MSI Z390 PLUS Intel motherboard LGA 1151 DDR4 128GB ATX
Supports 9th Gen Intel Core, Pentium and Celeron LGA 1151 CPUs with dual-channel DDR4 4400MHz up to 128GB, two PCIe 3.0 x16 slots, 7.1 Realtek ALC892 audio and Gigabit LAN
- CPU Socket TypeLGA 1151
- CPU Type9th Gen Intel Core ™, Pentium and Celeron processors with LG
- ChipsetIntel Z390
- Memory StandardSupports dual-channel DDR4 4400MHz memory
- Maximum Memory Supported128GB
- PCI Slots2 PCIe 3.0 x16 slots 3 PCIe 3.0 x1 slots 1 M.2 slot with E k
- Supports 9th Gen Intel Core processors with LGA 1151 socket
- Dual-channel DDR4 memory up to 4400MHz and 128GB capacity
- Realtek ALC892 codec delivers 7.1 channel high-definition audio
- Two USB 3.1 Gen2 ports at 10Gbps including Type-A and Type-C
- Six SATA III ports and two M.2 interfaces for storage expansion
Z390 Chipset LGA 1151 Board
This ATX motherboard uses the Intel Z390 chipset and fits LGA 1151 processors from the 9th generation Core, Pentium and Celeron families. It targets builders who want a full-size board for a mainstream Intel desktop platform.
128GB DDR4 Capacity and Dual-Channel Layout
Four memory slots support dual-channel DDR4 up to 4400MHz and a total of 128GB. The board handles large multi-tasking workloads and content-creation projects, but memory speed above the rated ceiling and capacities beyond 128GB are not supported.
PCIe 3.0 Lanes and Connectivity Limits
Two PCIe 3.0 x16 slots and three PCIe 3.0 x1 slots provide expansion for graphics and add-in cards. One M.2 slot with E key accepts only an Intel Wireless-AC CNVi module. Six SATA III ports and two M.2 interfaces handle storage, while the rear I/O supplies two USB 3.1 Gen2 ports at 10Gbps and eight USB 3.1 Gen1 ports. Realtek ALC892 delivers 7.1 channel audio and a single Gigabit LAN port handles wired networking.
Highlights
- Supports 9th Gen Intel Core processors with LGA 1151 socket
- Dual-channel DDR4 memory up to 4400MHz and 128GB capacity
- Realtek ALC892 codec delivers 7.1 channel high-definition audio
- Two USB 3.1 Gen2 ports at 10Gbps including Type-A and Type-C
- Six SATA III ports and two M.2 interfaces for storage expansion
Specifications
| Brand | MSI |
|---|---|
| Series | MSI Z390 PLUS |
| Model | MSI Z390 PLUS |
| CPU Socket Type | LGA 1151 |
| CPU Type | 9th Gen Intel Core ™, Pentium and Celeron processors with LGA1151 pin support |
| Chipset | Intel Z390 |
| Memory Standard | Supports dual-channel DDR4 4400MHz memory |
| Maximum Memory Supported | 128GB |
| PCI Slots | 2 PCIe 3.0 x16 slots 3 PCIe 3.0 x1 slots 1 M.2 slot with E key for Integrated Intel Wireless-AC (CNVi) module only |
| SATA RAID | 2XM.2 interface, 6xSATA III interface |
| Audio Chipset | Realtek ALC892 decoding chip 7.1 channel high-quality sound effects |
| LAN Chipset | 1 Realtek Gigabit network interface card |
| Onboard USB | Intel Z390 chipset 2 USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the backplane) 8 USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the backplane, 4 via onboard USB 3.1 ports) 4 USB 2.0 (High-speed USB) interfaces (4 provided via onboard interface) |
Questions about this item
Will this board take a 9th-generation Intel Core i7?
Yes, the LGA 1151 socket supports 9th Gen Intel Core, Pentium and Celeron processors.
How many DDR4 sticks can I install and what is the total limit?
Four slots accept dual-channel DDR4 up to 4400 MHz with a maximum capacity of 128 GB.
What expansion cards fit the two full-length PCIe slots?
Both are PCIe 3.0 x16, so graphics cards or other x16 add-in cards will work.
