866 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3300 (OC)/3200 (OC)/3000 (OC)/2800 (OC)/2667/2400/2133 MHz memory
Maximum Memory Supported64GB
PCI Slots2 PCIe 3.0 x16 slots (supports x16/x4 modes)
2 PCIe 3.0 x1 slots
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetDual Realtek ALC892 Decoding Chip
- 7.1 channel high-quality sound effects
- Supports S/PDIF output
LAN Chipset1 Intel I219-V Gigabit network interface card
Onboard USB8 USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the backplane, 4 via onboard USB ports)
6 USB 2.0 (High-speed USB) ports (2 Type-A ports on the backplane, 4 via onboard USB ports)

Questions about this item

Will my existing DDR4-2400 memory run at its rated speed on the Z370M MORTAR?

Yes, the board supports DDR4 at 2400 MHz natively alongside higher overclocked speeds up to 4000 MHz.

How can I confirm the 7.1-channel audio is active after building the system?

Open the Realtek audio control panel in Windows and verify 7.1 speaker configuration is selectable and playback tests produce sound from all channels.

Does the box include the I/O shield and a SATA cable, or must I buy them separately?

The package contains the motherboard, one SATA cable and the chassis I/O back panel; no other accessories are included.
